Health - Foxconn Z68A-S Series User Manual

Health

Main Advanced
Case Open Warning
CPU Temperature
System Temperature
CPU Fan Speed
System Fan 1 Speed
CPU Vcore
DRAM Voltage
+12V SYS
+5V SYS
VBAT
Smart Fan Function
► Case Open Waring
This item is used to enable or disable case open waring function.
► CPU Temperature
These items show the current CPU temperature detected automatically by the system.
► System Temperature
These items show the current System temperature detected automatically by the system.
► CPU Fan Speed
This item shows the current CPU Fan speed detected automatically by the system.
► System Fan 1 Speed
This item show the current North Bridge Fan speed detected automatically by the system.
► CPU Vcore/DRAM Voltage/+12V SYS/+5V SYS/VBAT
These items show the Current CPU Ccore/DRAM/+12V SYS/+5V SYS/VBAT voltage de
tected automatically by the system.
► Smart Fan Function
This option is used to enable or disable smart fan function.Default value is [Enabled].
This item shows the current CPU Fan speed detected automatically by the system.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Chipset Boot Power Health
Health
[Disabled]
: +84 C
: +35 C
: 3000 RPM
: N/A
: +1.020 V
: +1.572 V
: +11.919 V
: +5.082 V
: +3.120 V
[Enabled]
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
Security Save & Exit
Enabled Case Open Warning and
open chassis, Intrusion Alarm
will appear. If don't enter
bios setup and disabled Case
Open Warning one time, Intrusion
Alarm don't clear,it will appear
all the time.
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
