OWNER'S GUIDE

AIR CONDITIONER

SPLIT AC WITH
INTERACTIVE
REMOTE
TRANE SPLIT AC
Pictures of the actual product may di er as per the product purchased.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPLIT AC and is the answer not in the manual?

Questions and answers

Summary of Contents for Trane SPLIT AC

  • Page 1: Air Conditioner

    INTERACTIVE OWNER’S GUIDE AIR CONDITIONER SPLIT AC WITH INTERACTIVE REMOTE TRANE SPLIT AC Pictures of the actual product may di er as per the product purchased.
  • Page 2 Once it’s in your home, a whole new world of evolved living experiences will open up to you. The ‘Trane mode’ optimizes comfort and e ciency. ‘E ciency meter’ on the remote keeps you updated on energy consumption, and therefore, keeps bills in check.
  • Page 3: Table Of Contents

    2.4.2.4. Fan Mode ......................................2.4.2.5. Sleep Mode ....................................2.4.2.6. Turbo Mode ....................................2.4.2.7. Fan speed ....................................... 2.4.2.8. Night latch Mode (Only for units with “TRANE Lock”) ......................2.4.2.9. Multi Room ....................................2.4.2.10. Swing Control ....................................2.4.2.11. Power ON and OFF ..................................
  • Page 4: About This Manual

    1. About this manual This manual is given as a guide to good practice for operating and periodic maintenance of TRANE Air Conditioners. This does not contain the full servicing procedures necessary for continued, or successful operation of this equipment. The services of a quali ed service personnel must be employed, through medium of maintenance contract with a TRANE service company.
  • Page 5: Safety Information

    1.1. Safety Information Indicates a potentially hazardous situation which, if not avoided, could result in serious injury. Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or property damage. Obey the following points to prevent electrical shock or re: Don’ts Do not remove power plug while the unit is in operation.
  • Page 6 Do not place ammable spray near this unit. It can cause • ignition and explosion. Do not insert or stick your hands into air intake or outlet • vents. It is dangerous and can cause injury. Do not spray or wash the unit with water. It can cause electrical •...
  • Page 7 • Do not insert any objects or ngers into the outdoor unit fan. It may cause unit failure and/or serious injury to the person. Do not touch the ns at the back side of outdoor unit. It can • cause injury. •...
  • Page 8 Operate this unit with stable voltage in range of 230 ± 10%, • single phase. If not done, compressor can vibrate and damage refrigeration system. Use only fuse of correct capacity. Incorrect wire can cause • breakdown or re. Turn off the power supply •...
  • Page 9 Run in the Green Zone Set the unit at TRANE mode for e cient performance. It will • save energy. It is suggested to use TRANE recommended stabilizer. For stabilizers check with local TRANE • distributor. 48626782 rev 2 Contents...
  • Page 10: Product Overview

    1.2. Product Overview Indoor unit Indoor unit 1. Front panel 2. Air inlet 3. Air filter 4. Air outlet 5. Horizontal air flow grille 6. LED display 7. Remote control Outdoor unit 8. Connecting pipe 9. Connecting cable 10. Sensor cable 11.
  • Page 11: Operation

    2. Operation 2.1. Remote Operation • Make sure power is ON • Select the room which needs to be controlled. • Refer section 2.4.2 for di erent functions of remote. 2.2. Manual and Auto Restart Operation Manual operation can be used temporarily in case remote controller is not available. •...
  • Page 12: Indicators

    Unit status LED1 LED2 Stand by Stand by + Error on PCB Operating without TRANE mode GREEN Operating without TRANE mode and Error on PCB GREEN TRANE mode active GREEN GREEN TRANE mode active + Error on PCB GREEN GREEN and RED Blinks alternately...
  • Page 13: Remote Controls

    Energy Efficiency Meter Error Message Display Room Selection Power ON/OFF Increase Temperature Fan Speed Decrease Temperature Louver Direction Sleep/Turbo Mode Mode Adjustment TRANE Mode Remote Night Latch Multi Room Control Figure - 6 Symbol Button Function Display Description Fan speed Air ow rate adjustment.
  • Page 14: Range Of Operation

    (Refer Figure - 5) It will set room temperature automatically based on outdoor temperature. Unit shall exit ‘TRANE mode’ if user changes any of the following: set point, fan speed, mode, sleep and also if button is pressed.
  • Page 15: Cool Mode

    Unit will not exit ‘TRANE mode’ if user changes any of the following: swing button, multi room or night latch button. The indication of TRANE mode is button with red back light and the remaining buttons with light OFF. The back light will go OFF after 20 seconds from last operation of remote controller.
  • Page 16: Turbo Mode

    Figure - 14 Figure - 14 Fan speed is adjusted automatically according to set point and room temperature when FAN speed is set to AUTO mode. 2.4.2.8. Night latch Mode (Only for units with “TRANE Lock”) LOCK AC Remote Press Twice...
  • Page 17: Swing Control

    Adjust air ow direction properly otherwise it can cause discomfort or uneven room temperatures. 2.4.2.11. Power ON and OFF Press ON/OFF button to switch ON/OFF the unit. When power is ON, the unit operate in TRANE mode by default. Remote back light will glow in red 2.4.3.
  • Page 18: Stabilizer Detail

    2.5. Stabilizer Detail AC Tonnage Stabilizer KVA 3. Maintenance 3.1. Cleaning air lter Clogged air lter decreases cooling e ciency. Clean lter at interval of two weeks. Disconnect power supply before cleaning indoor unit. • Lift Front panel up to an angle, keeping it attached Support pole until it makes a clicking sound.
  • Page 19: Maintenance (Unit Not In Use For Long Duration)

    3.2. Maintenance (Unit not in use for long duration) If you do not plan to use unit for a long time, perform following actions: • Clean indoor unit and lters. • Operate fan for approximately 30 minutes in order to dry inner side of unit. •...
  • Page 20: Troubleshooting

    4. Troubleshooting Before requesting service, perform following checks. Symptom Remedy Compressor restarts after approximately Waiting Indoor unit does not give three minutes to protect itself. On cool air immediately when compressor restarting units starts to give unit starts. cool air again Open the door or window for 2 minutes Unusual odor blowing from and run the AC in Fan mode to allow fresh...
  • Page 21: Error Messages And Actions

    Contact service Operates indoor technician unit and outdoor unit as per user Error 05 outdoor temp OUTDOOR TEMP SENSOR setting. If TRANE 0x05 sensor failure contact ERROR mode is activated service technician unit should operate at set point 24 °C.
  • Page 22 Error Error Displayed on Action to be Error Description Unit Response Code Remote taken by user Unit operates Remote not in network Remote must be NETWORK NOT FOUND as per previous range in network range settings. Connect to network (if Unit operates Contact service user did factory reset on...
  • Page 23: Warranty

    Terms & Conditions Ingersoll-Rand (hereinafter referred to as ‘the company’) warrants to the purchaser that this TRANE split air conditioner (“Product”) carries a warranty for the period mentioned above, commencing from the date of purchase. The company will repair or replace free of charge any part or parts of the Product, if the defect is due to the defective material or workmanship.
  • Page 24 While the company undertakes responsibility to supply only the compressor free of cost during warranty period, cost of labour, transportation and other incidental expenditures shall be borne by the customer after the lapse of rst year Product warranty. In areas where voltage uctuates +/-10% of rated or usable voltage, customer is advised to use a branded voltage stabilizer which steps up or down the incoming voltage to give an output of 230V.
  • Page 25 Corporate Office: Plot No.35, KIADB Industrial Area, Bidadi, Ramanagaram Taluk, Bangalore-562109, Karnataka, INDIA. www.traneindia.com For more information call on 1800 102 9986 or write to smartcare@trane.com 48626782 | Edition 2 | January 2013...
