Replacement Parts.
For 20–52 gallon models with single or double elements.
Relief valve
Hot outlet heat tube
(on side connect
models only)
Shroud
Shroud
Drain valve
Cold inlet nipple
(on side connect
16
models only)
Instructions For Placing a Parts Order
To place orders using a Visa/MasterCard
call 800-431-1549.
All parts orders should include:
The model and serial number of the
water heater from the rating plate.
Specify voltage and wattage as
marked on the rating plate.
Relief valve
**Heat Trap
**Nipple
Anode rod
attempt repair of electrical wiring,
thermostat(s), heating elements or
other operating controls. Refer repairs
to qualified service personnel.
Dip tube gasket
(on top connect models only)
Anode rod
Top Connect Models
(see illustration below for other parts)
Upper thermostat*
Upper thermostat protective cover*
N OFF
TUR
ER
POW
OR
E
BEF
VIC
ING
SER
Thermostat bracket*
Heating element*
Heating element gasket*
Lower thermostat
Lower thermostat protective cover
Heating
element
Heating element gasket
Part description (as noted below)
and number of parts desired.
CAUTION: For your safety DO NOT
**Heat Trap
**Nipple
Dip tube (on top connect models only)
Junction box cover
Plate cover
**Not supplied
on all models
Junction box cover
Plate cover
Cavity insulation
Jacket access cover
Cavity insulation
Jacket access cover
Thermostat bracket
*These parts are supplied only on
double element models
