HTM18IBP – Hotpoint
®
Front View
B
A
Specification Revised 6/07
410328
'94 TMNF Refer
18.0 Cu. Ft. Top-Freezer Refrigerator
C
D
Top View
H
G
E
F
Note: Before installing, consult installation instructions packed with
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
Width (in.) G
Width with door open 90° with door handle (in.) H
Each side (in.)
Top (in.)
Back (in.)
product for current dimensional data.
Total volume and shelf
area are calculated by
Listed by
the Association of Home
Underwriters
Appliance Manufacturers'
Laboratories
standards.
66-5/8
66-1/8
27-1/2
30-1/4
32-1/8
58-1/8
29-1/2
32
1/8
1
1
