Weed Eater WE EL-15TNE Parts List

Parts List No.
966048001
Date
NEW
02/26/10

WARNING

All repairs, adjustments and
maintenance not described in
the Operator's Manual must be
performed by Qualified Service
Personnel.
Ref. Part No.
1.
574495901 Bolt Carriage,
2. Assist Handle
574495601
3. Knob
574473101
Clamp
574495801
4.
574491601
5.
Edge Guide
Spool with 0.065" Trimmer line
952711920
6.
Shield Assembly
574495401
7.
Spool Cap
8. 574492201
= New Part Number For This IPL
WEED EATER
NOTE : Illustration may differ from actual model due to design changes.
Description
M6 X 1
R
2
3
4
7
8
Ref. Part No.
115254226
= Refer to the Service Reference Indicated for more information.(Located at the END of the IPL)

PARTS LIST

1
6
Description
Not Shown
Manual
MODEL
WE EL-15TNE
Page: 1
5
