Summary of Contents for Vivitar 13MM-P
- Page 1 13mm Ultra Wide Aspherical Lens INSTRUCTION MANUAL VIV-13MM-P...
-
Page 2: Limited One Year Warranty
Vivitar warrants this quality product to be free of defects in material and workmanship for a period of one year from the date of purchase. During the period, Vivitar will repair or replace the product at no charge for parts or labor. -
Page 3: Technical Support
When service is complete, the product will be returned to you shipping prepaid. In the event the product is deemed to be not faulty or the defect is a result in wear and tear, Vivitar may levy a handling charge for the from country and State to State thereof. - Page 4 Introduction Thank you for purchasing the VIV-13MM-P Ultra Wide Aspherical Lens. This lens will provide you with many unique and exciting photo taking opportunities which we hope you will enjoy. Features of Your Lens: -Super Spectra coatings -113.8º diagonal angle...
- Page 5 A Quick Look at Your Device 1. Depth of Field Scale 4. Hood Locking Area 2. Focus Scaling Ring 5. Mount 3. Focusing Ring 6. Aperture Adjustment Ring...
- Page 6 Your VIV-13MM-P lens is uniquely designed for Pentax cameras. Attaching Your Lens to Your Camera Hold the hood locking area of the lens gently, and align the lens mounting reference point or line with the lens ring mount of the camera. Next, push the lens into the camera and turn the lens softly until it makes a clicking sound, and the depth of field scale is positioned on the upper part of the camera.
-
Page 7: Focus Adjustment
Focus Adjustment You can adjust the focus of the subject you are photographing by turning the focus adjustment ring on your lens, as it is an MF (manual focus) adjustment lens. To do so, please follow the steps below: 1. When focusing on a subject from a long distance, turn the focus ring to the right (∞... -
Page 8: Brightness Control
Brightness Control You can set the amount of brightness you want by turning the aperture adjustment ring when using your lens. [Aperture adjustment ring markings] When you turn the aperture adjustment ring between 22, 16, 11, 8, 5.6, 4, 2.8, 2 and 1.4 you are making 1 stop each turn. -
Page 9: Camera Settings
Camera Settings Some cameras require special settings when using this lens. Please read the information below and set your camera accordingly. Av mode: the mounts on your lens supports Av mode. 1) Allign the A mode indicator to the depth of field scale by pressing the A button on the aperture adjustment ring of the lens. - Page 10 Camera Settings (continued) 3. Set the focus adjustment 4. Set the menu on the camera. lever of the camera to MF 5. Adjust the brightness by turning the dial at the back of the camera. (The camera settings discussed apply to the Pentax K20D camera. Settings for the camera or the menu may be changed depending on the model or due to a menu upgrade.
-
Page 11: Specifications
Specifications Filter size: None F/stop range: F2.8 ~ 22 Maxium diameter: 87.0mm Angle of View: 115.7 ˚ (APS-C: 93.9 ˚) Group/Elements: 10/14 Length: 3.72" (94.6mm) Weight: 18.69 oz (530g) -10-... -
Page 12: Troubleshooting
Troubleshooting -11-... - Page 13 Troubleshooting (continued) -12-...
- Page 14 Caution -13-...
- Page 15 Caution -14-...
- Page 16 ®...
