KIT 1163
CHEVY
* APPLY STICKERS
*APPLIQUEZ LES AUTO-COLLANTS
READ BEFORE YOU BEGIN
• CLEAR A SPACE TO WORK ON
• STUDY THE ASSEMBLY DRAWINGS
BEFORE YOU BEGIN
• EACH PLASTIC PART IS IDENTIFIED BY
A PART NUMBER
• SEE NOTE ABOUT APPLYING
STICKERS IN STEP #9
CAUTION:
POSITION ALL PARTS IN THIS KIT
CAREFULLY. PARTS WILL ONLY SNAP
TOGETHER ONCE.
If you have any questions or comments, call our hotline at:
or, please write to:
Revell-Monogram Consumer Service Department, 725 Landwehr Road, Northbrook, Illinois 60062
Be sure to include the plan number (85116300200), part number, description, your return address and phone number.
Visit our website: www.revellmonogram.com
REVELL-MONOGRAM, LLC Northbrook, IL. Copyright © 2005. All rights reserved.
CAMARO
Z/28
85116300200
®
®
* REPEAT SEVERAL TIMES
*A REPETER PLUSIEURS FOIS
Á LIRE AVANT DE COMMENCER
• DÉGAGGEZ UN ESPACE POUR TRA-
VAILLER.
• ÉTUDIEZ LES ÉTAPES DE MONTAGE
AVANT DE COMMENCER.
• CHAQUE PIÉCE EN PLASTIQUE PORTE
UN NUMÉRO DE PIÉCE.
• LISEZ LA RE MARQUE CONCERNANT
L´APPLICATION DES AUTO-COLLANTS,
´A L´ ÉTAPE 9.
MISE EN GARDE:
POSITIONNEZ AVEC PRÉCAUTION
TOUTES LES PIÉCES DE CE MODÉLE
RÉDUIT, CAR VOUS NE POUVEZLES
EMBOîTER QU'UNE SEULE FOIS.
(800) 833-3570
Step 1
™
1
BODY
Step 2
DASHBOARD
6
SEAT
Step 3
11
WINDSHIELD
4
10
STEERINg WHEEL
INTERIOR TUB
Step 4
5
WHEEL
12
HEADLIgHTS
(REMOVE AND USE
IN STEP #7)
6
SEAT
3
7
TIRE
