Model No. PETL51305.2
USER'S MANUAL
Serial No.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.

Advertisement

Table of Contents
loading

Related Manuals for ProForm 570 V Treadmill

Summary of Contents for ProForm 570 V Treadmill

  • Page 1 Model No. PETL51305.2 USER’S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call: 08457 089 009 Or write: ICON Health &...

  • Page 2: Table Of Contents

    ORDERING REPLACEMENT PARTS ..........Back Cover Note: An EXPLODED DRAWING is attached in the centre of this manual. PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure conductor, 1mm (14-gauge) cord that is no that all users of this treadmill are adequately longer than 1.5 m (5 ft.).
  • Page 4 21. When using iFIT.com programs, an elec- 24. Inspect and properly tighten all parts of the tronic “chirping” sound will alert you when treadmill regularly. the speed and/or incline of the treadmill is about to change. Always listen for the 25.

  • Page 5: Before You Begin

    ® the telephone number on the front cover of this man- 570 V treadmill. The 570 V treadmill offers an impres- ual. To help us assist you, please note the product sive array of features to help you achieve your fitness model number and serial number before calling.

  • Page 6: Assembly

    Console Bolt (76)–4 Latch Screw (46)–2 Internal Star Washer (77)–4 ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 7 2. With the help of a second person, carefully tip the Uprights (97) down as shown. (Note: It may be helpful to place one foot against one of the Extension Legs [115] as you tip the Uprights.) Make sure that the Extension Legs remain in the Uprights.
  • Page 8 5. See drawing 5c. With the help of a second person, hold the Console Base (101) near the Uprights (97). Look under the Console Base and locate the wires on the sides of the Console Base. Make sure that the wires are not routed through the openings for the Trays (111, 112).

  • Page 9: How To Use The Chest Pulse Sensor

    HOW TO USE THE CHEST PULSE SENSOR HOW TO PUT ON THE CHEST PULSE SENSOR • Store the chest pulse sensor in a warm, dry place. Do not store the chest pulse sensor in a plastic bag The chest pulse sensor consists of two components: or other container that may trap moisture.

  • Page 10: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE ™ WALKING BELT , a high-performance lubricant. IMPOR- Your treadmill features a walking belt coated with PERFORMANT LUBE ™ TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear.
  • Page 11 CONSOLE DIAGRAM Note: If there is a sheet of clear plastic Clip on the face of the console, remove it. FEATURES OF THE CONSOLE sonal trainer in your home. Using a stereo audio cable, you can connect the treadmill to your portable stereo, The treadmill console offers an impressive array of home stereo, computer, or VCR and play special features designed to make your workouts more effec-...
  • Page 12 HOW TO TURN ON THE POWER mph. As you exercise, change the speed of the Note: To prevent damage to the walking platform, walking belt as desired wear clean shoes while using the treadmill. by pressing the Speed + and – buttons. Each Plug in the power cord (see time a button is pressed, page 10).
  • Page 13 The left side of the dis- the handrail. play will show the incline Next, stand on the foot rails level of the treadmill, the elapsed time, and the and hold the distance that you have metal contacts— walked or run. Note: avoid moving Contacts your hands.
  • Page 14 tings for the next four segments will be shown in HOW TO USE A SPEED & INCLINE PROGRAM the columns to the right. Insert the key into the console. When only three seconds remain in the first seg- ment of the program, both the Current Segment column and the column to the right will flash and a See HOW TO TURN ON THE POWER on page series of tones will sound.
  • Page 15 Follow your progress with the display. HOW TO USE A SPEED PROGRAM See step 5 on page 12. Insert the key into the console. Measure your heart rate if desired. See HOW TO TURN ON THE POWER on page See step 6 on page 13. Select one of the speed programs.
  • Page 16 Enter a target heart rate setting. HOW TO USE A PULSE CONTROL PROGRAM If pulse control pro- Pulse control program 1 will automatically adjust the gram 1 is selected, the speed and incline of the treadmill to keep your heart rate target heart rate setting near a target heart rate setting that you select.
  • Page 17 When only three seconds remain in the first seg- If your pulse is not detected during the program, ment, both the Current Segment column and the the letters “PLS” will flash in the display and the column to the right will flash and a series of tones speed and/or incline of the treadmill may automat- will sound.
  • Page 18 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO USE IFIT.COM PROGRAMS Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 3.5 mm LINE OUT jack, see instruction B. If your To use iFIT.com MP3 or CD programs, the treadmill stereo has only a PHONES jack, see instruction C.
  • Page 19 HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, A. Plug one end of a long 3.5 mm to 3.5 mm stereo see instruction A below. If the LINE OUT jack is audio cable (available at electronics stores) into the being used, see instruction B.
  • Page 20 HOW TO CONNECT YOUR VCR HOW TO USE AN IFIT.COM MP3, CD, OR VIDEO PROGRAM Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV To use an iFIT.com MP3, CD, or video program, the with a built-in VCR, see instruction B.
  • Page 21 • Make sure that the audio cable is properly If the speed or incline settings are too high or too low, you can manually override the settings at any connected. time by pressing the Speed or Incline buttons on • If you are using a portable CD player and the the console.
  • Page 22 THE INFORMATION MODE/DEMO MODE that the treadmill has been operated. An “E” for English miles or an “M” for metric kilometers will appear in the The information mode keeps track of the total number right side of the display. Press the Speed + button to of hours that the treadmill has been operated and the change the unit of measurement if desired.
  • Page 23 Return to the treadmill and stand on the foot HOW TO USE AN IFIT.COM PROGRAM rails. Find the clip attached to the key and slide DIRECTLY FROM OUR WEB SITE the clip onto the waistband of your clothes. When the on-screen countdown ends, the program Our Web site at www.iFIT.com allows you to access will begin and the walking belt will begin to move.

  • Page 24: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill.
  • Page 25 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.

  • Page 26: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call the telephone number on the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 27 With the help of a second person, carefully raise the Uprights (97) as shown. Carefully pivot the Hood (54) off. Locate the Reed Switch (22) and the Magnet (19) on the left side of the Pulley (18). Turn the Pulley until the 3 mm Magnet is aligned with the Reed Switch.
  • Page 28 PROBLEM: The chest pulse sensor does not function properly SOLUTION: a. If the chest pulse sensor does not function properly, see CHEST PULSE SENSOR TROUBLE- SHOOTING on page 9. b. If the chest pulse sensor still does not function properly, the battery should be changed.

  • Page 29: Conditioning Guidelines

    CONDITIONING GUIDELINES is to burn fat, adjust the speed and incline of the tread- WARNING: mill until your heart rate is near the lowest number in Before beginning this your training zone. or any exercise program, consult your physi- cian. This is especially important for individu- For maximum fat burning, adjust the speed and incline als over the age of 35 or individuals with pre- of the treadmill until your heart rate is near the middle...

  • Page 30: Part List

    PART LIST—Model No. PETL51305.2 R0106A To locate the parts listed below, see the EXPLODED DRAWING attached in the centre of this manual. Key No. Qty. Description Key No. Qty. Description Left Foot Rail Circuit Breaker Foot Rail Screw Receptical Pulse Receiver Screw Belly Pan Clip Isolator Decal Belly Pan...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Console Base, Top Roller Ground Wire Optic Disk Lift Frame Ground Wire Console Back 5/32” Hex Key Key Clip Hood Screw/Endcap Screw Left Handrail Console Fan Rear Roller Star Washer Console 4” Black Wire, F/F Screw 18”...
  • Page 34 To help us assist you, please be prepared to give the following information: • the MODEL NUMBER of the product (PETL51305.2) • the NAME of the product (PROFORM 570 V treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
