INTERNET MP3 PLAYER
OWNER'S MANUAL
MODEL: MF-FD200TB/TN/TS
MF-FD200EB/EN/ES
Please read this manual carefully before
operating your set.
Retain it for future reference.
Designs and specifications are subject to
change without notice for improvement.
The working life of this product is 7 years
since the date of purchase.

Advertisement

loading

  Related Manuals for LG MF-FD200TN

  Summary of Contents for LG MF-FD200TN

  • Page 1 INTERNET MP3 PLAYER OWNER’S MANUAL MODEL: MF-FD200TB/TN/TS MF-FD200EB/EN/ES Please read this manual carefully before operating your set. Retain it for future reference. Designs and specifications are subject to change without notice for improvement. The working life of this product is 7 years since the date of purchase.
  • Page 2: Table Of Contents

    Contents Important Safety Instructions Important Safety Instructions . .3 Basic Operation ..41-42 To reduce the risk of fire or electric shock, do not expose To play files ....41 this appliance to rain or moisture.
  • Page 3: Precautions

    Precautions Player features and controls • If you plan not to use the main unit for a long time, remove the Accessories battery to avoid any damage caused by battery leakage and corrosion. • Avoid listening to the main unit while driving or operating any motorized vehicle.
  • Page 4: Side Panel

    Player features and controls Player features and controls Front/ Rear Panel Side Panel Volume (-/+) button MENU B.MARK VOLUME PRESET + FM/MP3 PRESET - Necklace connector MENU button Book Mark (B.MARK) button • MENU PRESET button FM/MP3 • PRESET + ••...
  • Page 5: To Install Battery

    Player features and controls Player features and controls LCD (MP3) To install Battery Volume level Open the battery cover. Local repeat indicator Current track/ Playing time (Total track) Equalizer (X-LIVE, JAZZ, ROCK, FLAT) Insert the battery. File information HOLD indicator Make sure to match the + and - on the batteries to the marks inside the battery compartment.
  • Page 6: System Requirements

    98SE/ME/2000/XP available etc. from an internet website by MP3 is a well known, high quality digital audio format. MP3 files LG Electronics Inc. Refer to the following sample contact can be compressed up to 12 times the original wave file size.
  • Page 7: What Is "Wma

    How to use your MP3 Player What is “MP3 Player”? You’ll need to have MP3 files stored on your computer, a data New generation Digital Audio Player that does not require In/Out cable and your MP3 Player. tapes or CDs. Using the MP3 Explorer software, select the MP3 files you wish Pure sound guaranteed while handling, exercising and jog-...
  • Page 8: Installing Software

    Installing Software Installing Software To Install Manually The MP3-Explorer is the communication software that allows your computer to share information with your MP3 Player. In If automatic installing is not run, try manual installing as per the order for your MP3 Player to work properly, The MP3 Explorer following description.
  • Page 9: Connecting Data In/Out Cable

    Connecting Data In/Out Cable Using MP3 Explorer To connect your MP3 Player to a PC Using MP3 Explorer To complete setup, you should connect the supplied Data The MP3-Explorer is the software that interacts with the MP3 In/Out cable to a PC from your MP3 Player. Player and a PC.
  • Page 10: To Format Memory

    Using MP3 Explorer Using MP3 Explorer Using MP3 Explorer To format memory Shortening icons This function deletes all files existing on the file list window of MP3 Player. Connects or releases to communicate between your Click “FORMAT” icon. MP3 Player and a PC. Click “Start”.
  • Page 11 Using MP3 Explorer Using MP3 Explorer The MP3 Player displays the process of file formatting. Click “Close”.
  • Page 12: To Download Files

    Using MP3 Explorer Using MP3 Explorer To download files All files is deleted. Before downing files to your MP3 Player and connect the MP3 Player to PC using the Data In/Out cable. Select file(s) to download. Notes • Before formatting the internal memory, connect the Data In/Out cable to MP3 Player and PC.
  • Page 13 Using MP3 Explorer Using MP3 Explorer Click the “ ” icon. The MP3 Player displays the process of file downloading.
  • Page 14: To Upload Files

    Using MP3 Explorer Using MP3 Explorer To upload files The selected file has been downloaded. Now you can listen to music with the MP3 Player after Select file(s) to upload. remov ing the USB cable. Notes • Do not remove the Data In/Out cable while downloading files. •...
  • Page 15 Using MP3 Explorer Using MP3 Explorer Click the “ ” icon. The MP3 Player displays the process of file uploading.
  • Page 16: To Delete The Files On Mp3 Explorer

    Using MP3 Explorer Using MP3 Explorer To delete the files on MP3 Explorer The selected file has been uploaded. Select the file(s) to delete. Note MP3 and WMA files are not available to upload.
  • Page 17 Using MP3 Explorer Using MP3 Explorer Click the “ Delete” icon. Click “ YES”. You can also delete the file by pressing the right button on the mouse.
  • Page 18: To Upgrade Firmware

    Using MP3 Explorer To upgrade firmware This function shows how to upgrade to the new version. The selected file has been deleted. Click “Tools” “Firmware Upgrade”.
  • Page 19 To upgrade firmware To upgrade firmware Click “ Start”. The MP3 Player displays the process of upgrade.
  • Page 20: Before Operation

    To upgrade firmware Before Operation Power on/off Click “ Close”. The MP3 Player is upgraded to the new version. To turn on, press the PLAY/PAUSE ( ) button. • To turn off, press the PLAY/PAUSE ( ) button for more •...
  • Page 21: Hold Function

    Before Operation Basic Operation Hold Function • This function locks the main unit to prevent it from operating POWER when you accidentally press a button. HOLD • Unlock it before operating. • If you set the Hold Switch (HOLD ) on the main unit to lock position and press a button in lock position, the “Holding.
  • Page 22: To Skip The Files

    Basic Operation Advanced Operation Book Mark Function To skip the files If you set Book Mark function during file playing, you can search To skip the next file the setting point of the track automatically. Press right briefly the SKIP/SEARCH ( ) dial on the Select the setting point you want during file playing, press and main unit to select the next file.
  • Page 23: Equalizer Function

    Advanced Operation Advanced Operation EQUALIZER Function REPEAT Function You can choose between 4 fixed repeat mode. You can choose between 4 fixed sound mode. Press MENU button, press SKIP/SEARCH ( ) dial Press MENU button, press SKIP/SEARCH ( ) dial left or right and then select “REPEAT”...
  • Page 24: Contrast Function

    Advanced Operation Advanced Operation CONTRAST Function BACK LIGHT Function Whenever any button is pressed, the LCD becomes bright. This function can adjust lightening or darkening the LCD. This function can set time of brightness displayed in the LCD. Press MENU button, press SKIP/SEARCH ( ) dial Press MENU button, press SKIP/SEARCH ( ) dial...
  • Page 25: Scroll Function

    Advanced Operation Advanced Operation To delete files on MP3 Player SCROLL Function Select a file you want to delete. This function adjust the speed of th file information which passed by the LCD. (The SCROLL Function is not available to Press MENU button, press SKIP/SEARCH ( ) dial the FM TUNER mode.)
  • Page 26: To Select Menu Language

    Advanced Operation Advanced Operation To select the menu language Voice Recording Press Record (••REC) button briefly twice on pause/stop Press MENU button, press SKIP/SEARCH ( ) dial mode. left or right and then select “LANGUAGE” menu. Start the voice recording to the Microphone (MIC) on the LANGUAGE main unit.
  • Page 27: Listening To The Radio Frequency

    Radio Operation Radio Operation Listening to the radio frequency You can preset 20 stations on the radio. Auto memory Press the MENU button for more than 1 second during file playing or pause mode. All available radio stations with sufficient signal strength will be stored automatically.
  • Page 28: Erasing A Preset Radio Frequency

    Radio Operation Radio Operation Erasing a preset radio frequency Radio recording • Press the Record (••REC) button twice briefly during FM Select a FM radio frequency you want to delete. receiving. Press MENU button, press SKIP/SEARCH ( ) dial left or right and then select “DELETE” menu. CH-02 89.1 DELETE...
  • Page 29: Before Calling Service Personnel

    Before calling service personnel Before calling service personnel To install recovery firmware program Click “ Start”. Press and hold the PLAY/PAUSE ( ) button and then connect the Data In/Out cable with the USB port of PC and the Data In/Out terminal of your MP3 Player. Double-click “MP3 Explorer MF-FD200”...
  • Page 30 Before calling service personnel Before calling service personnel The MP3 Player displays the process of upgrade. Click “ Close”. The MP3 Player is upgraded to the new version.
  • Page 31: Specifications

    Specifications MF-FD200TB/TN/TS: 128 MB Memory Capacity MF-FD200EB/EN/ES: 256 MB Battery AAA type (1EA) Dimensions (WxHxD) 26x78x24mm Weight 32g (without battery) Operating Voltage 1.5V DC Dynamic Range 55dB Earphone Output Power 5mW+5mW (1kHZ,0dB/16 Ω S/N Ratio 55/80 (No Filter/JIS-A Filter) Channel Separation 40/40 (1kHz/10kHz) Power Source Alkaline AAA size battery 1EA...
