- Page 1 Central Vacuum Systems OWNER’S MANUAL CENTRAL VACUUM CLEANERS DS MODULAR MOD. DS A01 MOD. DS B01 MOD. DS B02 MOD. DS BC100i MOD. DS C03 MOD. DS CD125i MOD. DS D02 MOD. DS F03 MOD. DS H02...
- Page 2 Photos, drawings and descriptions in this handbook reflect the state of the art at the moment when this catalogue was printed. The company Disan reserves the right to update its production, previous catalogues and handbooks. For further information, please contact “DISAN”’s technical office.
-
Page 3: Table Of Contents
Unloading and handling of the power unit Technical features and main parts Central vacuum cleaner DS A01 100 l – 125 l – up to 1 operator . 6 Central vacuum cleaner DS B01 100 l – 125 l – up to 2 operators 6 Central vacuum cleaner DS B02 100 l –... -
Page 4: Introduction
Thank you for trusting and choosing our directives on the safety of electrical systems. brand. We are confident that the use of this three Disan’s central vacuum cleaner was engineered for phase central vacuum cleaning system with a a professional use, particularly focusing on the modular system will fully satisfy you. -
Page 5: Quality Controls
It is the purchaser’s responsibility always to con- • Checks during production trol the goods on delivery and check that they Disan’s central vacuum cleaners and their were not damaged during their transport. If a damage components are repeatedly subjected to quality... -
Page 6: Technical Features And Main Parts
CHARACTERISTICS OF THE CENTRAL VACUUM CLEANER AND MAIN PARTS Central vacuum cleaner Central vacuum cleaner model DS A01 100l – 125l model DS B02 100 l - 125 l 1 x 2,2 kW for 1 operator Code A100 – A125 2 x 2,2 kW for 2 operators Code B200 –... -
Page 7: Central Vacuum Cleaner Ds C03 100 L - 125 L - Up To 3 Operators
Central Vacuum Systems - cyclonic dust separator in steel, painted with epoxy Central vacuum cleaner powder, secured on a metal frame, filter chamber model DS C03 100 l – 125 l equipped with industrial-conceived star filter made of special polyester cloth with high withholding properties, 3 x 2,2 kW for 3 operators Code C100 –... -
Page 8: Technical Data Of The Central Vacuum Cleaner
Central Vacuum Systems... -
Page 9: Main Parts
CE220 Cap 5,5 kW Ø100mm code CE451 19. Main electric control box Cap 7,5 kW Ø100mm code CE451 · Mod. DS A01 code IE201 8. Filter chamber 100 l code CE702 · Mod. DS B01 code IE203 · Mod. DS B02... -
Page 10: Optional Parts
Central Vacuum Systems L I S T O F O P T I O N A L S • Automatic self-cleaning • Grill and pipe complete Z 277 Z 822 f i l t e r d e v i c e w i t h with two plastic bags. -
Page 11: Installation Of The Power Unit
Central Vacuum Systems INSTALLATION OF THE CENTRAL VACUUM CLEANER The central vacuum cleaner must be installed and the corresponding handbook “DESIGN - hooked up by an authorized installer. Instructions INSTALLATION – INSPECTION OF DS SUPER for a correct installation of the system are given in COMPACT AND DS MODULAR SYSTEMS”. -
Page 12: Check Of The Functioning Of The Automatic Filter Shaker
Central Vacuum Systems Sequence procedure 3. Reinsert the container by setting it under the vacuum cleaner. Please pay attention that the In the containers without dust bag the visual indicator visual indicator (9) remains outside. Push the (9) shows how full the dust container (17) is and lever to the bottom so that the container (17) when it is covered by dust it must be emptied. -
Page 13: Check Of The Functioning Of The Turbine
Central Vacuum Systems Z 828 Functional check of the turbine Check whether the turbine works properly: 1. Switch the system on and set the switches of the turbines (22) on the control panel in the position “manual”. 2. If noisiness or the emission of vibrations is higher than normal or in any case excessive, contact the installer. -
Page 14: Check Of The Lid Tight
Central Vacuum Systems Steps for filter dismantling: Control of the tight of the lid 1. Turn the filter (26) upside down to expose the fixing clamps (27). 2. Cut the clamps (27) and detach the housing (28) Control the tight of the lid (14) with the filter chamber from the filter (26). -
Page 15: Regular Maintenance
Each component original Disan star-filters was designed on the basis of strict safety guarantees Leave always the switch of the electric box in which Disan has adopted. the position “automatic”. Do not start the system when out of order. Electrical safety... -
Page 16: Troubleshooting
Central Vacuum Systems TROUBLESHOOTING SYMPTOM CAUSE 1 Filter clogging 2 Hose clogging 3 Wrong closing of the dust container – cyclone’s gasket (optional) damaged or out of place 4 Simultaneous use of several inlet sockets 5 Tubes clogging – air infiltration 6 Thermal contact breaker 7 Defective or dirty microswitch of the socket 8 Wear of the inlet socket’s contacts... - Page 17 Explore the tubes with a spiral probe (used for plumbing works) Contact Disan’s technical office insufficient air infiltrations 1A If there is no noise, switch on the system keeping the inlet suction sockets closed...
-
Page 18: Identification Data
Data identification for assistance or guarantee your central vacuum cleaner are indicated on the purposes identification plate. Whenever you contact Disan’s “technical assistance service” or the installer, specify the data of your A = vacuum cleaner’s model machine. A clear indication of the “machine’s model”... -
Page 19: Check List For The Installer
Central Vacuum Systems CHECK LIST FOR THE INSTALLER Check of inlet socket’s tightness Check of the turbine’s operation Check of the starting of the system at the Check of the functioning of the starting inlet sockets device system* Check of the wear of vacuum cleaning Check of the correct adjusting of the by- accessories pass valves... -
Page 20: Certificate And Guarantee Terms
To be filled in by the manufacturer Tested by: Model: Serial number: GUARANTEE CERTIFICATE !I M PO R TA N T! Please send us this card, filled in, within 30 days to allow the recording of your guarantee right. Guarantee certificate Seller’s stamp and signature Model: Date of purchase:... - Page 21 Otherwise Disan may choose not to make the 24 months repairs. Furthermore, the manufacturer holds himself The Disan company undertakes to replace under...
