- Page 1 Tensioning Winder 30 User’s Guide For Océ CS9050, CS9060 & CS9160 Eco Solvent Printers...
- Page 2 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer This page is left blank intentionally AP-40104 - Revision 1.1 – 12/03/2008...
-
Page 3: Copyright Notice
This document may not be reproduced by any means, in whole or in part, without written permission of the copyright owner. This document is furnished for the installation of the Tensioning Winder 30 on a OCÉ CS9060 & CS9160 Eco Solvent Printer. - Page 4 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer This page is left blank intentionally AP-40104 - Revision 1.1 – 12/03/2008...
-
Page 5: Table Of Contents
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer Table of contents Safety instructions .....................7 Product overview......................9 Part names and functions..................9 2.1.1 Front side ......................9 2.1.2 Rear side ......................10 2.1.2.1 CS9050() ....................10 2.1.2.2 CS9060 and CS9160 () ................10 In-the-box contents CS9050 ................11... - Page 6 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer This page is left blank intentionally AP-40104 - Revision 1.1 – 12/03/2008...
-
Page 7: Safety Instructions
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 1 SAFETY INSTRUCTIONS Important BE SURE TO READ THE TERMS IN THE NEXT CHAPTER THOROUGHLY BEFORE INSTALLING AND OPERATING THE SYSTEM FOR YOUR OWN SAFETY. All safety related terms are bundled and categorized in three types. - Page 8 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer This page is intentionally left blank AP-40104 - Revision 1.1 – 12/03/2008...
-
Page 9: Product Overview
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 2 PRODUCT OVERVIEW 2.1 PART NAMES AND FUNCTIONS 2.1.1 Front side Name Function Operation panel Enable or disable the winding system Power switch To switch ON and OFF the T Winder 30... -
Page 10: Rear Side
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 2.1.2 Rear side 2.1.2.1 CS9050(*) Name Function Scroller Supports the movable flanges Flange There is one movable and one fixed flange to position the media correctly Scroller receiver Movable flange 2.1.2.2... -
Page 11: In-The-Box Contents Cs9050
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 2.2 IN-THE-BOX CONTENTS CS9050 Part Description Quantity Front tensioning system a Driving mechanism b Left bracket c Winder Kit d Scroller assembly (2-3” compatible) and core e Tensioning bar Please refer to the next page for the contents of the winder kit AP-40104 - Revision 1.1 –... -
Page 12: Winder Kit Cs9050
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 2.2.1 Winder kit CS9050 Part Description Quantity PET adjusting strip Hexagon key 3 mm Hexagon key 4 mm Spacer Adjustment plate Screw M4x10 Screw M5x12 Power cable (EU and UK) -
Page 13: In-The-Box Contents Cs9060 And Cs9160
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 2.3 IN-THE-BOX CONTENTS CS9060 AND CS9160 Part Description Quantity Front tensioning system a Driving mechanism and right bracket b Left bracket c Tensioning bar d Scroller assembly... -
Page 14: Winder Kit Cs9060 And Cs9160
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 2.3.1 Winder kit CS9060 and CS9160 Part Description Quantity PET adjusting strip Hexagon key 3 mm Hexagon key 4 mm Spacer Adjustment plate Screw M4x10 Screw M5x12 Power cable (EU and UK) AP-40104 - Revision 1.1 –... -
Page 15: Installation Procedure
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 3 INSTALLATION PROCEDURE 3.1 INSTALLING THE FRONT TENSIONING SYSTEM Step 1 : Loosen the four screws fixing the right bracket with the driving mechanism. Step 2 : Mount the right bracket (1) to the right leg (2) of the stand using 2 “M5x12”... - Page 16 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer Step 3 : On the CS9060 and CS9160, install the driving mechanism (1) in the right bracket (2) and tighten the four screws (3). On the CS9050, install the driving mechanism (1) onto the support bracket (2) and tighten the four screws (3) AP-40104 - Revision 1.1 –...
- Page 17 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer Step 4 : On the CS9060 and CS9160, Mount the left bracket (1) to the left leg (2) of the stand using 4 “M4x10” screws (3). Notes Note that there are 8 holes in the left bracket.
- Page 18 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer On the CS9050, the left bracket consists out of two parts. • First attach the closing bracket (1) to the stand (2). • When fixing the support bracket (3) to the closing bracket, make sure the support bracket is slided against the feet of the stand.
- Page 19 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer Step 5 : Insert the tensioning bar (1) in the positioning pen in the left bracket (2). Step 6 : Fix the tensioning bar (1) to the drive mechanism (2) using 2 “M4x10” screws (3).
- Page 20 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer Step 7 : Install the scroller bar between the left bracket and driving mechanism. Step 8 : The installation is completed. Step 9 : Refer to the next chapter to calibrate the tensioning bar and scroller assembly.
-
Page 21: Calibration Procedure
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 4 CALIBRATION PROCEDURE As well as the swingbar as the scroller assembly should be adjusted after installation. 4.1 TENSIONING BAR Tools needed • Synthetic paper strip •... - Page 22 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer Step 5 : Place the adjustment plate at the front of the printer against the pressure rollers. Step 6 : Draw a line on the strip. Step 7 : Move the strip to the right side.
-
Page 23: Adjustment
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 4.1.2 Adjustment Depending on the result of the calibration (as described in the previous chapter), the tensioning bar should be adjusted until it is positioned horizontally to obtain an equal tension left and right. -
Page 24: Scroller Bar
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 4.2 SCROLLER BAR Tools needed • Synthetic paper strip • Adjustment plate • Hexagon key 3 mm • Tape (not included in winder kit) • Pencil (not included in winder kit) 4.2.1 Calibration... - Page 25 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer Step 5 : Draw a line on the strip. Step 6 : Move the strip to the right side. Step 7 : Draw a line for the second time. The following two situations can be obtained.
-
Page 26: Adjustment
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 4.2.2 Adjustment Depending on the result of the calibration (as described in the previous chapter), the scroller bar should be adjusted until it is positioned horizontally to obtain a straight winding flow. -
Page 27: Operating The System
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 5 OPERATING THE SYSTEM 5.1 SWITCHING THE POWER ON/OFF Step 1 : Push the button at the back of the driving mechanism (position “I”) to power ON. -
Page 28: Activate The Winding System
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 5.3 ACTIVATE THE WINDING SYSTEM Step 1 : Power ON the driving mechanism at the back. Step 2 : Enable the winding system with the switch on top of the driving mechanism. -
Page 29: Loading Roll Media
User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer 5.5 LOADING ROLL MEDIA Step 1 : Power ON the printer. Step 2 : Power ON the winding system (at the back). Step 3 : Be sure that the winding switch is set “OFF”. - Page 30 User’s Guide Tensioning winder 30 for Océ CS9050, CS9060 & CS9160 Eco-Solvent Printer Step 10 : Set the winding system to “FREE” and manually turn the scroller to roll up some media. Step 11 : Pull down the tensioning bar (2) and set the winding system back to “SET” (1).
