InFocus HW-COMMANDER-2 User Manual

Batteries: The remote uses two (2) AA batteries. Install batteries by removing the cover from the back of the remote, aligning
the + and - ends of the batteries, pushing them into place, and replacing the cover.
Operation: Point the remote at the projector or at the screen (not at the video source or computer). The maximum operating
distance is 30 feet (9.14m).
Buttons and controls: Refer to your projector's reference guide for details on remote functions.
• Power - turns the projector on and off
• Laser - lights the laser pointer (CAUTION: Do not stare into the laser beam. Beam is emitted from front of remote)
• Help - shows interactive help for common picture and connection problems*
• Previous, Next - moves backwards and forwards through your presentation**
• Mouse control - moves mouse pointer**
• Left, Right - presses mouse buttons**
• Volume - adjusts sound level
• Custom - can be assigned a special function (older projectors may call this Effect instead)
• Source - switches between sources
• Blank - shows a blank screen instead of the source
• Presets - selects stored settings
• Mute - mutes sound
• Auto Image - resynchronizes the projector to the source
• Keystone - adjusts squareness of the image
• Overscan - removes noise around the edges of the image
• Resize - changes the aspect ratio
• Source 1, 2, 3 - directly accesses specific sources
• Menu - shows the projector's menu system
• - navigate menu items and adjust settings
• Select - confirm menu choices
• Backlight (side of remote) - lights remote buttons
Laser Information
Radiation specification:
• Laser Radiation Class II product; wavelength 650nm; maximum output 1mW
• Remote control complies with applicable requirements of 21 CFR 1040.10
• Remote control complies with applicable requirements of IEC 60825-1:Am 1. 1997
Commander 2 Remote Control
Model: HW-COMMANDER-2
Location of laser beam
warning label on back of
remote:
*Help, , and keys only function on
supported projectors.
**Presentation and mouse functions
require a USB or DisplayLink
connection between the projector and
computer.
See other side for warranty and troubleshooting.
power button
laser button
(see laser
information)
mouse control
backlight button
(side of remote)
connector for
wired remote
capability
included on some
projectors. Use a
shielded 2.5mm
stereo jumper
cable up to 50
feet long
(15.24m).
Batteries are not
required in the
remote when
cable is
connected.
