REVELL '67 Chevelle SS 396 Assembly Manual

Since its introduction in 1964, the Chevrolet
has been one of the all-time favorite American muscle cars.
Designed to fill a niche between the compact Chevy
the ever-growing full size line, the Chevelle offered most of the
larger powertrain options from the Impala
lighter body. Handsome body styling also helped many families
make the decision to "drive it off the lot".
1967 was a transitional carry-over year for the Chevelle as
many of Chevrolet's engineers had spent the previous couple
years working on the just introduced '67 Camaro
had several engines to chose from including the 230 and 250
cubic inch 6 cylinder as well as the 283 and 327 cubic inch V8s.
Aware that the Camaro might steal some sales away from the
Chevelle, additional hardware was added the option list, espe-
cially for the hot SS 396.
™
The Super Sport
™
version of the big block 396 cubic inch V8 engine included as
* REPEAT SEVERAL TIMES * OPTIONAL PARTS
* A REPETER PLUSIEURS FOIS * PIECES EN OPTION
READ THIS BEFORE YOU BEGIN
* Study the assembly drawings.
* Each plastic part is identified by a number.
* In the assembly drawings, some parts will be
marked by a star (★) to indicate chrome
plated plastic.
* For better paint and decal adhesion, wash
the plastic parts in a mild detergent solution.
Rinse and let air dry.
* Check the fit of each piece before
cementing in place.
* Use only cement for polystyrene plastic.
* Scrape plating and paint from areas
to be cemented.
* Allow paint to dry thoroughly before
handling parts.
* Any unused parts may be discarded.
DECAL APPLICATION INSTRUCTIONS
1. Cut desired decal from sheet.
2. Dip decal in water for a few seconds.
3. Place wet decal on paper towel.
4. Wait until decal is movable on paper backing.
5. Place decal in position on model, face up and
slide backing away.
6. Press out air bubbles with a soft damp cloth.
7. Milkiness that may appear is for better decal
adhesion and will dry clear. Wipe away any
excess adhesive.
8. Do not touch decal until fully dry.
9. Allow the decals 48 hours to dry before
applying clear coat.
NOTE: Decals are compatible with
setting solutions or solvents.
If you have any questions or comments, call our hotline at:
Revell-Monogram Consumer Service Department, 725 Landwher Road, Northbrook, Illinois 60062
Be sure to include the plan number (85218300200), part number, description, your return address and phone number.
KIT 2183
line but in a smaller,
™
. Base models
™
had the base level 325 horsepower
* DECAL
* DECAL COMANIE
LIRE CE QUI SUIT AVANT DE COMMENCER
* Etudier les schémas de montage.
* Chaque pièce en plastique est identifiée par un numéro.
* Sur les schémas de montage, certaines pièces sont
marquées d'une étoile (★) pour indiquer qu'elles sont en
plastique chromé.
* Pour une meilleure prise de la peinture et des autocollants,
laver les pièces en plastique avec une solution détergente
peu concentrée. Les rincer et les laisser sécher à l'air.
* Vérifier que chaque pièce s'ajuste bien avant
de la coller en place.
* N'utiliser que de la colle pour polystyrène.
* Gratter les parties à coller pour enlever le chrome et la peinture.
* Laisser la peinture bien sécher avant de manipuler les pièces.
* Toute pièce inutilisée peut être jetée.
DIRECTIVES D'APPLICATION DES AUTOCOLLANTS
1. Découper l'autocollant désiré de la feuille.
2. Tremper l'autocollant dans de l'eau pendant quelques secondes.
3. Placer l'autocollant mouillé sur une serviette en papier.
4. Attendez que l'autocollant puisse être déplacé sur son support
en papier.
5. Mettre l'autocollant en position sur le modèle face sur
le dessus et faire glisser le support pour l'enlever.
6. Appuyer avec un chiffon doux humide pour éliminer les bulles d'air.
7. La substance laiteuse qui peut apparaître est destinée à
améliorer l'adhésion de l'autocollant et devient incolore au
séchage. Essuyer pour enlever tout excédent d'adhésif.
8. Ne pas toucher l'autocollant tant qu'il n'est pas bien sec.
9. Laisser l'autocollant sécher pendant 48 heures avant
d'appliquer une couche transparente.
REMARQUE: Les autocollants sont compatibles avec
les solutions de fixage ou les solvants.
Visit our website: www.revellmonogram.com
REVELL-MONOGRAM, LLC Northbrook, IL. Copyright © 2004. All rights reserved. Made in China
'67 Chevelle
Chevelle standard equipment. A 350 horsepower version was available
® ™
but the 375 H.P. engine was deleted from the factory option list
II and for '67 although approximately 600 cars had the engine installed
®
at the dealership level. Among the items available for the first
time on the '67 models were power disc brakes, which also then
came with rally wheels; 14 inch wheels and the 3 speed Turbo
Hydra-Matic automatic transmission, which was only available
on the SS models.
As we salute the 40th anniversary of the Chevelle's intro-
duction, Revell is proud to re-issue our 1967 Chevelle SS 396
kit. This release also includes newly-tooled large diameter cus-
tom wheels, so very popular on the street right now, as well as a
lowered front suspension and disc brake detail. Whether you've
built it before or if you're just getting to it for the first time, we're
confident you'll enjoy building your own SS 396.
* ALTERNATIVE ASSEMBLY
* ENSEMBLAGE ALTERNATIVE
or, please write to:
SS
™
* CEMENT TOGETHER * REMOVE AND THROW AWAY
* A COLLER * A RETIRER ET JETER
This optional paint guide is provided if you
choose to detail paint your model.
Ce guide de peintures vous sera fourni si vous choisissez de
peindre votre modèle en détail.
Aluminum
Flat Black
Gloss Black
Gloss Orange
Metallic Black
Metallic Orange
Semigloss Black
Satin White
Silver
(800) 833-3570
85218300200
396
™
* DO NOT CEMENT
* NE PAS COLLER
Aluminium
Noir mat
Noir lustré
Orange lustré
Noir métallisé
Orange métallisé
Noir satiné
Blanc satiné
Argent
