Keyboard Split Tones

The preset tones numbered 90 through
96 on your keyboard let you automati-
cally play two different musical instru-
ments or sound effects independently
on opposite sides of the keyboard.
The instrument listed first in the tone's
name plays on the left half of the key-
board (below middle C). The instrument
listed next plays on the right half of the
keyboard (above middle C). For exam-
ple, BS/PNO (No. 90) plays a bass tone
on the left half of the keyboard and a pi-
ano tone on the right.

Layered Tones

The preset tones numbered 80 through
89 on your keyboard let you automati-
cally play two different layered tones at
the same time when you press one key.
For example, STR PNO (No. 80) plays
string and piano tones when you press a
key.

Percussion Sounds

PERCUSSION (No. 99) lets you play the
35 different percussion sounds shown
here. The symbol for each sound ap-
pears above the corresponding key on
the keyboard.
Bass Drum
Side Stick
Acoustic Snare
Hand Clap
16
Note: When you select the Fingered or
Concert Chord mode, the keys in the
lower 1
niment keys and do not produce percus-
sion
Accompaniment" on Page 18.
Cowbell
Crash Cymbal 2
Claves
Ride Cymbal 2
Electric Snare
Low Floor Tom
Closed Hi-Hat Mute High Conga
High Floor Tom Open High Conga
Pedal Hi-Hat
Low Tom High Timbale
Open Hi-Hat Low Timbale
Low-Mid Tom
High-Mid Tom
Crash Cymbal 1
High Tom
Ride Cymbal 1
Chinese Cymbal
Ride Bell Voice Closed
Tambourine
Splash Cymbal
/ octaves become the accompa-
1
2
sounds. See "Using
High Bongo
Low Bongo
Low Conga
High Agogo
Low Agogo
Cabasa
Maracas
Voice Bass
Drum
Voice Snare
Hi-Hat
Voice Open
Hi-Hat
Auto
