- Page 1 User’s manual MATRIX RANGE...
-
Page 3: Table Of Contents
SUMMARY Introduction ..................2 Unpacking ..................3 Control of accessories ..............4 Construction features ..............5 Technical data .................6 Installation ..................7 Place of installation .................7 Inlet reversibility ................7 Fixing of central unit ................9 Connection to pipe network ............11 Electrical connection ..............12 Use of central unit ................13 Use of accessories .................13 Maintenance .................14 Technical advice ................14... -
Page 5: Introduction
Congratulations for purchasing a DISAN central vacuum unit of Matrix range. A combination of technology, simplicity and well-being. The Matrix range is ideal: compact, practical and re- ally powerful and available in two different models: Matrix PT with disposable bags and Matrix FF with permanent flat cartridge and easy collection of the dust. -
Page 6: Control Of Accessories
2.1 Control of the accessories Check inside the box that all accessories are present: Central unit Metal fixing plate Two rubber muffs Four clamps for rubber muffs Paper bag User’s guide and Guarantee coupon Installation template Every central unit manufactured and packaged in our facility is standing an operational test and certified by every operation. - Page 7 3. Construction scheme Matrix PT Motor Motor protection Disposable bag Cover with quick fix Matrix FF Flat filter Dust container...
-
Page 8: Technical Data
4. Technical data : Field of application Matrix - PT Matrix - FF area up to max. tube length ca. 30 ca. 30 max. inlet valves Stk. Stk. TECHNICAL FEATURES: Power Motor stage Inlet power supply Volt Volt IPX Protection degree IP55 IP55 Max Vacuum... -
Page 9: Installation
5. Installation 5.1 Place of installation The installation of central unit is following to the layout of the piping set by an appointed installer. Considering the construction’s features, the protection class IP55 and the moderate noise level, the Matrix units can be installed even outdoor. The minimal room for installation chamber is 70 x 60 cm (lxh) 5.2 Inlet reversibility... - Page 10 5.3 Fixing the central unit Inside the packaging you will find the special installation template to easy the position and fixing, as well as the installation wall plate. 1. The template should be fixed on the wall where the central unit should be installed.
-
Page 11: Connection To Pipe Network
5.4 Connection to pipe network Connect with the muff and clamps included the middle side inlet in with piping network Connect with the muff and clamps included the outlet with the exhaust line. The silences (optional) can be connected near the exhaust grid. 5.5 Electrical connection Before plugging in the central unit make sure that the main power supply correspond to the voltage requirements written on the label, which referred to the data on the identification... -
Page 12: Use Of Central Unit
• Pay attention to the ceasing of the cleaner; Due to the vacuum pressure in the tubing and in the motor, the system remains active for a couple of second after switching it off; • Disan takes no responsibility for any harm or damage done due to misuse of the central unit. -
Page 13: Maintenance
No maintenance or repair work should be carried out on the central unit unless it is discon- nected from the main power supply. Disan recommend a general check of the electric motor, bearings, cables every 4/5 years. 7.2 Ordinary maintenance. -
Page 14: Troubleshooting
Modell Matrix FF: Open the front panel 1 and the internal panel 2, both with quick-fix magnets Slide out the dust container, remove the funnel and waste the content in the proper trash. Clean the flat filter by shaking and knocking or even with cold water, but make sure in the second option that this must be completely dry before to use it again. - Page 15 5. Blockages in the pipes. Contact the Disan customer service. 6. Simultaneous use of several inlet valves: the Matrix range is conceived to be used by a single person at the time. 7. Inlet valve seal damaged or not well secured. The air loss in connection with a whistling noise by a closed inlet valve is caused by a not perfect sealing or screwing of the inlet with pipes.
-
Page 16: Guarantee
The guarantee issued by Disan will be valid if the coupon is received by the manufacturer or installer no more than 30 days after the purchase date. Replacement parts under guarantee will not be issued if the payment terms were observed by the purchaser. - Page 17 ✁ da affrancare zu frankieren to stamp d’affranchir...
- Page 18 Certificato di garanzia - Garantieschein - Guarantee Coupon - Certificat de Garantie T i m b r o e f i r m a d e l v e n d i t o r e S t e m p e l u n d U n t e r s c h i e d d e s V e r k Š u f e r S t a m p a n d s i g n o f s e l l e r C a c h e t e t s i g n a t u r e Data di acquisto:...
- Page 20 central vacuum systems...
