Tripp Lite ECO650LCD Specification

Model #: ECO650LCD
ECO 650VA Energy-saving 120V Standby UPS with Enhanced LCD interface and USB monitoring port
Description
The ECO650LCD ultra-compact green UPS offers complete protection from blackouts, voltage fluctuations and transient surges. Interactive LCD
user interface offers detailed UPS and site electrical data, including input/output voltage, estimated runtime remaining, load percentage, load
wattage and battery charge level. Energy saving ECO outlets give users the option to automatically power off unused desktop accessories like a
printer and audio speakers as the computer connected via USB goes to low-power sleep or shutdown modes. 99% full load efficiency rating offers
energy savings and cool operating temperatures. Green eco-friendly design meets strict RoHS environmental standards. Provides uninterruptible
transfer to battery derived AC output during power failures and voltage fluctuations with enough runtime to save and shutdown connected equipment
without data loss. Space saving, ultra-compact desktop or wall mount compatible housing. Includes 4 battery supported outlets for computer,
monitor and two vital system accessories, plus 4 additional surge suppression-only outlets for accessories not requiring battery support. Three
surge-only outlets marked "ECO" can be configured to automatically power-off within 3 minutes of the connected computer entering sleep or
shutdown mode. USB port monitors computer power status for ECO power savings and enables direct integration with built-in power management
and auto-shutdown features of Windows and Mac OS X. PowerAlert software is also available via free download from www.tripplite.com to provide
advanced auto-shutdown, UPS monitoring and data saving options. USB cable included. Built-in single line RJ11 phone suppression protects
modem, fax machine, cordless phone or other accessories with a dial-up/DSL phone connection. Built-in interactive LCD screen offers continuous
power and UPS status information. Audible alarm warns of power failure conditions. Self-test, display brightness, alarm disable and LCD information
display scrolling options are controllable via interactive LCD user interface. 650VA / 325 watt UPS capacity supports entry-level PC systems for up
to 17 minutes during power fail conditions. $100,000 connected equipment insurance (USA, Puerto Rico, & Canada Only).
Package Includes
ECO650LCD UPS System
USB cable
Instruction manual
Features
ECO650LCD power saving, green UPS offers complete protection from blackouts, voltage fluctuations and transient surges
Interactive LCD user interface with scroll and select buttons offer detailed UPS status and control options
LCD screen options support continuous display of Input voltage, Output voltage, Estimated runtime, Load percentage, Load wattage and
Battery charge percentage - with the option to continuously scroll all six information fields
LCD screen with scroll and select functions also gives users the ability to enable and disable specific UPS features, such as the ECO
energy-saving feature, permanent alarm silence, LCD brightness, information display scroll functions and UPS self-test operation
Set of 3 optional ECO outlets automatically power off unnecessary computer accessories like a printer, scanner and audio speakers three
minutes after computer enters sleep or shutdown mode
Full load efficiency rating of 99% saves energy and ensures cool operating temperatures
ECO650LCD emits only 17 BTU/hr. and consumes less than 4 watts once the battery is charged
Eco-friendly design meets strict RoHS (Restriction of Hazardous Substances) environmental standards
650VA / 325 watts provides battery-derived AC output during power failures and severe voltage fluctuations to support an entry level
desktop computer up to 17 minutes
Highlights
650VA ultra-compact 120V standby UPS, LCD status and control display
Maintains AC output during power failures, 99% line mode efficiency
ECO option turns off set of three outlets when the computer is not in use
USB port, TEL/DSL protection, Wall mountable, Surge-only outlets
NEMA 5-15P input plug and 8 NEMA 5-15R outlets
This product is ENERGY STAR qualified for its ability to save customers
money while helping to protect the environment
