Hitachi CP-A222WN Quick Manual

CP-A222WN LCD Projector
Accessories and Lenses
Supplied Remote control, power cord,
Accessories computer cable, user's manual,
network manual
Optional UST1WALLARM, A3WALLARM,
Accessories USBWL11N USB wireless adapter,
MS-1 wired multifunction switcher,
MS-1WL wireless multifunction switcher,
TT-251 tabletop stand
Optional Lenses
N/A
Replacement Parts
Lamp DT01381 with filter
Remote Control HL02882
Filter UX37191
Projection Throw Chart (In inches)
Screen Size 4:3 Throw Distance
Diagonal Distance from
leading edge of
projector to screen
60 3.8
70 6.3
80 8.9
90 11.4
100 13.9
Throw Ratio: (distance : width)
0.1 : 1 from edge of projector
0.3 : 1 from mirror
HI0133-Rev.1-09/13
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2013 Hitachi America, Ltd. All Rights Reserved.
Hitachi America, Ltd.
Toll Free: 1.800.HITACHI Email: dmd.info@hal.hitachi.com
•
Web: hitachi-america.us/projectors
Specifications
Projection Technology
Resolution
White Light Output
Color Light Output
Colors
Aspect Ratio
Contrast Ratio
Throw Ratio
(distance : width)
Lens
Lamp Wattage
Expected Lamp Life*
Expected Filter Life**
Speaker Output
Acoustic Noise Level
Keystone
Computer
H-Sync
V-Sync
Composite Video
Distance from
Component Video
mirror to screen
HDMI
15.9
Digital Input
18.4
Computer Input 1
Computer Input 2
20.9
Computer Monitor Output
23.4
Video Input
26.0
Audio Input
Audio Output
Network LAN Wired
Network LAN Wireless
USB
Control Terminals
Power Supply
Power Consumption
Operating Temperature
Dimensions (W x D x H)
Weight
Approvals
Warranty
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
3LCD, 3 chip technology
XGA - 1024 x 768
2,200 ANSI lumens
2,200 ANSI lumens
16.7 million colors
Native 4:3 / 16:9 and 16:10 compatible
4000 : 1 (using active IRIS)
0.1 : 1 from edge of projector to screen
0.3 : 1 from mirror to screen
F = 1.8, f = 4.1 mm
215W
Approximately 3,000 hours (standard mode)
5,000 hours (Eco mode)
Approximately 4,000 hours
10W
34 dB (28 dB in Eco mode)
H and V: +/- 5º
VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/UXGA
(compressed), MAC 16"
31.5 kHz - 106 kHz
56 Hz - 120 Hz
NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
480i, 480p, 576i, 720p, 1080i, 1080p
480i, 480p, 576i, 720p, 1080i, 1080p,
computer signal TMDS clock 27 MHz - 150 MHz
HDMI x 1 (HDCP compliant)
15-pin mini D-sub x 1
15-pin mini D-sub x 1
15-pin mini D-sub x 1
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2, (shared with computer in 1/2)
3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
RCA jack (L/R) x 1
RJ-45 port (10 base-T / 100 base-TX)
USB-A, IEEE802.11 b/g/n - optional wireless adapter required
Type A x 2 (PC-less presentation, wireless adapter)
Type B x 1 (USB display or mouse control)
9-pin mini D-sub x 1 (RS-232 control)
AC100-120V / AC220-240V, 50/60Hz
320W
32ºF - 104ºF (0ºC - 40ºC)
13.6" x 11.9" x 3.4" (excluding protruding parts)
Approximately 8.4 lbs.
UL 60950-1 / cUL FCC Part 15 subpart B Class B
3 year limited parts and labor
Extended Service Contract available (additional cost)
CP-A222WN
Ultra Short Throw
Series
