Anedio U2 USB Converter

Specifications

Resolution: Up to 24 Bits
Sample Rates: 44.1K, 48K, 88.2K, 96K, 176.4K, 192KHz
Period Jitter: 20 ps rms
Asynchronous Mode: Yes
Two Independent Master
Yes
Clocks:
Processor: XMOS 500 MHz real-time processor
Galvanic Isolation: Yes, using an ultra high-speed transformer
Transformer Bandwidth: 115 MHz
SPDIF Output Rise Time: 6 ns
USB bus powered (no external power supply
Power:
needed)
USB Input Connector: Type B
15 feet
USB Cable Maximum Length:
5 meters
75-ohm BNC, gold plated
SPDIF Output Connector:
RCA adapter included
Recommended Coax Cable: RG-59, 75 ohms (not included)
USB Audio Class: 2.0
Operating System Windows 7, Vista, XP
Requirement: Apple Mac OS X
Thesycon driver for Windows
Driver:
No driver installation for Apple OS X
Dimensions (W x H x D): 2.8 x 0.9 x 4.1 inches (71 x 23 x 104 mm)
Weight: 4 oz (0.12 Kg)
U2 USB-to-SPDIF Converter
BNC (M) to RCA (F) adapter
BNC (M) to RCA (M) adapter
In the Box:
BNC (M) to BNC (M) adapter
Driver installation CD
Manual
4 5

Trouble Shooting

Symptoms
Installation fails
(Windows only)
"Anedio USB Audio" does
not appear in the audio
device property.
No sound through USB
If the problem persists, please contact Anedio via the "Contact"
page at www.anedio.com.
CE Compliance
This equipment has been found to comply with the requirements of
the EN 55022 and EN 61000-6 standards.
Anedio U2 USB Converter
Remedy
• Some USB devices might interfere with the
installation of the U2. Disconnect other USB
devices attached to your computer and check if it
affects the installation.
• When plugging the USB cable into the U2
converter, be sure to apply sufficient force so that
the plug is inserted promptly without hesitation.
• When plugging the USB cable into the U2
converter, be sure to apply sufficient force so that
the plug is inserted promptly without hesitation.
• For Windows computers, ensure that the driver is
installed correctly.
• If the above steps do not solve the problem,
unplug the USB cable, wait 10 seconds, and plug
it back.
• Ensure that the USB cable is plugged in fully and
seated properly.
• In your media player, ensure that "Anedio USB
Audio" is selected as the device for playback.
• If the above steps do not solve the problem,
unplug the USB cable, wait 10 seconds, and plug
it back.
WARNING: Repairs are to be performed by qualified
service personnel only. Please do not disassemble the
U2 as doing so might damage the EMI shield.
