REVELL KIT 1907 Assembly Manual

Step 13
SCREWS
COMPLETED

ASSEMBLY

Step 15

Sticker Placement Guide

5
NOTE:
When applying stickers, avoid touching the "sticky" side to prevent finger prints on stickers. Bend sticker sheet slightly to lift edge of sticker & use a finger-
nail to lift sticker from sheet. Line up sticker on body and press an edge into place, slowly working sticker with a finger nail until sticker is fully on model.
Step 14
7
BRUSH GUARD
CHASSIS
Completed
Assembly
ANY UNUSED PARTS MAY BE DISCARDED

Parts Included

20
TIRES
METAL AXLES
& SCREWS
KIT 1907
HUMMER
AM General's Hummer is one of most rugged and capable 4X4's ever
built. Development of the Hummer originally began in 1979, when the U.S.
Army needed a High Mobility Multi-Purpose Wheeled Vehicle (HMMWV, or
"Humvee" for short). The Hummer quickly proved itself as a highly versatile,
effective military vehicle, and became so popular that AM General introduced
a civilian version of the Hummer in 1992. The Hummer remains in widespread
use in the U.S. Army and commercial industries, and is a very popular "status"
vehicle among the general public.
The Hummer's main body is made of a strong, heat-treated aluminum alloy,
held together with more than 2,800 rivets for unmatched durability. It features
a 4-wheel, fully independent suspension system with heavy-duty springs
and hydraulic shock absorbers, plus a Central Tire Inflation System (CTIS)
that enables the driver to inflate or deflate the Hummer's tires right from the
driver's seat for better traction. With its low center of gravity, 72 inch track
width, and a full 16 inches of ground clear-
ance, the Hummer can tackle almost any
road terrain, and with a snorkel kit,
it is capable of fording 60 inches
of water.
Your Revell Snaptite model
kit features easy snap and
screw together assembly, accu-
rate body with separate brush
guard, free rolling wheels on metal
and colorful customizing stickers. Enjoy
* REMOVE AND THROW AWAY
* A RETIRER ET JETER
* REPEAT SEVERAL TIMES
* A REPETER PLUSIEURS FOIS
READ BEFORE YOU BEGIN
• CLEAR A SPACE TO WORK ON
• STUDY THE ASSEMBLY DRAWINGS BEFORE YOU BEGIN
• EACH PLASTIC PART IS IDENTIFIED BY A PART NUMBER
• DO NOT OVER TIGHTEN SCREWS
• SEE NOTE ABOUT APPLYING STICKERS IN STEP #15
CAUTION:
BODY
POSITION ALL PARTS IN THIS KIT CAREFULLY. PARTS
WILL ONLY SNAP TOGETHER ONCE.
If you have any questions or comments, call our hotline at:
or, please write to:
Revell-Monogram Consumer Service Department, 725 Landwehr Road,
Northbrook, Illinois 60062
Be sure to include the plan number (85190710200), part number, description,
your return address and phone number.
Visit our website: www.revell-monogram.com
REVELL-MONOGRAM LLC Northbrook, IL. Copyright © 2003. All rights reserved.
85190710200
