REVELL KIT 1916 Assembly Manual

Step 13
Sticker Placement Guide
Step 16
NOTE:
When applying stickers, avoid touching the "sticky" side to prevent finger prints on stickers. Bend sticker sheet slightly to lift edge of sticker & use a fingernail to lift
sticker from sheet. Line up sticker on body and press an edge into place, slowly working sticker with a finger nail until sticker is fully on model.
REMARQUE :
Pendant l'application des autocollants, éviter de toucher à la face collante pour ne pas laisser d'empreintes. Plier légèrement la feuille d'autocollants pour relever le
bord d'un autocollant, et le détacher de la feuille avec le bout d'un ongle. Aligner l'autocollant sur la carrosserie, appuyer pour coller un de ses bords, et continuer de
l'appliquer lentement du bout de l'ongle jusqu'à ce qu'il soit complètement collé sur le modèle réduit.
Step 14
17
GAS CAP
CHROME
RIGHT REAR
BUMPER
CHROME
13
LEFT REAR
BUMPER
CHROME
Step 15
14
11
LEFT SIDE
MOLDING
CHROME
Parts Included
ANY UNUSED PARTS MAY BE DISCARDED
'63 Corvette ® Sting
KIT 1915
12
The 1963 Corvette is a true American classic that is widely
RIGHT SIDE
MOLDING
regarded as one of Chevrolet's best cars ever. 1963 was
CHROME
the first year the Corvette was called the Sting Ray, the first
year a fixed roof coupe was offered, and the first year for the
Corvette's signature hidden headlights. Corvette is synonymous
with sports car, and with its 327 V-8 and all-new independent
rear suspension, the '63 Sting Ray did not disappoint. The new
'63 model represented the most radical design and engineering
change in Corvette history, and the influence of its timelessly
beautiful styling can still be seen clearly in today's Corvette.
Your Revell Wheels of Fire kit features easy snap and screw
together assembly, detailed interior and
chassis, chrome plated parts, and
colorful optional road
racing numbers and
sponsor decals.
Enjoy building
your kit of this clas-
Corvette!
