TreadClimber
by StairMaster
®
©
Owner's and Assembly Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TreadClimber and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stairmaster TreadClimber

Summary of Contents for Stairmaster TreadClimber

  • Page 1 TreadClimber by StairMaster ® © Owner’s and Assembly Manual...

  • Page 2: Table Of Contents

    Regulatory Information…………………………………………………………………………………………… FCC and Other Domestic / International Regulations…………………..………… StairMaster and the StairMaster logo are regestrered trademarks of Core Fitness LLC. TreadClimber is a registerd trademark of Nautilus Inc. and used under license. Every effort has been made to keep this information current; however, periodically, changes are made to the information herein, and these changes will be incorporated into new editions of this publication.

  • Page 3: Introduction

    The information on the following pages will enable you to begin easily, quickly and safely. WARNING Your TREADCLIMBER® is designed for aerobic exercise in a gymnasium or health club environment. Please check with your physician prior to beginning any exercise program.

  • Page 4: Safety Instructions

    This chapter includes fitness safeguards and precautions for the installation and use of the TREADCLIMBER®. These safety notes are directed to you as the owner of the machine. Please read this chapter carefully before installing or using your equipment and be sure to train all your members and fitness staff to follow these safety instructions.
  • Page 5 Verricht regelmatig preventief onderhoud. beschadigd is. Neem contact op met uw geautoriseerde StairMaster detailhandelaar Houd het snoer bij verwarmingssystemen of de onderhoudsafdeling van StairMaster vandaan. op +1 (888) 678-2476 of bezoek onze website op http://www.stairmaster.com voor een onmiddellijke inspectie of reparatie.

  • Page 6: Precautions

    CAUTION: MOVING PARTS, KEEP HANDS AND FEET FROM UNDER THE TREADCLIMBER WHEN OPERATING These safety notes are directed to you as the owner of the TREADCLIMBER. For safety purposes, please train all your members and fitness staff to follow these safety instructions. DO NOT...
  • Page 7 Do set your goals (see Getting Started in Do not overtighten the walking belt. Chapter 4). Do not operate your TreadClimber if it has a Do complement your walking with a damaged cord or plug, if it is not working nutritious diet.

  • Page 8: Mesures-De-Precaution

    LA PARTIE INFERIEURE DU TAPIS ROULANT FERME PENDANT SON FONCTIONNEMENT. Ces instructions sont destinées su propriétaire du TREADCLIMBER. Assurez vous que votr personnel et vos adhérents les suivent toujours. Encouragez vos adhérents à parler de leur programme d’entraînement à un médecin ou Respectez les périodes d’échauffement et de...
  • Page 9 Ne laissez pas d’enfants non-accompagnés sur le tapis. Une surveillance très stricte est néecessaire si des personnes invalides ou handicapées utilisent le tapis. Ne pas dépasser la charge maximum (159 kg) admise pour le tapis roulant. Ne laissez jamais le tapis sans surveillance s’il est branché.

  • Page 10: Sicherheitsvorschriften

    Complétez votre entraînement par un des aérosols ou de l’oxygène ont été utilisés. régime alimentaire. Débranchez le tapis avant le nettoyage ou le Suivez votre progrès grâce aux informations changement de fusibles. du tableau de bord. N’enlevez pas de vis, ne modifiez pas Essayez d’utiliser l’inclinaison afin de brûler l’appareil.
  • Page 11 Sicherheitshinweise sind an Sie, den Besitzer des Laufbandes TREADCLIMBER, gerichtet. Bitte weisen Sie Ihre Mitglieder und Ihre Fitneß-Mitarbeiter an, sich an die folgenden Sicherheitsvorschriften zu halten. LESEN SIE ALLE ANWEISUNGEN VOR DER BENUTZUNG DEL LAUFBANDES. WARNUNG: Um das Risiko eines elektrischen Schlages zu vermeiden, nehmen Sie den Stecker des Laufbands vor dem Reinigen IMMER aus der Netzsteckdose.

  • Page 12: Instruzioni Di Sicurezza

    ATTENZIONE: PRIMA DI PULIRE O ESEGUIRE LA FERMA IL MANUTENZIONE, TOGLIETE LA SPINA MOVIMENTO CORRENTE ALTERNATA ATTENZIONE: PRIMA DI USARE LEGGETTE IL MANUALE DELLE ISTRUZIONI ACCESO ATTENZIONE: PARTI IN MOVIMENTO. DURANTE IL FUNZIONAMENTO DEL TREADCLIMBER ALLONTARE SPENTO MANI E PIEDI DAL SUO RAGGIO D'AZIONE...
  • Page 13 Queste indicazioni sono indirizzate ai proprietari del TREADCLIMBER. Chiedete a tutti I membri della vostra palestra e al vostro staff di seguire queste istruzioni di sicurezza. LEGGETE TUTTE LE ISTRUZIONI PRIMA DI USARE IL TREADCLIMBER. ATTENZIONE: per redurre il rischio di scossa elettrica, staccate SEMPRE la spina della corrente del treadclimber prima di pulirlo.
  • Page 14 MOVER PEÇAS COM A ESTEIRA EM O DESLIGAR FUNCIONAMENTO. Estas observações de segurança destinam-se à você, proprietário de TREADCLIMBER. Treine todos os membros e funcionários que utilizarão o equipamento para que sigam estas instruções de segurança. LEIA TODAS AS INSTRUÇÕES ANTES DE USAR SUA ESTEIRA ADVERTÊNCIA: para reduzir os rescos de choque elétrico, SEMPRE desconecte a esteira da...
  • Page 15 Mantenha o fio afastado de superfícies revendedor autorizado StairMaster ou o aquecidas. departamento de assistência técnica StairMaster pelo telefone 1 888 678 2476 ou Espere até que a esteira esteja acesse nosso “web site” no endereço completamente parada antes de descer do http://www.stairmaster.com para fazer uma...

  • Page 16: Instrucciones De Seguridad

    APAGADO MISMA ESTÉ EN FUNCIONAMIENTO Estas notas sobre seguridad van dirigidas a Vd. Como propietario del TREADCLIMBER. Haga que todos los usuarios y preparadores físicos cumplan estas instrucciones de seguridad. LEA TODAS LAS INSTRUCCIONES ANTES DE UTILIZAR SU TAPIZ RODANTE.

  • Page 17: Sikkerhedsinstruktioner

    Póngase en contacto con su vendedor autorizado de StairMaster, con el departamento de servicios de StairMaster Mantenga el cable separado de fuentes de llamando al número +1 888 678 2476 o calor.
  • Page 18 er sat til en stikkontakt, som har samme konfiguration som stikket. DER MÅ IKKE BRUGES ADAPTER TIL DETTE PRODUKT. Hvis produktet absolut skal omstilles til en anden slags el-net, skal omstillingen foretages af kvalificeret servicepersonale. FORSIGTIG: AFBRYD EL-KABLET, FØR DU GØR STOP (AF FUNKTION) RENT ELLER SERVICERER.
  • Page 19 är nödvändigt. eller væltet og er blevet beskadiget. Kontakt den autoreserede StairMaster, forhandler eller serviceafde-lingen hos StairMaster Ring Holdledningen fri af varmeanlæg. på +1 888 678 2476 eller du kan få fat i os på vores web-site: Vent til løbebåndet standser, før du stiger af...

  • Page 21: Assembly Instructions

    TreadClimber (Fig.1). Fig. 1 2. Cut all straps to remove the cardboard packaging along with any protective wrapping to expose the ® palletized TreadClimber base (Fig. 2). Fig. 2 3. Move all unattached components off the ® TreadClimber base (Fig. 3).
  • Page 22 ® 4. To move the TreadClimber off the pallet; remove the alternator shroud to expose the transport grip handles. With two people and each gripping a handle; drive the base off the rear of the pallet (Fig. 4). Fig. 4 5.
  • Page 23 Fig. 7 8. Mount the left & right lower handrail sections to the ® TreadClimber base and loosely thread four socket head cap bolts to each handrail mount (Fig. 8) along with sliding on the corresponding left & right handrail grommets into place.
  • Page 24 10. Slide on the second set of beauty rings (Fig. 10) onto each upper handrail while making sure the radius cutouts clear the available threaded holes. Fig. 10 11. Slide the console frame onto each upper handrail (Fig. 11) and rest the center of the console frame on top of the neck mast plate.
  • Page 25 13. Secure the console frame to the handrails (Fig. 13) by loosely threading two button head cap screws trough the rail into the console frame. Final Torque: o 35 In-Lbs (4.0 Nm) Fig. 13 14. Using a torque wrench, go back to steps: 6, 8, 9, 12, & 13 to thread all bolts mentioned in each step to their corresponding final torque (Fig.
  • Page 26 16. Mate all the applicable electrical connections to the back of display electronics board (Fig. 16). Fig. 16 17. Slide the left & right display alignment studs (Fig. 17) into the corresponding console frame guide holes to rest the top half of the display on to the console frame.
  • Page 27 (Fig. 21). Fig. 21 ® 21. Dislodge the rear step shroud from the TreadClimber base (Fig. 22) and move the handrail grommets up the handrails. Fig. 22...
  • Page 28 ® 22. Mount the rear shroud to the TreadClimber base and secure it in place by installing the corresponding five phillips head screws to the top (Fig. 23) and lower (Fig. 24) sections at the circled locations. Fig. 24 Fig. 23 23.
  • Page 29 Fig. 28 27. With two or more people, have one person carefully ® tilt the assembled TreadClimber (Fig. 29) at an angle by pushing up at the center of each handrail while the second person installs the rear stabilizing feet.
  • Page 30 ® 28. Transport/push (Fig. 30) the TreadClimber to its final location by rolling it into position. Fig. 30 29. Dislodge the rear step plugs (Fig. 31) to expose the wheel jacking bolts. Turn the bolts in a counter clock direction to retract the rear wheels into the base and rest the machine on the rear stabilizing feet.

  • Page 31: Operating Instructions

    OPERATING INSTRUCTIONS Operating the TREADCLIMBER® is very easy. Simply step onto the treadles, securely attach the pull cord STOP to an article of your clothing, press QUICK START, and begin walking. IMPORTANT: Before operating the unit, you must be familiar with the following equipment limitations and safety features.
  • Page 32 Incline Level Window: Shows the incline level from 1 to 5. Numeric Keypad: Allow you to enter specific values for program parameters during program setup. The numeric keypad can also be used to adjust TreadClimber speed while the TreadClimber is operating.

  • Page 33: Hot Bar Control Features

    TreadClimber. SAFTEY FIRST Your TreadClimber by StairMaster is equipped with an easy to reach HOT BAR that provides you with an additional PAUSE/STOP button and a Stop Switch. The Stop Lanyard Clip attached to the HOT BAR® is provided for your protection to stop the machine. Always attach the Stop Lanyard Clip to your clothing before each workout.

  • Page 34: Hints And Tips For Getting Started

    HINTS AND TIPS FOR GETTING STARTED The following hints and tips will assist in training your users to maximize the fitness benefits of your TREADCLIMBER®. Walk at a rate that feels comfortable and most natural, yet is sufficiently vigorous to get a good cardio workout.

  • Page 35: Preset Programs

    GOAL-BASED PROGRAMS (TIME, CALORIES, DISTANCE) When you begin a workout, often you have a goal in mind. With the TREADCLIMBER, you can set your program to your personal goal, and it will track your progress to help you reach it. You can set a goal for TIME, CALORIES or DISTANCE.
  • Page 36 (5-99 minutes), user weight, maximum speed desired and maximum level desired. The workout will begin at a low speed and level, and the TreadClimber will adjust the Speed and Level as you go. Speed and Level can also be adjusted manually at any time.

  • Page 37: Cooldown Cycle

    USING THE COOLING FAN The TreadClimber is equipped with a built-in cooling fan to increase your comfort during a workout. You can control the fan speed during your workout. The fan will automaticlly turn on one minute into your workout.
  • Page 38 NOTE: The performance of the transmitter may be affected by body types, body oils, metal in clothing, and outside electrical interference. Always be sure that the transmitter and skin are in good contact. Avoid operating other electrical equipment near your TreadClimber® when you use the heart rate strap.

  • Page 39: Preventative Maintenance

    Slipping-Walking Belt” (later in this chapter), or contact Customer Services as described at the beginning of this chapter. Ensure the power cord is not under moving parts of the TreadClimber This will ■ prevent the power cord from being pinched or from binding up the treadles.

  • Page 40: Monthly Maintenance

    MONTHLY MAINTENANCE WARNING: To prevent personal injury, always turn the machine off and unplug the power cord before performing maintenance inside the motor compartment. Remove the motor shroud and vacuum around the motor and its ventilation holes. Avoid bumping or ■...
  • Page 41 Slipping-Walking Belt: Remove the motor shroud and operate the machine slowly at 1 to 2 mph (2 to 3 kph). While observing the tailroller, walk on the belt and try to slow it down by gently applying pressure with your feet while holding the handrails. If only the walking belt, and not the tailroller, slows down, tighten the walking belt by turning both the right and left tailroller adjustment bolts clock- wise 1/4-turn.

  • Page 42: Settings And Testing

    SETTINGS AND TESTING After having used your TREADCLIMBER® for many workouts, you may wish to change some of its settings MANAGER MODE The Manager Mode allows you to query and modify the basic settings of your unit. To enter Manager Mode: Press and hold the keys together.

  • Page 43: Maintenance Mode

    OFF=Elevation function disabled. AUTO STOP ON=Auto stop feature enabled. OFF=Auto stop feature disabled. CSAFE ON=CSAFE communication enabled. OFF=CSAFE communication disabled. LOCK OUT ON=TreadClimber lock out enabled. OFF=TreadClimber lock out disabled. LOCKOUT ID 10000 12345 65535 TreadClimber lockout ID. MINIMUM 0.5/0.8 0.5/0.8...
  • Page 44 (see above). Number/Program Select Keys: Enter new data item values for numeric parameters. Stop Key: Exits Maintenance Settings Mode and restarts the TreadClimber greeting. The items that you may display and change with the previous keys are: Item...
  • Page 45 Value Value Value Mc1 V X.XX Display’s primary processor software version and checksum. LOCKOUT ID 10000 12345 65535 TreadClimber lockout ID. MINIMUM 0.5/0.8 0.5/0.8 2.0/3.2 Minimum speed in mph (UNITS=English), or km/hr (UNITS=Metric). SPEED MAXIMUM 5.0/5.0 10.0/16.0 12.5/20.0 Maximum speed in mph (UNITS=English), or km/hr (UNITS=Metric).

  • Page 46: Motor Calibration

    The Motor Calibration function allows for calibration of the treadclimber's speed function. CAUTION: Changing Max Speed setting may expose users to increase risk. Any changes to the treadclimber's maximum speed settings should be clearly communicated to all users of the treadclimber. To enter the Motor Calibration function:...

  • Page 47: Troubleshooting

    ON. It may also happen if a key becomes stuck. When you see KEY DOWN: Set the ON/OFF switch to OFF; wait 2 seconds. Set the ON/OFF switch to ON. The TreadClimber should be operational again. Notify Service if additional assistance is needed.

  • Page 48: Regulatory Information

    FCC AND OTHER DOMESTIC / INTERNATIONAL REGULATIONS The TREADCLIMBER® has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC rules. Under the FCC guidelines, operation is subject to the following two guidelines: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
