User's Technical Manual of Leadtek GPS EVK
User's Technical Manual of
Leadtek GPS EVK
Page 1 of 20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Leadtek EVK

  • Page 1 User’s Technical Manual of Leadtek GPS EVK User’s Technical Manual of Leadtek GPS EVK © 2010 Leadtek Research Inc. All rights reserved. Preliminary Confidential - Information is subject to change without prior notice. Page 1 of 20...
  • Page 2: Table Of Contents

    Module: LR9101 (example) ....................6 LR9101F1 (G)PCB REV:03....................6 LR9500 EVK Board ......................6 7.2. 2: S ....................7 TART TO CONNECT OPERATION OF G-MONITOR SOFTWARE WITH GPS EVK..........8 8.1....................... 8 ORMAL OPERATION 8.2..............10 OT START TIME MEASUREMENTS DOWNLOAD THE FIRMWARE TO GPS MODULE .............
  • Page 3: Introduction

    Leadtek GPS LR9500 is an evaluation kit designed to demonstrate the performance of Leadtek GPS modules. It supports all Leadtek GPS modules. GPS LR9500 EVK not only helps customers to evaluate our GPS modules performance but also can be used to update new firmware for the GPS modules.
  • Page 4: Mechanical Dimensions

    User’s Technical Manual of Leadtek GPS EVK 4. Mechanical dimensions 5. Outline and Descriptions Connector (CN1) Connector (J2) USB Output Port Boot select Reset button © 2010 Leadtek Research Inc. All rights reserved. Preliminary Confidential - Information is subject to change without prior notice.
  • Page 5: Functional Description

    User’s Technical Manual of Leadtek GPS EVK 6. Functional Description Functional kit Description Power ON by USB connector for GPS 9500 EVK. To Power ON inset USB port of PC will turn on power. Interface Connect with F1 board. Power & Status LED Two colors by LED, which show power and data transmitting status.
  • Page 6: The Operation Of Evk

    User’s Technical Manual of Leadtek GPS EVK 7. The operation of EVK This chapter will show you how to operate an EVK, let’s take LR9101 for example. 7.1. Step 1: Check devices Module: LR9101 (example) LR9101F1 (G)PCB REV:03 LR9500 EVK Board ©...
  • Page 7: Step 2: Start To Connect

    User’s Technical Manual of Leadtek GPS EVK 7.2. Step 2: Start to connect Then connect the LR9101F1 board to LR9500 EVK board © 2010 Leadtek Research Inc. All rights reserved. Preliminary Confidential - Information is subject to change without prior notice.
  • Page 8: Operation Of G-Monitor Software With Gps Evk

    User’s Technical Manual of Leadtek GPS EVK 8. Operation of G-Monitor software with GPS EVK 8.1. Normal operation In GPS monitor main screen, click data source setup button indicated in the figure below. <Note>Go to view menu to choose desirable information windows you like to observe.
  • Page 9 User’s Technical Manual of Leadtek GPS EVK Next, please choose Com Port and Baud Rate correctly. Next, please click on Auto detect protocol and baud rate button. The GPS software will go on detecting protocol for GPS module. © 2010 Leadtek Research Inc. All rights reserved.
  • Page 10: Cold/Warm/Hot Start Time Measurements

    User’s Technical Manual of Leadtek GPS EVK 8.2. Cold/Warm/Hot start time measurements You can use the GPS EVK device and GPS Monitor software to measure hot, warm and cold start time of the GPS module. Please click on Initialize Data Source button.
  • Page 11 User’s Technical Manual of Leadtek GPS EVK This example shows how to measure hot start time. Please choose Hot Start item and click on OK button. Finally, please wait a moment and you will get time of hot start. The hot start time will show on the left side below.
  • Page 12: Warm Start

    User’s Technical Manual of Leadtek GPS EVK Please repeat above the steps and you will get time of warm and cold start. <Warm Start> © 2010 Leadtek Research Inc. All rights reserved. Preliminary Confidential - Information is subject to change without prior notice.
  • Page 13: Cold Start

    User’s Technical Manual of Leadtek GPS EVK <Cold Start> © 2010 Leadtek Research Inc. All rights reserved. Preliminary Confidential - Information is subject to change without prior notice. Page 13 of 20...
  • Page 14: Download The Firmware To Gps Module

    User’s Technical Manual of Leadtek GPS EVK Download the firmware to GPS module <Step 1>Double click the GMonitor desktop icon to run software in order to download firmware. The Main screen is shown as follows. <Step 2> Choose the Setup GPS Flash Star II/III option from of main menu.
  • Page 15 User’s Technical Manual of Leadtek GPS EVK <Note> If the module is type of single chip (ex. 9805ST), please install GMonitor2.102. The file path is in the E:\GPSMonitor\GM2.102.exe. (If E:\ is your CD-ROM) © 2010 Leadtek Research Inc. All rights reserved.
  • Page 16 1. To use Software Download method, uncheck “Force Download” box and follow the reset of the download operations. For some Leadtek products that do not have boot select and reset switches, software download is the only way to upgrade firmware.
  • Page 17: Install The Usb Driver

    Insert the software CD in your CD-ROM drive. The Autorun program (LEADTEK.exe) will display a setup screen as the figure to the right. Note: You can also start the setup program by running LEADTEK.exe in the main directory of the CD. © 2010 Leadtek Research Inc. All rights reserved.
  • Page 18 User’s Technical Manual of Leadtek GPS EVK Step 2. Please click on the USB Driver button for installation. You will see the following picture on your screen. Click one of the items you want to operate. Step 3. You can begin installing the USB driver by click on the Install button. Then you can also see the following picture on your screen.
  • Page 19 User’s Technical Manual of Leadtek GPS EVK Step 5. Perform a reboot of PC and then insert the USB serial cable. GMonitor should now be able to detect a new serial port for the USB serial cable. © 2010 Leadtek Research Inc. All rights reserved.
  • Page 20: Appendix A Gps Evk Schematic

    User’s Technical Manual of Leadtek GPS EVK Appendix A GPS EVK schematic © 2010 Leadtek Research Inc. All rights reserved. Preliminary Confidential - Information is subject to change without prior notice. Page 20 of 20...
