SKYLINE
Natural Gas Barbecue
Owner's Manual
®
WARNING: Follow all leak check procedures
carefully in this manual prior to barbecue
operation. Do this even if barbecue was
dealer assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
1200
™
Serial Number
Please use this number in registering your warranty
and any correspondence with the factory.
WARNING: Do not try to light this appliance
without reading "Lighting" instructions
section of this manual.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your
gas supplier or your fire department.
98695
1/98

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Skyline 1200 NG and is the answer not in the manual?

Questions and answers

Related Manuals for Weber Skyline 1200 NG

Summary of Contents for Weber Skyline 1200 NG

  • Page 1 Serial Number Please use this number in registering your warranty and any correspondence with the factory. SKYLINE 1200 ™ Natural Gas Barbecue Owner’s Manual ® WARNING: Do not try to light this appliance WARNING: Follow all leak check procedures without reading "Lighting" instructions carefully in this manual prior to barbecue section of this manual.
