IMPORTANT MANUAL
OWNER'S MANUAL

MODEL NUMBER:

P14530ES
SNOW THROWER
Always Wear Eye Protection During Operation
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
580 92 59-27 Rev. 1
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P14530ES and is the answer not in the manual?

Questions and answers

Related Manuals for Poulan Pro P14530ES

Summary of Contents for Poulan Pro P14530ES

  • Page 1: Model Number

    IMPORTANT MANUAL Do Not Throw Away OWNER'S MANUAL MODEL NUMBER: WARNING: P14530ES Read the Owner's Manual and fol low all Warnings and Safety In struc tions. Fail ure to do so SNOW THROWER can result in serious injury. Always Wear Eye Protection During Operation Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.

  • Page 2: Safety Rules

    IMPORTANT Safe Operation Practices for Walk-Behind Snow Throwers This snow thrower is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury. WARNING: Snow throwers have ex- Look for this symbol to point out im- posed rotating parts, which can cause por tant safety precautions.

  • Page 3: Table Of Contents

    6. When cleaning, repairing or inspecting the snow thrower, 16. Never touch a hot engine or muffler. stop the engine and make certain the collector/impel- ler and all moving parts have stopped. Disconnect Clearing a Clogged Discharge Chute the spark plug wire and keep the wire away from the Hand contact with the rotating impeller inside the discharge plug to prevent someone from accidentally starting the chute is the most common cause of injury associated with...

  • Page 4: Assembly / Pre-Operation

    PARTS PACKED SEPARATELY IN CARTON (1) MULTI- WRENCH (180684) (1) RETAINER SPRING (2) FLAT WASHERS (169675) (1) POWER CORD (198563) (1) DISCHARGE CHUTE ROTATOR HEAD MOUNTING (2) CARRIAGE BOLTS 3/8-16 x 2.25 SAFTEY IGNITION KEY(S) (443059) (1) WASHER 3/8 (1) LOCKNUT 3/8 (19131316) (73800600) (2) HANDLE KNOBS...
  • Page 5 ASSEMBLY / PRE-OPERATION NOTE: The multi-wrench may be used for assembly of the INSTALL TRACTION DRIVE CONTROL ROD chute rotator head to snow thrower and making ad just ments (See Figs. 3 and 4) to the skid plates. The traction drive control rod is installed on the snow thrower. UNFOLD UPPER HANDLE 1.
  • Page 6 ASSEMBLY / PRE-OPERATION INSTALL DISCHARGE CHUTE / CHUTE ROTATOR INSTALL AUGER CONTROL ROD (See Figs. 5 and 6) HEAD (See Fig. 7) The auger control rod is installed on the snow thrower. NOTE: The multi-wrench provided in your parts bag may 1.

  • Page 7: Operation

    OPERATION KNOW YOUR SNOW THROWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR SNOW THROWER. Compare the illustrations with your snow thrower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your snow thrower or in literature supplied with the product.
  • Page 8 OPERATION DISCHARGE CHUTE MUF FLER ELECTRIC CONTROL LEVER AUGER DRIVE START TRACTION CONTROL SPEED BUTTON DRIVE LEVER CON TROL GAS O LINE CONTROL FILLER CAP LEVER POWER LEVER CORD PLUG CHOKE CHUTE CON- DE FLEC TOR TROL SAFETY IGNITION ON / OFF SWITCH PRIM ER DISCHARGE...
  • Page 9 OPERATION The operation of any snow thrower can result TO CONTROL SNOW DISCHARGE (See Figs. 11 & 12) in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear WARNING: Snow throwers have ex- safety glasses or eye shields while operating posed rotating parts, which can cause your snow thrower or performing any ad just- severe injury from contact, or from ma-...

  • Page 10: Using The Clean-Out Tool

    OPERATION TO THROW SNOW (See Fig. 13) TO MOVE FORWARD AND BACKWARD (See Fig. 15) The auger rotation is controlled by the auger control lever SELF-PROPELLING, forward and reverse movement of located on the right side handle. the snow thrower, is controlled by the traction drive control lever located on the left side handle.

  • Page 11: Before Starting The Engine

    OPERATION NOTE: It is not recommended to operate the snow thrower over gravel or rocky surfaces. Objects such as gravel, rocks CAUTION: Alcohol blended fuels (called gas o- or other debris, can easily be picked up and thrown by the hol or using ethanol or methanol) can attract impeller, which can cause serious personal injury, property moisture which leads to separation and for ma-...

  • Page 12: Snow Throwing Tips

    OPERATION COLD START - ELECTRIC STARTER IF RECOIL STARTER HAS FROZEN 1. Insert safety ignition key (tied to recoil start cord) into If the recoil starter has frozen and will not turn the engine, ignition slot until it clicks. DO NOT turn the key. Keep proceed as follows: the extra safety ignition key in a safe place.

  • Page 13: Maintenance Schedule

    MAINTENANCE GENERAL REC OM MEN DA TIONS LUBRICATION CHART The warranty on this snow thrower does not cover items that have been sub ject ed to operator abuse or negligence. SAE 5W-30 Motor Oil To receive full value from the warranty, operator must maintain snow thrower as in struct ed in this manual.

  • Page 14: To Change Engine Oil

    MAINTENANCE AUGER GEAR CASE 1. Remove safety ignition key and disconnect spark plug • The gear case was filled with lubricant to the proper wire from spark plug. Place wire where it cannot come level at the factory. The only time the lubricant needs in contact with spark plug.

  • Page 15: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: To avoid serious injury, before performing any service or ad just ments: 1. Be sure the on/off switch is in the OFF position. 2. Remove safety ignition key. 3. Make sure the augers and all mov ing parts have completely stopped. 4.

  • Page 16: To Replace Belts

    SERVICE AND ADJUSTMENTS TO REPLACE BELTS (See Fig. 20) 8. RELIEVE TENSION ON TRACTION DRIVE BELT IDLER and remove traction drive belt from around The auger and traction drive belts are not adjustable. If pulleys. the belts are damaged or begin to slip from wear, they should be replaced.
  • Page 17 SERVICE AND ADJUSTMENTS TO REMOVE WHEELS (See Fig. 21) ENGINE • Remove the wheel pin and retainer pin and remove SEE ENGINE MANUAL. wheel from axle. IMPORTANT: When installing wheel, be sure to use the in- CARBURETOR ner most hole in axle and the wheel hub hole. To disengage Your carburetor is not adjustable.

  • Page 18: Storage

    STORAGE Immediately prepare your unit for storage at the end of the • Empty the fuel tank by starting the engine and letting it run until the fuel lines and car bu re tor are empty. season or if the unit will not be used for 30 days or more. •...

  • Page 19: Troubleshooting

    TROUBLESHOOTING See appropriate section in manual unless directed to an authorized service center/department. PROBLEM CAUSE CORRECTION Does not start 1. Fuel shut-off valve (if so 1. Turn fuel shut-off valve to OPEN position. equipped) in OFF position. 2. Safety ignition key 2.

  • Page 20: Repair Parts

    SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY 2 (EXPLODED) 01.07.026-F NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty.
  • Page 21 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 18 41-05 IMPELLER 42 71-48 GEARBOX ASSEMBLY 18 89-09 BEARING 42 71-46 IMPELLER PULLEY 44 24-38 DISCHARGE BASE 18 40-95 CORNER BRACKET 19 21-99 CLEAN OUT TOOL...
  • Page 22 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 532 41 52-91 AUGER HOUSING 532 40 76-45 SCRAPPER BAR 872 27 05-05 CARRIAGE BOLT 5/16−18 X .625 532 15 53-77 NUT 5/16−18 3 (5x) 4 (5x) 01.07.003-A...
  • Page 23 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY PART DESCRIPTION 532 42 04-78 AUGER BEARING 532 41 19-39 BEARING PLUG 01.07.024-B 532 17 95-82 SCREW 5/16−18 X 1.00 PART DESCRIPTION 532 43 59-51 PLATE SKID PLASTIC HDPE...
  • Page 24 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE PART DESCRIPTION 532 44 36-24 CHUTE WELDMENT 532 18 45-11 DEFLECTOR WELDMENT 532 42 03-25 DEFLECTOR SEAL 532 18 41-14 STRAP 532 19 19-38 KNOB BLACK 532 12 84-15...
  • Page 25 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE 01.09.010-C PART DESCRIPTION 532 42 82-72 LEVER/CABLE ROTATOR ASSEMBLY 817 54 10-08 SCREW 10-24 X .625 532 42 06-78 ROTATOR HEAD 532 40 59-32 ROTATOR PIVOT BRACKET...
  • Page 26 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS HANDLES PART DESCRIPTION 532 42 10-69 PLOW HANDLE LH 532 42 10-70 PLOW HANDLE RH 532 42 91-48 PANEL BRACKET LH 532 42 91-49 PANEL BRACKET RH 532 19 95-13 HANDLE GRIP 874 78 05-12 SCREW 5/16−18 X .750...
  • Page 27 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS HANDLES PART DESCRIPTION 584 80 87-01 IMPELLER ROD ASSEMBLY 584 80 88-01 TRACTION ROD ASSEMBLY 532 18 04-45 SHIFTER ROD TOP 532 18 77-16 SHIFTER ROD BOTTOM 532 18 04-47 SPRING SLEEVE...
  • Page 28 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS HANDLES 01.08.021-A PART DESCRIPTION 585 19 88-02 CONTROL PANEL 581 77 98-01 LH CONTROL LEVER 581 77 97-01 RH CONTROL LEVER 584 80 90-01 INTERLOCK CONTROL ROD 585 00 47-01 INTERLOCK BRACKET 874 78 04-10 1/4-20 X .625 HEX HEAD SCREW...
  • Page 29 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS HANDLES PART DESCRIPTION 532 41 62-88 INTERLOCK SPRING 532 44 52-91 INTERLOCK CAM 532 44 32-15 TORSION SPRING 532 16 96-75 RETAINER 817 06 04-10 SCREW 1/4−20 X .625 532 42 18-14 INTERLOCK STOP 01.08.007-D...
  • Page 30 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS DRIVE ITEM 42 EXPLODED 14 15 01.02.013-F NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty.
  • Page 31 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS DRIVE PART PART DESCRIPTION DESCRIPTION 532 19 88-75 SPEED SELECTOR ASSEMBLY 532 17 53-44 BEARING 817 54 10-08 THRED ROLLING SCREW 532 17 86-13 WHEEL HUB 10-24 X .500 874 76 05-14 SCREW 5/16-18-.875...
  • Page 32 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS DRIVE 01.03.005-C PART DESCRIPTION 532 18 82-26 AXLE ASSEMBLY (assy of 1a,1b) 532 17 93-52 AXLE SHAFT 532 18 42-06 ROLL PIN 3/16 532 40 26-91 SPROCKET 532 44 49-49 THRUST WASHER...

  • Page 33: Chassis/Engine/Pulleys

    SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS CHASSIS / ENGINE / PULLEYS PART DESCRIPTION 580 42 61-01 LCT COMPLETE ENGINE PW2HK19850781DE 532 42 92-75 FRAME 01.00.034-A 532 15 04-06 BOLT 3/8-16 532 42 88-67 SCREW 5/16-18 X .750 PART...
  • Page 34 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS CHASSIS / ENGINE / PULLEYS 01.21.020-H PART PART DESCRIPTION DESCRIPTION 532 43 07-84 IMPELLER BELT 532 85 10-84 SCREW 3/8-24 X 1.375 532 42 73-04 TRACTION BELT 532 05 92-89 WASHER 584 23 24-02...

  • Page 35: Wheels

    SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS WHEELS PART DESCRIPTION 532 44 87-14 WHEEL ASSEMBLY LH 532 44 87-15 WHEEL ASSEMBLY RH 01.06.016-A NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.

  • Page 36: Bag Of Parts

    SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS BAG OF PARTS PART DESCRIPTION 532 19 85-63 POWER CORD 532 16 96-75 RETAINER PIN 532 42 91-12 WRENCH 873 80 06-00 LOCKNUT 3/8−16 819 13 13-16 WASHER 3/8 532 19 20-90 SHEAR BOLT 1/4−20 X 1−3/4...
  • Page 37 SNOW THROWER - MODEL P14530ES (96198004502) REPAIR PARTS DECALS PART DESCRIPTION 532 18 10-37 DECAL, DANGER 532 18 10-33 DECAL, CONSOLE INSTRUCTION E/F 532 18 10-35 DECAL, DANGER, DEFLECTOR 532 18 10-42 DECAL, DANGER 581 43 01-01 DECAL, CONSOLE RT SPEED LEVER...
  • Page 38 SERVICE NOTES...
  • Page 39 SERVICE NOTES...

  • Page 40: Limited Warranty

    LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
