REVELL Proto CX Assembly Manual

3.7V 110mAh
LiPo Helicopter
Battery
Spare Upper and Lower
Four "AA" Alkaline
Batteries
Do not touch the spinning blades or fl y over another person's head. Adult supervision is required.

Safety Precautions:

Warning: Do not modify or alter this unit. Changes or modifi cations to this unit not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
• Do not turn on the Proto CX helicopter unless the
controller has been turned on fi rst.
• Keep hands, hair and loose clothing away from the
spinning blades.
• Turn off the controller and Proto CX when not in use.
• Remove the battery from the controller when not in use.
• Parental guidance is recommended while fl ying.
• Always keep your Proto CX in sight while fl ying.
Care and Maintenance:
• Always remove the batteries from the controller when it is not
being used for a long period of time.
• Wipe the toy gently with a clean, damp cloth.
• Keep the toy away from direct heat.
• Do not submerge the toy into water. This could damage the
electronic assemblies.
Adult supervision is required.
This device complies with Part 15 of the FCC rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Battery Cautions:
• Non-rechargeable batteries are not to be recharged.
• If the controller uses rechargeable batteries, remove them
before recharging.
• Rechargeable batteries should be recharged only by an adult.
• Do not power the controller by mixing different types of
batteries, or old and new batteries.
• Use only batteries of the same or equivalent type as those
recommended.
• Install batteries following the correct polarity.
• Remove exhausted batteries from the controller.
• Do not short-circuit the supply terminals.
WARNING:
CHOKING HAZARD —
Small parts.
Not for children under 3 years of age.
Contents
Proto CX EP
Rotor Blades
Screwdriver
• For the best performance, use new alkaline batteries
in the controller.
• Replace the batteries in the controller with new ones
as soon as any function becomes diminished.
• Keep these instructions for future reference.
• Follow the operating instructions exactly.
• Your controller's built-in charger is made specifi cally
for the rechargeable Proto CX LiPo battery. Do not
use it to charge any other battery.
The Proto CX is equipped with a rechargeable LiPo battery. Please
pay attention to the following cautions for safe use:
• Do not dispose of the battery into fi re or heat.
• Do not use or leave the battery near a heat source, such as fi re or
a heater.
• Do not strike the battery or throw it against a hard surface.
• Do not immerse the battery into water. Keep the battery cool and dry.
• When recharging the battery, use only the charger designed for that
purpose.
• NEVER leave the battery unattended while charging.
• Do not over-discharge the battery.
• Do not connect the battery to an electrical outlet.
• Do not directly solder the battery or pierce it with a nail or other
sharp object.
• Do not transport or store the battery together with metal objects such
as necklaces, hairpins, etc.
• Do not disassemble or alter the battery.
• Charge the battery every six months.
• Turn off your equipment power switch after use.
• Recycle used batteries after covering the battery terminals with
insulation tape or inserting the battery into an individual polybag.
Note:
• Parental guidance is recommended when installing or replacing
batteries.
• Static electricity may cause the toy to malfunction, requiring you to
turn it off and back on before fl ying again.
"This product is in compliance with the
essential requirements and other relevant
provisions of Directive 1999/5/EC."
™
2.4GHz Transmitter
• Counter-rotating rotor blades for ultimate stability
• Full, four-channel control
• Interference-free 2.4GHz operation
• Interchangeable Mode 1 or Mode 2 confi guration
• Built-in LiPo battery charger
• Computer display screen
in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on. The user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Hobbico
Main Features
FCC REQUIREMENT
NOTE: This equipment has been tested and found to comply with the limits
for Class B digital device, pursuant to part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
Note Specifi cally for Adults:
• Regularly examine all parts of the toy for damage. If any is found,
do not use the toy again until the damage has been repaired.
• This toy is not intended for children under 8 years old.
• This toy must be used only with the recommended charger.
• Do not try to charge other batteries with the controller's charger.
Battery Requirement for Proto CX:
Requires: 3.7V LiPo Rechargeable Battery Pack (included and
installed)
Battery Requirements for Controller:
Requires: 4 x 1.5V "AA" size batteries (included)
CAUTION: Changes or modifi cations to this product not expressly
approved by the party responsible for compliance may void the user's
authority to operate the equipment.
Do not touch the spinning blades
or fl y over another person's head.
Adult supervision is required.
www.revell.com
Revell, Inc., a subsidiary of
®
, Inc., Champaign, IL 61826
