SPORTS MP3 PLAYER
OWNER'S MANUAL
MODEL: MF-FD150TB/TN/TS
MF-FD150EB/EN/ES
Please read this manual carefully before
operating your set.
Retain it for future reference.
Designs and specifications are subject to
change without notice for improvement.
The working life of this product is 7 years
since the date of purchase.

Advertisement

Table of Contents
loading

  Related Manuals for LG MF-FD150EB

  Summary of Contents for LG MF-FD150EB

  • Page 1 SPORTS MP3 PLAYER OWNER’S MANUAL MODEL: MF-FD150TB/TN/TS MF-FD150EB/EN/ES Please read this manual carefully before operating your set. Retain it for future reference. Designs and specifications are subject to change without notice for improvement. The working life of this product is 7 years...
  • Page 2: Table Of Contents

    Contents Important Safety Instructions Important Safety Instructions . .3 Before Operation ..38-39 To reduce the risk of fire or electric shock, do not expose Power on/off ....38 this appliance to rain or moisture.
  • Page 3: Precautions

    Precautions Player features and controls • If you plan not to use the main unit for a long time, remove the Accessories battery to avoid any damage caused by battery leakage and corrosion. • Avoid listening to the main unit while driving or operating any motorized vehicle.
  • Page 4: Top/ Front/ Bottom Panel

    Player features and controls Player features and controls Top/ Front/ Bottom Panel Rear Panel Book Mark (B.MARK) button (Tuner preset memory) Necklace connector Earphone Jack ( 3.5mm Hold Switch (HOLD Battery Cover Battery cover Volume (-/+) button Side Panel • MENU Dial (FM/MP3 function selection) Microphone (MIC) •...
  • Page 5: Lcd

    Player features and controls Player features and controls To install Battery LIVE LIVE ROCK Open the battery cover. Play ( ), Pause ( ), Stop ( LIVE ROCK LIVE JAZZ LIVE ROCK JAZZ ROCK Counter unit ( STEP LIVE DIST JAZZ CALO ROCK...
  • Page 6: System Requirements

    You can update the MP3 Explorer software for Windows 98/ files without requiring the use of tapes or CDs. SE/ME/2000/XP available etc. from an internet website by LG MP3 is a well known, high quality digital audio format. MP3 files Electronics Inc.
  • Page 7: What Is "Wma

    How to use your MP3 Player What is “MP3 Player”? You’ll need to have MP3 files stored on your computer, a data New generation Digital Audio Player that does not require In/Out cable and your MP3 Player. tapes or CDs. Using the MP3 Explorer software, select the MP3 files you wish Pure sound guaranteed while handling, exercising and jog-...
  • Page 8: Installing Software

    Installing Software Installing Software To Install Manually The MP3-Explorer is the communication software that allows your computer to share information with your MP3 Player. In If automatic installing is not runned, try manual installing as per order for your MP3 Player to work properly, The MP3 Explorer the following description.
  • Page 9: Connecting Data In/Out Cable

    Connecting Data In/Out Cable Using MP3 Explorer To connect your MP3 Player to a PC Using MP3 Explorer To complete setup, you should connect the supplied Data The MP3-Explorer is the software that interacts with the MP3 In/Out cable to a PC from your MP3 Player. Player and a PC.
  • Page 10: To Format Memory

    Using MP3 Explorer Using MP3 Explorer Using MP3 Explorer To format memory This function deletes all files existing on the file list window of “Add” - Adds the file list window of MP3 Player to a MP3 Player. downloading file. Click “FORMAT”...
  • Page 11 Using MP3 Explorer Using MP3 Explorer The MP3 Player displays the process of file formatting. All file is deleted. Notes • Before formatting the internal memory, connect the Data In/Out cable to MP3 Player and PC. • Don’t remove the Data In/Out cable while formatting or down- loading a files.
  • Page 12: To Download Files

    Using MP3 Explorer Using MP3 Explorer To download files Click the “ Add” or “ ” icon. “Ready to transfer” appears. Before downing files to your MP3 Player and connect the MP3 Player to PC using the Data In/Out cable. Select file(s) to download.
  • Page 13 Using MP3 Explorer Using MP3 Explorer Click the “ Transfer(F6)” icon. The selected file has been downloaded. Now you can listen to music with the MP3 Player after The MP3 Player displays the process of file downloading. removing the USB cable. Notes •...
  • Page 14: To Upload Files

    Using MP3 Explorer Using MP3 Explorer To upload files The selected file has been uploaded. Select file(s) to upload. Click the “ Upload” or “ ” icon. Note MP3 and WMA files are not available to upload.
  • Page 15: To Delete The Files On Mp3 Explorer

    Using MP3 Explorer Using MP3 Explorer To delete the files on MP3 Explorer Click “ OK”. Select the file(s) to delete. Click the “ Delete” icon.
  • Page 16: Firmware Upgrade (Os Update)

    Using MP3 Explorer Using MP3 Explorer Firmware Upgrade (OS update) The selected file has been deleted. This function shows how to upgrade to the new version. Click “Edit” “OS update”.
  • Page 17 Using MP3 Explorer Using MP3 Explorer Click “ Start”. Click “ OK”. The MP3 Player is upgraded to the new version and then the OS update screen is closed automatically). Cancel Cancel...
  • Page 18: To Check Version Information

    Using MP3 Explorer Using MP3 Explorer To check version information MP3 Explorer update You can check OS version and Explorer version information. It means updating necessary files used by Explorer program. Click “About Explorer” “About MP3 Explorer MF- Click “View” “Explorer Update”.
  • Page 19: To Select Mp3 Explorer Menu Language

    Using MP3 Explorer Using MP3 Explorer To select MP3 Explorer menu language Click “ OK”. Click “View” “Language”. Select the menu language by moving the mouse. Cancel...
  • Page 20: Before Operation

    Before Operation Before Operation Power on/off Hold Function • To turn on, press the PLAY/ • This function locks the main unit to prevent it from operating PAUSE/STOP button. when you accidentally press a button. To turn off, press the Unlock it before operating.
  • Page 21: Basic Operation

    Basic Operation Basic Operation To skip the files To skip the next file • Press down briefly the SKIP/SEARCH ( ) dial on the main unit to select the next file. SKIP/SEARCH To skip the previous file ( / ) Dial •...
  • Page 22: Advanced Operation

    Advanced Operation Advanced Operation Book Mark Function To select the MENU If you set Book Mark function during file playing, you can You can choose 11 fixed menu by pressing the MENU Dial. search the setting point of the track automatically. Select the setting point you want during file playing, press and RETURN Equalize...
  • Page 23: Play Mode Function

    Advanced Operation Advanced Operation PLAY MODE Function To select the menu language You can choose between 4 fixed repeat mode. Equalize English Playmode Korean Disable Equalize Japanese Language Playmode Repeat Backlight Chinese Chinese Language Repeat All Contrast Russian Backlight Random Contrast Random All Press the MENU Dial.
  • Page 24: Contrast Function

    Advanced Operation Advanced Operation CONTRAST Function To delete files on the MP3 Player This function can adjust lightly or darkly the LCD by pressing Press the MENU Dial. SKIP/SEARCH ( / ) dial up or down in the “Contrast” menu. Select the “Erase”...
  • Page 25: To Check Memory And Version Information

    Advanced Operation Advanced Operation To check memory and version information Select the “Counter set” menu by pressing SKIP/SEARCH ( / ) dial up or down and then press the MENU Dial. You can check the memory and version information in the “About”...
  • Page 26: Return Function

    Press the Book Mark (B.MARK) button once or twice briefly. For your reference MF-FD150TB/TN/TS : About 8 hour Voice Recording MF-FD150EB/EN/ES : About 16 hour Available hour Note If the “Device Full” appears in the LCD, delete the files to save voice recording available hour.
  • Page 27: Presetting The Radio Frequency

    Radio Operation Radio Operation Erasing a preset radio frequency Presetting the radio frequency Press the MENU Dial during FM receiving. Press and hold SKIP/SEARCH ( / ) dial up or down until the frequency indication starts to change, then release. Select the “Erase”...
  • Page 28: Radio Recording

    Radio Operation Specifications Radio recording MF-FD150TB/TN/TS: 128 MB Memory Capacity MF-FD150EB/EN/ES: 256 MB • Press the Record (REC) button twice briefly during FM receiving. Battery AAA type (1EA) Dimensions (WxHxD) 66x66x22mm Weight 35g (without battery) Radio record indicator Record playing time Operating Voltage 1.5V DC...
  • Page 29 P/NO:3834RL0002A...
