MOTU PCIe
424
User's Guide for Windows
1280 Massachusetts Avenue
Cambridge, MA 02138
Business voice: (617) 576-2760
Business fax: (617) 576-3609
Technical support: (617) 576-3066
Tech support fax: (617) 354-3068
Tech support email: techsupport@motu.com
Web site: www.motu.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the PCIe- 424 and is the answer not in the manual?

Questions and answers

Summary of Contents for MOTU PCIe- 424

  • Page 1 MOTU PCIe ™ User’s Guide for Windows 1280 Massachusetts Avenue Cambridge, MA 02138 Business voice: (617) 576-2760 Business fax: (617) 576-3609 Technical support: (617) 576-3066 Tech support fax: (617) 354-3068 Tech support email: techsupport@motu.com Web site: www.motu.com...
  • Page 2 7. Power Sources - This MOTU interface should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your location, consult your local power company.
  • Page 3: Table Of Contents

    Contents Quick Reference: PCIe-424 Audio Card About the PCIe-424 System Packing List and PC System Requirements Installing the PCIe-424 Hardware Expanding Your PCIe-424 System...
  • Page 4 (b) rent, lease or grant sublicenses or other rights to the program; (c) permission of MOTU, or if the product serial number has been removed or defaced. provide use of the program in a computer service business, network, time-sharing,...
  • Page 5: Quick Reference: Pcie-424 Audio Card

    Quick Reference: PCIe-424 Audio Card Connect the first (core Connect additional MOTU system) interface to PCI audio interfaces here. the PCIe-424 card here You can connect up to using the Audio Wire four I/Os to a PCIe-424 cable included with card for a maximum of 96 your core system.
  • Page 6: About The Pcie-424 System

    Audio Wire cable, Up to four MOTU PCI audio interfaces can be connected to expandable to 96 inputs/outputs. A core system consists of a a single PCIe-424 card for a maximum of 96 possible input PCI card connected to a standard 19-inch, single-space, and output connections.
  • Page 7 transfer a single track of material from the ADAT via light Analog bank The analog inputs are equipped with 24-bit, 96 kHz 64x pipe into the 2408mk3’s Macintosh workstation software, oversampling A/D converters. The analog outputs have and then transfer the track back to the ADAT, it will be 24-bit, 96 kHz 128x oversampling D/A converters.
  • Page 8 input to receive SMPTE time code. Any active channel, Level Meters The front panel of the 24I/O displays 48 level meters, digital or analog, can be chosen as a SMPTE time code arranged in three banks of 8 channels. For each channel, output.
  • Page 9 32-bit floating point processing, crossfades, support for many third-party audio plug-ins (in the MOTU Audio System plug-in format), background processing of file-based operations, sample-accurate editing and placement of audio, and more.
  • Page 10: Packing List And Pc System Requirements

    Thank you for taking the time to register your new MOTU products! P A C K I N G L I S T A N D P C S Y S T E M R E Q U I R E M E N T S...
  • Page 11: Installing The Pcie-424 Hardware

    Installing the PCIe-424 Hardware CHAPTER OVERVIEW Install the PCIe-424 software first! ....11 Install the PCIe-424 audio card ..... . 11 Connect the audio interface .
  • Page 12 CONNECT THE AUDIO INTERFACE 1 Plug one end of the Audio Wire cable (included) into the Audio Wire socket next to the 9-Pin ADAT Sync connector on the PCIe-424 card as shown below in Figure 3-1. 2 Plug the other end of the Audio Wire cable into the audio interface as shown below in Figure 3-1.
  • Page 13: Expanding Your Pcie-424 System

    Core system interface (#1) details. Figure 4-1: You can connect up to four MOTU PCI audio interfaces to a single PCIe-424 card. Connecting expansion interfaces ....13 MULTIPLE INTERFACES IN THE CONSOLE Multiple interfaces in the Console.
  • Page 14 SYNCHRONIZING MULTIPLE INTERFACES The entire PCIe-424 system gets its clock from whatever you choose from the Clock Source menu in the MOTU PCI Audio Console window. Synchronization across all connected interfaces is sample-accurate. All available sync sources on all connected interfaces are displayed in the menu as demonstrated below in Figure 4-4.
