Network Surveillance Camera
NSC 3615 / NSC 3621 / NSC 3622
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Leadtek NSC 3615

Summary of Contents for Leadtek NSC 3615

  • Page 1 Network Surveillance Camera NSC 3615 / NSC 3621 / NSC 3622 User Manual...
  • Page 2 Date Version Description Author 2006.09.25 1.0.0 Standard Operation 1450 2006.11.08 1.1.0 Installation Process Enhanced 1450 Webs Enhanced with : System Privacy password Network DIDO DDNS RTP port Camera Encode type 2006.11.09 1.1.1 MD sensitivity modification 1450 2006.12.06 1.2.0 PTZ feature enhanced 1450 Add in FAQs 2006.12.13...
  • Page 3 No part of this document may be copied or reproduced in any form or by any means without the prior written consent of Leadtek Research Inc. Leadtek makes no warranties with respect to this documentation and disclaims any implied warranties of merchantability, quality, or fitness for any particular purpose.

  • Page 4: Table Of Contents

    Index Package Contents ............. 6   Introduction ..............9   Key Features ............11   How to Connect？ ............ 12   System Requirement ..........15   Hardware Installation ..........15   Software Installation ..........16   Restore to factory default ......... 25  ...
  • Page 5 Use Windows Client for IP Cam ....... 49   Install Netcam SMC ..................... 49  Quick Launch ....................... 53  Overview ......................57  Add camera ......................58  Add one more group.................... 60  Modify camera’s connection setting..............60  Camera Connection Wizard ................. 61  Channel management ...................

  • Page 6: Package Contents

    Package Contents Contents - NSC3615- -NSC3621- Leadtek Surveillance Camera - NSC3615- -NSC3621- Accessories Software CD:...
  • Page 7 Ethernet cable: -NSC3615- / -NSC3621 Power Adaptor: -NSC3615- -NSC3621- - Page 7 -...
  • Page 8 SPK-MIC-PWR 3-in-1 cable -NSC3621- Mounting Rack: -NSC3615- - Page 8 -...

  • Page 9: Introduction

    Please unpack the product package with caution; inspect the Items closely. If you find any damaged item, please contact your local distributor immediately. Also, please keep the box and packing material for future use in the event of future shipments. Introduction High-quality, high efficiency video &...
  • Page 10 Unparalleled surveillance functions where nothing slips through your watch The network surveillance camera’s motion detection function sends out the alarm when any movement of any object occurring on the scene is detected, which makes it ideal for home and after-hour facility security. 16 preset positions can be programmed and the auto-cruise function will make the tour accordingly as if you were taking the patrol rounds in person.

  • Page 11: Key Features

    Key Features Surveillance Camera NSC3615 / NSC3621 Compact color CMOS / CCD camera Manual / Auto Pan and Tilt functions (Specified models) MPEG-4 / H.263 video and G.711 audio compression Internet connection compatible with Ethernet Support audiovisual transmission and recording A client viewer is able to simultaneously access multiple cameras located at different sites Built-in Web server for remote surveillance on network...

  • Page 12: How To Connect

    How to Connect？ Both NSC3615 / NSC3621 equip with 1DI / 1DO connector and PC compatible mono microphone and speaker. You can also find 2 pinholes (NSC3615:rear view / NSC3621: back side view of bottom) on surveillance camera. One is Factory Default and the other one is Reset.

  • Page 13: Led Indication

    LED Indication Network LED : BLUE - OFF : network link down or service unavailable - ON : network link is up - Blinking : in/out traffic on going System 1 LED : YELLOW - No RTP packet traffic - RTP received from remote peer (periodic flashing, 0.5 second on, 0.5 second off) System 2 LED :YELLOW - OFF : Do not register to SIP server...
  • Page 14 - NSC3621 - 10x optical / 10 digital CCD Factory Default Warm Reboot DIDO Connector Same as NSC3615 DIDO interface. DI : 0 ~ 12V(with 5V logic trigger) / 20 mA(minimum) DO: 30VDC / 1A - Page 14 -...

  • Page 15: System Requirement

    System Requirement Before you give surveillance camera a shot, please check setting of your notebook / PC and see if following requirement is proper. Windows XP with service pack 2 installed or DirectX 9.0 installed Best Screen Resolution : 1024x768 Color Quality : full color (32 bit) Hardware Installation - NSC3615 -...

  • Page 16: Software Installation

    -NSC3621- Software Installation Follow the procedures describe bellows to do a quick installation setup / test. 1. Device Connection: Connect your surveillance camera to PC (NSC3621 is taken as an example) - Page 16 -...
  • Page 17 Use crossover ethernet cable: Connect devices with ethernet hub / switch (normal RJ-45 cable) 2. Configure your PC to the same subnet segment of surveillance camera. i) The camera’s default IP is 192.168.0.100. We need to change our PC’s network setting first in order to connect to the camera.
  • Page 18 iii) Chooses Internet Protocol (TCP/IP), and then click Properties Chooses Use the following IP addresses, field, and input IP address with 192.168.0.139, subnet mask with 255.255.255.0, and then click - Page 18 -...
  • Page 19 Verify the on-line status of your surveillance camera. Please follow the procedure bellows a) Start Program Accessories Command Prompt .A DOS command shell screen will appear and shows "C:\>". b) Type ipconfig and press Enter. c) check if you can get the response from surveillance camera. d) Type ping 192.168.0.100 and press Enter.
  • Page 20 Launches Microsoft Internet Explorer and type URL: http://192.168.0.100, then you shall see the home page like bellows. The default username/ password is admin / admin, after you login to web you can get the video and find the system version on the lower-left corner For the very first time, IE will ask for user to download a video / audio decoder (a.k.a.
  • Page 21 Click the Install button to start installation of decoder plug-in. The live video will be displayed on IE after the plug-in automatically installed. In some case, your local PC may turn on the firewall option and the following warning message will pop up. Remember to click Unblock to allow the in-coming packet and avoid firewall protection.
  • Page 22 Note: In order to turn off the firewall protection, you can refer to Control Panel Windows Firewall General and turn off the Windows Firewall and permit the in-coming network packets (audio or video media packets) - Page 22 -...
  • Page 23 Otherwise, you can discriminately allow specific application and automatically unblock the firewall protection. You can check current firewall protection option of your network setting. If the network connection icon comes with a lock sign, that means the network interface is firewall protected by Windows Firewall. - Page 23 -...
  • Page 24 - Page 24 -...

  • Page 25: Restore To Factory Default

    Restore to factory default If the system is up and running, you can push factory default button through pinhole of surveillance camera (marked as Restore default, the Reset is used to perform a warm system reboot). The firmware will recover the setting to factory default.The following configuration is the firmware factory default setting: Default IP Setting IP mode: Fixed IP...

  • Page 26: Installing Scan Utility

    Installing Scan Utility The following procedures guide you through the steps of scan utility installation and operation: Step 1 : Visit WinPcap and download WinPcap version 3.1 from the website: http://www.winpcap.org/ Step 2 : Install WinPcap version 3.1(Installer for Windows / WinPcap_3_1.exe). Double click WinPcap_3_1.exe icon.
  • Page 27 Click Finish to complete installation. Step 3 : Launch Scan Utility and Assign new IP address to surveillance camera - Page 27 -...
  • Page 28 Double click the scan utility iiap.exe Click Scan button to send out scan packet to the LAN. iii) The found devices will be displayed on lower panel of utility program. The Status field shows you whether the device is ON LINE(configured in same subnet) or IDLE(not configured properly in the same subnet).
  • Page 29 will accept your designated network setting and reboot itself to be effective right away. The default IP network mode will be changed to Fixed IP mode after reboot(manually assigned by user’s). ☆ The standalone scan utility mentioned here can look up all the cameras in the same subnet(within same router boundary).

  • Page 30: Administrating From Webs

    Administrating from Webs Login ach surveillance camera includes a web interface system. As long as you know the camera’s IP, you can launch IE and access the camera’s IP. Logon to the web server and the following login screen will appear: In above screen, user name and password are required for user authentication.

  • Page 31: Download Activex Control

    Download ActiveX Control hen you use IE to connect the web first time, the system will ask you to download an Active control. To download an ActiveX control will take about one minute and the screen below will be displayed. Just press the “Yes” button.to install...

  • Page 32: Overlook

    Overlook hen the screen will appears as below: A: Menu: There are several items in the left column for you to choose: System, Network, Camera, User Management, and System Log. B: Version Information: Will list for users to know the detail information as following.

  • Page 33: System

    System n following screen, you may see 3 different sheets for System, SIP and Other configuration and can be switched by mouse click to each tabs. System Host Name Enter host camera name. Welcome Text Set your own welcome message in the login window. Date and Time 1.

  • Page 34: Sip

    SIP Phone Name SIP Phone Number IP Camera SIP Port Surveillance camera’s listen port for SIP invite SIP Server SIP Server IP (optional) Server Port SIP Server listen port (optional) Register Timer SIP Server register timer (second) Domain Name Domain Name of SIP Server Proxy Domain Proxy Domain of SIP Server User Name...

  • Page 35: Others

    Others Upgrade 1. Choose “Kernel” or “Ramdisk” to upgrade 2. Click “Browse…” to choose a valid kernel or ramdisk. 3. Press “Upgrade” to start upgrade. System Reboot Press "Execute" button to perform a soft reboot Reset Data to Factory Press "Initial" button to enable this function. It will revert its Default configuration to factory default setting.

  • Page 36: Dido

    DIDO DI Enable Enable Device Input device use DI Type Select for RISE or FALL type of DI(trigger edge). IM Notify IP Notify which IP address will be notified after DI triggered . *SMC will take action on behalf of this configuration . IM Notify Phone Notify which number will be notified after DI triggered .

  • Page 37: Surveillance Password

    Surveillance Password Enable Password The password is saved for the privacy viewing of IPCAM audio/video sources. If the option is enabled, client shall provide the password and being authenticated by IPCAM. Input Password Password for saving privacy connection. Confirm Password Confirm password for saving privacy connection.

  • Page 38: Network Control

    Network Control n following screen, you may see 3 different sheets for IP, FTP and SMTP configuration and can be switched by mouse click to each tabs. DHCP DHCP mode for acquiring an IP from DHCP server Static IP Assign and arrange IP setting on your plan. Including the IP address / Subnet Mask / Default gateway / Primary DNS / Secondary DNS settings PPPoE...

  • Page 39: Ftp

    Server Name FTP Server IP or Domain Name Login Name Login account for FTP server Password Login password for FTP server Note: This setting is effective when a snapshot sending is triggered by surveillance camera. - Page 39 -...

  • Page 40: Smtp

    SMTP Server Name SMTP Server IP or Domain Name Login Name SMTP mail account Password Password for the SMTP mail account Send From Sender information Send To Receiver email address Send To The 2 Receiver Send To The 3 Receiver Mail Title Subject of the email Mail Message...

  • Page 41: Ddns

    DDNS DDNS Client Enable Enable DDNS Client Support . DDNS Alias Alias DNS name DDNS Username DDNS service account username DDNS Password DDNS service password DDNS Uptimer DDNS Uptimer setting DDNS Fuptimer DDNS Fuptimer setting DDNS System ID System ID of DDNS, please use DYNDNS_DYNAMIC Note: For DDNS account subscription, please visit http://www.dyndns.org subscribe the service for your surveillance camera.

  • Page 42: Rtp Port

    RTP Port RTP Port range form Allow users to specify the RTP port range to send media stream from surveillance camera Please consult IT/MIS staff before you make modification of this configuration. ☆ - Page 42 -...

  • Page 43: Camera

    Camera Camera Resolution Adjust the resolution of the image (Restart required) Bit Rate Control Control the bandwidth automatically or manually Bit rate Control the available bandwidth manually. Frame Rate Choose the number of maximum frames to be sent by surveillance in frame per second Brightness Adjust the brightness of the image.

  • Page 44: Encode Type

    Encode Type Audio Type Configure audio encode type sent by surveillance camera. G.711 a-law G.711 mu-law Video Type Configure video encode type sent by surveillance camera. MPEG4 H.263 - Page 44 -...

  • Page 45: Call To

    Call to Enable Call assigned SIP agent phone number automatically Phone1 Assigned SIP phone number 1 Phone2 Assigned SIP phone number 2 Phone3 Assigned SIP phone number 3 Source The call triggered source Call Timeout The seconds of call timeout - Page 45 -...

  • Page 46: User Management Control

    Edit Edit user’s privilege control Delete Delete users Set user’s privilege control There are 3 levels of user privilege control in Leadtek network surveillance camera: Administrator, Guest Each group users are authorized with different web page management permissions. - Page 46 -...

  • Page 47: System Info

    System Info - Page 47 -...

  • Page 48: System Log

    System Log The system log book keeps system operating history in a cyclic way. The newest log record will over write the oldest log record. - Page 48 -...

  • Page 49: Use Windows Client For Ip Cam

    . In above screen, Netcam SMC stands for Surveillance Management Center, specially designed for the Leadtek Surveillance products .You may take advantage of the software to control and manage Leadtek Surveillance products .
  • Page 50 Press Next for continuing the install process. Please read the EULA carefully. Leadtek Netcam SMC is legally used for the Leadtek Surveillance Products and well-protected by the Copyright law. Press Next for continuing the installation process. - Page 50 -...
  • Page 51 Click the button marked by RED color and choose an installation folder or click Next to stay the default installation folder to continue the installation process. Click the Install to start the installation of Netcam SMC. - Page 51 -...
  • Page 52 You will see the installation progress from the green progress bar. While finished, please press Finish when installation is complete. - Page 52 -...

  • Page 53: Quick Launch

    Quick Launch You can click Windows Start->All Programs->Leadtek Research Inc->Netcam SMC- >Netcam SMC to launch the application. Otherwise you can click the Netcam SMC shortcut in desktop to launch the application. You will see the follow picture after you’ve launched Netcam SMC.
  • Page 54 Click the drop list which at the right-top corner, and then choice ‘Auto Scan’. It will display all cameras in the number list which have been connected to your network. Press ‘Refresh’ button to connect those cameras which are showing in the number list. - Page 54 -...
  • Page 55 You will see an ‘Input password’ image to ask the camera password in each camera. Right-click and choose ‘Input Password’ context in the menu. - Page 55 -...
  • Page 56 It will pop up an input box to ask the password of the camera. (The default password is: 12345) You will get the video and audio after you’ve inputted the correct password. - Page 56 -...

  • Page 57: Overview

    Overview There are some functions in the top of screen. File: Open records, System Diagnostic, Exit. View: Captions Setting: General Setting, Client SIP setting Window: Change layout Help: Version number. - Page 57 -...

  • Page 58: Add Camera

    Add camera Click ‘Add camera’ icon , and then the “Scan Camera” windows will pop up. Click ‘New Group’ button to add a group name. E.g.: Text Click ‘Scan’ button to capture any camera in the network. And then click to add the selected camera into ‘Test’...
  • Page 59 Click ‘Apply’ button And then you will see the ‘Test’ group list like below. Click ‘Refresh’ button, and then you will get the image. - Page 59 -...

  • Page 60: Add One More Group

    Add one more group. Of cause you call add as many group as you want. Modify camera’s connection setting. You can also modify the selected camera’s connection setting by clicking ‘Modify’ button. - Page 60 -...

  • Page 61: Camera Connection Wizard

    Camera Connection Wizard You can click ‘Wizard’ button the connect cameras easily! Please choose the connection mode Fill in IP Address, Name, and Password fields if you choose ‘Peer-to-peer’. - Page 61 -...
  • Page 62 Fill in Phone and Password fields if you choose ‘Through SIP server’. P.S. Please be noticed that you mush configure ‘SIP Setting’ first if you want add a camera through SIP server. - Page 62 -...
  • Page 63 Choose a group for the new camera. Choose if the new camera behind a NAT or not. - Page 63 -...
  • Page 64 You will get a new camera after the wizard was finish. - Page 64 -...

  • Page 65: Channel Management

    Channel management The texts that show on the image’s left-top indicate the information: : Number 192.168.129.108 : IP address 565 kb : Bandwidth 20 fps : Bit rate. The icons that show on the image’s right-top corner mean: : Re-connect : Two-way audio : Settings : Recording...

  • Page 66: Change Channel Layout

    Change channel layout You can change channel layout in the following way. E.g. Change to full screen by clicking the following button. - Page 66 -...

  • Page 67: Ptz Control

    PTZ control Navigation While the PTZ models being selected, the Navigation control panel can help users to do the manually control with the Pan, Tilt and Zoom features. Symbol Description Control the direction of UP-LEFT Control the direction of UP Control the direction of UP-RIGHT Control the direction of LEFT Control the RESET TO DEFAULT POSITION (HOME position)

  • Page 68: Preset

    Preset Presets are the position sets which users may pre-define the spots for the regular surveillance. Each preset can define its viewing angle and focus, a Preset Name is also included. If users already define a Preset Name, a tooltip will pop-up while user roll their mouse over the Preset buttons, just like the following picture.

  • Page 69: Cruise

    Cruise Cruise is the set of Presets; each cruise can contain 16 presets in it. If users did not define the cruise at the beginning, then the cruise button cannot be used Press to sop the cruise. - Page 69 -...

  • Page 70: Auto Pan

    Auto Pan PTZ IPCAM is able to do the automatically PAN with the lowest speed. This feature is designed for users can do the surveillance and move gently via the horizontal, visible angle of the PTZ camera. To start the Auto Pan, press the button.

  • Page 71: Device Setting

    Device setting Right-click a channel and choose ‘Device..’ context in the menu. You can manual some factor of the video quality. Resolution Adjust the resolution of the image (Restart required) Video Mode Control the bandwidth automatically(VBR) or manually(CBR) Bit rate Control the available bandwidth.

  • Page 72: Image Setting

    Image Setting Right-click a channel and choose ‘Image..’ context in the menu. Auto Exposure Adjust the Auto Exposure of the image for ON/OFF. Auto White Balance Adjust the white balance of the onscreen image for ON/OFF. Adjust the HUE of the image. Saturation Adjust the color saturation level of the image.

  • Page 73: Network Setting

    Network Setting Right-click a channel and choose ‘Network..’ context in the menu. DHCP DHCP mode for requiring an IP from DHCP server Fixed IP User can configure their prefer IP. Including the IP address / Subnet Mask / Default gateway / Primary DNS / Secondary DNS settings PPPoE Especially for ADSL users who can set their account and...

  • Page 74: Motion Detect Setting

    Motion Detect Setting Right-click a channel and choose ‘MotionDetect..’ context in the menu. Sensitivity This parameter determines the sensitivity of embedded motion detector algorithm. Area of Detection : Define the area ; 3 areas , each needs to be defined separately E-mail Setting: Configure the SMTP for sending out the captured image FTP setting: Configure the FTP for transferring the captured images...

  • Page 75: Dido Setting

    DIDO Setting Right-click a channel and choose ‘DIDO..’ context in the menu. DI / Enable: ON/OFF for DI DI / Type: Rise Edge / Fall Edge for trigger mode. DI / Server Action: Define what action will be done if DI triggered. DO / Type: Normal open / Close open for action mode.

  • Page 76: Camera Information

    Camera Information Right-click a channel and choose ‘Camera Info..’ context in the menu. You can see some camera information in this popup window. - Page 76 -...

  • Page 77: Preset Setting

    Preset Setting Right-click a channel and choose ‘Preset..’ context in the menu. There are 16 presets for users to do the presets. Click the drop list the preset and start the Preset Navigation adjustment (view angle and the focus adjust), the Preset Name can be also added in at this moment.

  • Page 78: Cruise Setting

    Cruise Setting Right-click a channel and choose ‘Cruise..’ context in the menu. The way to define the cruise will count on a process which start with the cruise set (A, B, C, D and E) The Duration here defines the pause time between 2 presets for users to watch/monitor the Preset more clearly.

  • Page 79: Trigger Do

    Trigger DO Right-click a channel and choose ‘Trigger DO..’ context in the menu. You can trigger DO device by clicking the menu text. - Page 79 -...

  • Page 80: Open Record Files

    Open record files Click Menu->File->Open… You can filter records by camera, record type, and date. Just press ‘View’ button to play the selected record. - Page 80 -...

  • Page 81: Using Camera With A Router

    Using Camera with a Router If users connect their own surveillance camera and / or PC to a router to access Internet, the router automatically assign IP address to each device. Those IP addresses assigned by the router are under private IP address range (depicted in the following figure).
  • Page 82 Install Surveillance Camera Manually Configure Internet Access Surveillance Camera with Subscription Fixed IP(arranged by users) IP address assigned by PPPoE / Fixed IP Router(DHCP) Direct Internet Inside NAT Router Connection Assign Surveillance Turn on SIP & STUN Camera with Fixed IP / option(private IP address) PPPoE(public IP...
  • Page 83 Note : For SIP Phone / SIP Server / SIP port / STUN Server / STUN Port parameter settings, you can contact VoIP service provider and subscribe a account to use. Please contact ipcamfae@leadtek.com.tw for further detail. II. SIP and STUN Option in Surveillance Camera: SIP Option: Log on to surveillance web page.
  • Page 84 Note : For SIP Phone / SIP Server / SIP port / STUN Server / STUN Port / Stun Enable HB parameter settings, you can contact VoIP service provider and subscribe a account to use. Please contact ipcamfae@leadtek.com.tw for further detail. The following snapshot is just an example setting for demo purpose only.
  • Page 85 Note : The example snapshot is just an example. You shall input the setting of your PPPoE account given by your ISP. Without Internet Access(arranged by users): If you have no Internet access link, they can manually configure their networking device and make sure each device IP address is unique and is of a same subnet.
  • Page 86 - Page 86 -...

  • Page 87: Firmware Upgrade

    Firmware Upgrade Surveillance camera firmware can be upgraded via Microsoft Internet Explorer. Prepare the firmware file and follow the procedure as the following: 1) Login on to web, and click System Others page. 2) Ensure Ramdisk radio button is selected. Click Browse button to choose the firmware file and then click Upgrade button to kick start firmware upgrade procedure.

  • Page 88: Frequently Asked Questions

    4) The surveillance camera rolls back its configuration to factory default when this procedure is done. Note: Depends on firmware version to be upgraded, surveillance camera may reboot itself with factory default or maintain its original setting. Note: Check the NSC3615 LED to ensure the surveillance camera reboot itself properly.
  • Page 89 The following figure is an example. Justify your network access point(User PC A /B/C) NSC3615 ( IP: 59.120.205.60 NAT Router ( Global IP : 211.72.242.91 ( Private IP : 192.168.0.1 ) Internet NSC3615 ( IP: 220.128.22.97 User PC B 1 NAT : ( IP: 192.168.0.3 User PC A(public)
  • Page 90 If you have direct Internet access(e.g. IP address 61.128.30.57) without an firewall or NAT router installed, you possibly can directly link to Leadtek IPCAM live demo site(IP address : 220.128.220.97, etc on the figure above) and get a real-time live view.
  • Page 91 - Page 91 -...

  • Page 92: Sip Configuration

    SIP Configuration Category : SMC / Configuration / General Question: How to verify SIP connection mode for A/V transmission in NSC3615(Peer-to-peer or SIP proxy) ? How do I configure SIP connection mode on SMC? Answer: SMC supports 2 mode of SIP connection, i.e. peer-to-peer or via SIP proxy.

  • Page 93: Motion Detection

    Motion Detection Category : SMC / Operation / General Question: How do I configure the Motion Detection of IPCAM ? Answer: Configure motion detection from “Advanced Setting” ”Motion Detection” ”Area 1” Use the mouse to make the selection of motion detection block and apply the “Enable”...
  • Page 94 The rest of the setting determines what actions will be taken by SMC(snapshot, record) or IPCam device(send snapshot by email or FTP, trigger DO) when motion alarm triggered. - Page 94 -...
  • Page 95 Four parameters (Sensitivity / Object Size / Frame Interval / Alarm Duration) need to configured before turning on the motion detection function. Sensitivity: This parameter determines the sensitivity of embedded motion detector algorithm. The higher the value, the more sensible to the motion object change.

  • Page 96: Video Quality Setting

    Object Size: This parameter determines the pixel change percentage of motion interest area. If more pixels(vs configured value) are justified and declared as changed by embedded motion detector algorithm, motion is reported by the device. Frame Interval: The frame interval check the number of required video frames in a row to confirm the motion condition.
  • Page 97 Answer: The following configurable parameters have dominant effects on user video quality feeling: Video Resolution Video Mode Bit Rate Frame Rate Quality Those parameters are closely linked and there is a tradeoff between setting of each parameters. For example, there is no guaranteed setting to satisfy user (Bit Rate, Frame Rate, Quality) setting under desired video resolution.
  • Page 98 Windows client. 2) Video Mode Leadtek surveillance camera supports 2 video mode for rate control, i.e. Variable Bit Rate (VBR) and Constant Bit Rate(CBR). The VBR setting honors the frame rate and quality setting and thus pump out as much as bitstream to satisfy those 2 parameter setting(frame rate , quality).
  • Page 99 Configuration Setting: Video Resolution / Video Mode / Bit Rate / Frame Rate / Video Quality Scene without moving object CIF / VBR / 256 k / 30fps / 4 Running bitrate 214 k/ 28 fps CIF / VBR / 256 k / 30fps / 31 Running bit rate 138k / 28 fps The blocked image will be observed on the image.
  • Page 100 Scene with moving object CIF / CBR / 256 k / 30fps / 4 Running bit rate 284k / 8fps The actual running frame rate is lower than 30 fps due to the constraint of available network bandwidth. CIF / CBR / 256 k / 30fps / 31 - Page 100 -...
  • Page 101 Running bit rate 260 k / 16 fps The video quality is lower and thus the network bandwidth requirement is less. The side effect of this is the poor video quality (mosaic effect on moving object) CIF / VBR / 256 k / 30fps / 4 Running bit rate 926 k / 28 fps The VBR setting ensures a better video quality and thus over bandwidth traffic is the result.
  • Page 102 QCIF / CBR / 256 K / 30fps / 4 Running bit rate 231 k / 23 fps The viewable region is less than CIF and network usage is also less. QCIF / CBR / 256 K / 30fps / 31 Running bit rate 54 k / 28 fps - Page 102 -...
  • Page 103 QCIF / VBR / 256 K / 30fps / 4 Running bit rate 50 k / 28 fps The actual network bandwidth usage is less due to QCIF resolution. QCIF / VBR / 256 K / 30fps / 31 Running bit rate 59 k / 28 fps - Page 103 -...

  • Page 104: Bandwidth Usage

    The poor video quality setting make the text a little fuzzy. Bandwidth Usage Category : IPCAM / Connection / General Question: What’s the network bandwidth requirement of each IPCAM connection? How can I estimate or configure the video parameters to get a better video quality and performance ? Answer: If you have an ADSL network connection to surf the internet, please...
  • Page 105 For example, your ADSL network bandwidth is 512K/1M. The surveillance camera is installed in your home. That means your upstream bandwidth is 512kbps for your surveillance camera. Ensure your surveillance camera video mode is CBR so that you can better estimate the network usage.

  • Page 106: Dynamic Domain Name Service

    Dynamic Domain Name Service Category : IPCAM / Configuration / General Question: How can I find out IPCAM IP address if I my IPCAM connect to Internet via PPPoE mode? Answer: Please subscribe an account from www.dyndns.org and use the DDNS client service in NSC3615 .
  • Page 107 - Page 107 -...

  • Page 108: Factory Default Setting

    Factory Default Setting Category : / IPCAM / Installation / NSC3615 Question: What's the factory default setting of NSC3615? How can I reset NSC3615 to factory default ? Answer: NSC3615 Factory Defaut Setting: Fixed IP mode : IP address : 192.168.0.100 Subnet mask : 255.255.255.0 Default admin account : Username : admin...

  • Page 109: Version Information

    Push the button underneath(marked “Restore Default”) the pinhole at the bottom of NSC3615 case. Version Information Category : IPCAM / Installation / General Question: How can I find out NSC3615 firmware version information and ethernet MAC address? Answer: 1) log on to web server 2) Refer to left-hand side of main webpage as shown belows - Page 109 -...

  • Page 110: Activex Control Download

    Video Decoder Plug-in ActiveX Control Download Category : IPCAM / Operation / General Question: How do I know the video NSC3615 video decoder is not installed in my local PC ? Answer: - Page 110 -...
  • Page 111 If the local PC does not install SMC software or video decoder is not installed in the PC, the IE will pop up the message and ask user to download the ActiveX control for the very first time. ActiveX Control Download Indication : A) When a red cross appeared at the top-left hand corner of the ActiveX viewer(IE), what can I do? Make sure your local PC specification meets the bottom line...

  • Page 112: Remove Old Activex Controls

    iii) Go to the Start Menu, Run dxdiag, click on the Display tab, make sure DirectX is enabled(DirectX9). Remove Old ActiveX Controls Category : IPCAM / Operation / General Question: How do I uninstall the old video decoder of NSC3615 ? 1.
  • Page 113 3. Click “View Objects…” button. Select the item “CSIPCtrlObject” and press “delete” key. - Page 113 -...
  • Page 114 Restart IE and Login to web again, then you will be asked to install a new ActiveX. Answer “Yes” to download ActiveX control again. - Page 114 -...
  • Page 115 iii. Check your webpage setting and clarify the SIP connection mode(peer-to-peer or proxy mode). - Page 115 -...

  • Page 116: Bandwidth Configuration

    Bandwidth Configuration Category : IPCAM / Connection / General Question: What’s the network bandwidth usage in IPCAM? How do I configure IPCAM bandwidth setting properly? Answer: You can control the network bandwidth of each connection by web page. Please refer to webpage “Camera” and set the “Bitrate” option. This option will place an upper limit on video codec rate control.

  • Page 117: Sip Connection Mode

    SIP Connection Mode Category : IPCAM / Configuration / General Question: How do I configure NSC3615 SIP connection mode on web? Answer: 1) peer-to-peer Ensure the SIP configuration : SIP Register is OFF ( Select OFF and Press “Save”) 2) SIP Proxy Mode - Page 117 -...

  • Page 118: Codec Select

    Ensure the “SIP Register” option is “ON” and also check SIP Server IP address, SIP port configuration are proper. Codec Select Category : IPCAM / Configuration / General Question: Can I select audio / video codec used in NSC3615? How to do it? Answer: NSC3615 supports multiple audio / video codec type.
