REVELL '69 Camaro Yenko/SC Assembly Manual

Catching both the automotive industry and the American motor-
ing public by surprise, Ford released the new Mustang in April, 1964
to unprecedented success. Its smaller, two door profile along with
its long hood/short rear deck design made a lasting impression on
everyone who saw it.
Stunned by the sales numbers the Mustang was racking up, it
took until 1967 for General Motors to bring its competitors to market.
Chevrolet unveiled the new '67 Camaro
®
the available options was the "SS"
350 cubic inch engine. In a classic example of corporate competi-
tion, Ford offered its 390 engine in the Mustang for '67 which of
course spurred Chevy to release its 396 big block V8 as a mid-year
®
Camaro option.
The 396 Camaros burned up the drag strips across the coun-
try, but fans also knew that Chevy had an even larger 427 cubic
inch V8 in its arsenal. When initial requests for the factory to install
the 427 into the Camaro were turned down, enterprising Chevrolet
dealers started ordering the engines by themselves and swapped
the big motors in. Don Yenko was one such dealer. Owning a large
* REPEAT SEVERAL TIMES * OPTIONAL PARTS
* A REPETER PLUSIEURS FOIS * PIECES EN OPTION
READ THIS BEFORE YOU BEGIN
* Study the assembly drawings.
* Each plastic part is identified by a number.
* In the assembly drawings, some parts will be
marked by a star (★) to indicate chrome
plated plastic.
* For better paint and decal adhesion, wash
the plastic parts in a mild detergent solution.
Rinse and let air dry.
* Check the fit of each piece before
cementing in place.
* Use only cement for polystyrene plastic.
* Scrape plating and paint from areas
to be cemented.
* Allow paint to dry thoroughly before
handling parts.
* Any unused parts may be discarded.
DECAL APPLICATION INSTRUCTIONS
1. Cut desired decal from sheet.
2. Dip decal in water for a few seconds.
3. Place wet decal on paper towel.
4. Wait until decal is movable on paper backing.
5. Place decal in position on model, face up and
slide backing away.
6. Press out air bubbles with a soft damp cloth.
7. Milkiness that may appear is for better decal
adhesion and will dry clear. Wipe away any
excess adhesive.
8. Do not touch decal until fully dry.
9. Allow the decals 48 hours to dry before
applying clear coat.
NOTE: Decals are compatible with
setting solutions or solvents.
If you have any questions or comments, call our hotline at:
Revell-Monogram Consumer Service Department, 725 Landwehr Road, Northbrook, Illinois 60062
Be sure to include the plan number (85282600200), part number, description, your return address and phone number.
KIT2826
'69 Camaro
in the fall of 1966. Among
®
™ package that included the new
* DECAL * ALTERNATIVE ASSEMBLY
* DECAL COMANIE * ENSEMBLAGE ALTERNATIVE
LIRE CE QUI SUIT AVANT DE COMMENCER
* Etudier les schémas de montage.
* Chaque pièce en plastique est identifiée par un numéro.
* Sur les schémas de montage, certaines pièces sont
marquées d'une étoile (★) pour indiquer qu'elles sont en
plastique chromé.
* Pour une meilleure prise de la peinture et des autocollants,
laver les pièces en plastique avec une solution détergente
peu concentrée. Les rincer et les laisser sécher à l'air.
* Vérifier que chaque pièce s'ajuste bien avant
de la coller en place.
* N'utiliser que de la colle pour polystyrène.
* Gratter les parties à coller pour enlever le chrome et la peinture.
* Laisser la peinture bien sécher avant de manipuler les pièces.
* Toute pièce inutilisée peut être jetée.
DIRECTIVES D'APPLICATION DES AUTOCOLLANTS
1. Découper l'autocollant désiré de la feuille.
2. Tremper l'autocollant dans de l'eau pendant quelques secondes.
3. Placer l'autocollant mouillé sur une serviette en papier.
4. Attendez que l'autocollant puisse être déplacé sur son support
en papier.
5. Mettre l'autocollant en position sur le modèle face sur
le dessus et faire glisser le support pour l'enlever.
6. Appuyer avec un chiffon doux humide pour éliminer les bulles d'air.
7. La substance laiteuse qui peut apparaître est destinée à
améliorer l'adhésion de l'autocollant et devient incolore au
séchage. Essuyer pour enlever tout excédent d'adhésif.
8. Ne pas toucher l'autocollant tant qu'il n'est pas bien sec.
9. Laisser l'autocollant sécher pendant 48 heures avant
d'appliquer une couche transparente.
REMARQUE: Les autocollants sont compatibles avec
les solutions de fixage ou les solvants.
or, please write to:
Visit our website: www.revell-monogram.com
REVELL-MONOGRAM, LLC Northbrook, IL. Copyright © 2003. All rights reserved.
Yenko/SC
®
Chevy dealership in Pennsylvania, Yenko used his connections
within the GM management to convince Chevy in 1969 to write what
was known as a "COPO" order, which stood for Corporate Office
Production Order. These were used for special combinations of
options that were not generally available.
Don Yenko grabbed up 201 of the special 427 powered '69
Camaros for his dealership. All of the Yenko cars came equipped
with the 450 horsepower version of the iron block 427, high-rise
intake with Holley 4 barrel carb, power disc brakes, the ZL2 cowl
induction hood, positraction rear end with 4.10 gear and the custom-
er's choice of a 4 speed manual transmission or GM's M40 Turbo-
Hydramatic automatic transmission which in this case came with
Hurst's dual-gate linkage. Yenko's staff added the horizontal body
stripes and headrest graphics after the cars arrived at his dealership.
Today, original Yenkos are among the most sought after Camaros
ever built
* CEMENT TOGETHER
* A COLLER
This optional paint guide is provided if
you choose to detail paint your model.
Ce guide de peinture vous sera fourni si vous choisissez
(800) 833-3570
427 Coupe
* REMOVE AND THROW AWAY
* A RETIRER ET JETER
de peindre votre modèle en détail.
Aluminium
Aluminum
Gloss Black
Noir brilliant
Gloss Red
Rouge brilliant
Gloss Yellow
Jaune brilliant
Semigloss Black
Noir satiné
Silver
Argent
Steel
Acier
Turn Signal Amber
Clignotant ambre
White
Blanc
85282600200
* DO NOT CEMENT
* NE PAS COLLER
