True TUC-27F-D-2 Specifications

Field's End Road, Goldthorpe, Nr. Rotherham, South Yorkshire S63 9EU,
United Kingdom • www.truemfg.com • Tel 01709 888 080 • Fax 01709 880 838
• Free Phone 0 800 783 2049 • Free Phone to U.S. 0 800 894 928
Model:
TUC-27F-D-2
Rough-In Data
Model
TUC-27F-D-2
3/11
TRUE EUROPE
Undercounter:
Drawered Freezer
Chart dimensions rounded up to the next whole millimeter
Cabinet Dimensions
(mm)
Drawers L D
2 702 766
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
H HP Voltage
839 1/3 230-240/50/1
ApprovAls:
Qty:
TUC-27F-D-2

True's undercounter units are
designed with enduring quality
that protects your long term
investment.

Designed using the highest
quality materials and components
to provide the user with colder
product temperatures, lower
utility costs, exceptional food
safety and the best value in
today's food service marketplace.

Oversized, environmentally
friendly (R404A) forced-air
refrigeration system holds -10°F
(-23.3°C). Ideally suited for both
frozen foods and ice cream.

All stainless steel front, top
and ends. Matching aluminum
finished back.

Front breathing.

Each drawer accommodates one
(1) full size 12"L x 20"W x 6"D (305
mm x 508 mm x 153 mm) food
pan (sold separately).

Automatic defrost system time-
initiated, time-terminated.

Foamed-in-place using Ecomate.
A high density, polyurethane
insulation that has zero ozone
depletion potential (ODP) and
zero global warming potential
(GWP).
Specifications subject to change without notice.
(inches rounded up to the next 1/8"
Cord
NEMA Length
Amps Config. (total m)
▲
3.3 2.13
▲Plug type varies by country.
AvAilAble At:
AIA #
SIS #
).
Crated
Weight
(kg)
98
