2001 East Terra Lane • O'Fallon, Missouri 63366
(636)240-2400 • Fax (636)272-2408 • (800)325-6152 • Intl Fax# (001)636-272-7546
Parts Dept. (800)424-TRUE • Parts Dept. Fax# (636)272-9471 • www.truemfg.com
Model:
TBB-24-48
ROUGH-IN DATA
Model
Doors
TBB-24-48
2
† Depth does not include 1" (26 mm) for rear bumpers.
T
R
RUE
EFRIGERATION
®
MADE IN
U.S.A.
SINCE 1945
3/13
TRUE FOOD SERVICE
EQUIPMENT, INC.
Underbar Refrigeration:
Solid Swing Door 24" Back Bar Cooler
Chart dimensions rounded up to the nearest 1/8"
Capacity
12 oz.
1/2
Cans
Barrels
Shelves
48 6-pks
2
4
Printed in U.S.A.
Project Name:
Location:
Item #:
Model #:
Scan code
for video
Cabinet Dimensions
(inches)
(mm)
L
D†
H
HP
491/8
241/2
355/8
1/3
1248
623
905
1/3
230-240/50/1
APPROVALS:
Qty:
TBB-24-48
True's refrigerated back bar
coolers are designed with
enduring quality and value.
Our commitment to using the
highest quality materials and
oversized refrigeration assures
colder product temperatures
and years of trouble free
service.
Oversized, factory balanced,
refrigeration system holds 33°F
to 38°F (.5°C to 3.3°C).
Exterior - heavy duty, wear
resistant laminated black vinyl
front and sides. Matching
black aluminum back. All
stainless steel counter top.
Interior - Stainless steel floor
with 1/2" (13 mm) reinforced lip
and heavy gauge galvanized
steel walls.
NSF-7 approved for packaged
and bottled product.
Positive seal doors.
Entire cabinet structure and
solid doors are foamed-
in-place using Ecomate. A
high density, polyurethane
insulation that has zero ozone
depletion potential (ODP) and
zero global warming potential
(GWP).
Specifications subject to change without notice.
(millimeters rounded up to next whole
NEMA
Voltage
Amps
Config.
115/60/1
7.0
5-15P
▲
4.2
▲Plug type varies by country.
AVAILABLE AT:
AIA #
SIS #
number).
Cord
Crated
Length
Weight
(total ft.)
(lbs.)
(total m)
(kg)
7
300
2.13
137
