35mm High Speed Aspherical Lens
INSTRUCTION MANUAL
VIV-35MM-N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 35MM-N and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivitar 35MM-N

  • Page 1 35mm High Speed Aspherical Lens INSTRUCTION MANUAL VIV-35MM-N...
  • Page 2: Limited Five Year Warranty

    Vivitar warrants this quality product to be free of defects in material and workmanship for a period of five years from the date of pu rchase. During the period, Vivitar will repair or replace the product at no charge for parts or labor.
  • Page 3: Technical Support

    When service is complete, the product will be returned to you shipping prepaid. In the event the product is deemed to be not faulty or the defect is a result in wear and tear, Vivitar may levy a handling charge for the from country and State to State thereof.
  • Page 4 Introduction Thank you for purchasing the VIV-35MM-N High Speed Aspherical Lens. This lens will provide you with many unique and exciting photo taking opportunities which we hope you will enjoy. Features of Your Lens: -A floating design that will provide you with sharp images for both long shots and close up shots -A single glass aspherical lens which can give you crisp looking shots even at periphery angles.
  • Page 5 A Quick Look at Your Device 1. Lens Ring Mount (camera locking area) 2. Aperture Value Scale 3. Distance Scale 4. Focus Scaling Ring 5. Focusing Ring 6. Hood Locking Tube 7. Hood 8. Depth of Field Scale 9. Aperture Adjustment Ring 10.
  • Page 6 Your VIV-35MM-N lens is uniquely designed for Nikon digital SLR cameras. Attaching Your Lens to Your Camera Hold the hood of the lens gently, and align the depth of field scale of the lens with the lens attachment reference point on of the camera. Next, push the lens into the camera and turn the lens carefully until it makes a clicking sound, and the depth of field scale is positioned on the upper part of the camera.
  • Page 7: Focus Adjustment

    Focus Adjustment You can adjust the focus of the subject you are photographing by turning the focus adjustment ring on your lens, as it is an MF (manual focus) adjustment lens. To do so, please follow the steps below: 1. When focusing on a subject from a long distance, turn the focus ring to the right (1 to ∞) and focus on the clearest subject by using the indication signal on the camera or by checking visually.
  • Page 8: Brightness Control

    Brightness Control In A mode (Aperture Priority Mode): Turn the sub command dial at the front of the camera to adjust the brightness. In S mode (Shutter Speed Priority Mode): Turn the main command dial at the back of the camera. The shutter speed is changed and the brightness is adjusted according to the changed shutter speed.
  • Page 9: Camera Settings

    Camera Settings Some cameras require special settings when using this lens. Please read the information below and set your camera accordingly. The aperture of this 35mm High Speed Aspherical Lens supports a maximum brightness of F1.4. If you take a photo outdoors where there is a great deal of sunlight, you may not get a clear image as the subject you are photographing may be too bright.
  • Page 10 Camera Settings (continued) Your lens mount has electronic contacts that allow it to communicate with Nikon AF cameras. These contacts enable A, S, and P modes of the camera and when a subject is focused correctly the camera emits a beep or an indicator light comes on.
  • Page 11: Mounting The Hood

    Mounting the Hood The hood has a bayonet system, which guarantees speedy, efficient, safe and precise installation and will help you take shots that are free of flaring and ghosting. Allign the attachment reference point on the hood with the reference point on the lens.
  • Page 12: Troubleshooting

    Troubleshooting -11-...
  • Page 13 Troubleshooting (continued) -12-...
  • Page 14 Caution -13-...
  • Page 15 Caution -14-...
  • Page 16 ®...
