Naxa NX-669 Instruction Manual

Naxa NX-669 Instruction Manual

Motorized etr slide down detachable car radio panel with dvd player, tv tuner, and 4 ” lcd screen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
THIS PRODUCT INCORPORATES COPYRIGHT PROTECTION
TECHNOLOGY THAT IS PROTECTED BY U.S. PATENTS AND
OTHER INTELLECTUAL PROPERTY RIGHTS. USE OF THIS
COPYRIGHT PROTECTION TECHNOLOGY MUST BE
AUTHORIZED BY MACROVISION, AND IS INTENDED FOR
HOME AND OTHER LIMITED VIEWING USES ONLY UNLESS
OTHERWISE AUTHORIZED BY MACROVISION. REVERSE
ENGINEERING OR DISASSEMBLY IS PROHIBITED.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
U.S. Patent Nos. 4,631,603;4,577,216;4,819,098 ;4,907,093;5,315,448 and 6,516,132.
PDF created with FinePrint pdfFactory trial version
http://www.pdffactory.com
Instruction Manual
RST
1
2
INT
3
RPT
SEL
_
+
VOL
AUX
ANG
4
RDM
5
-10
6
+10
USB/DVD/VCD/MP3/CD PLAYER
PWR
P/N
EQ
BAND
MU
MODE
MENU
SEL
0K
+
SETUP
Fully Compatible to These
1
2
3
4
-10
+10
Formats of Files: DVD,MP4,
5
6
7
8
9
0/10
10+
CLK
SLOW_FWD
ST
VCD,JPEG,MP3,WMA,CD.
LOC
SEARCH
APS
ZOOM
INT
RPT
RDM
AUDIO
TITLE/PBC
SUBTITLE
A-B
PROG
OSD
LOUD
STEP
Motorized ETR Slide Down Detachable
Car Radio Panel with DVD Player, TV Tuner,
and 4 " LCD Screen
NX-669
MU
M
MOD
EJ
UP
DN
BND
EQ
CLK
A.P
REL
D OLBY
D I G I T A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NX-669 and is the answer not in the manual?

Questions and answers

Related Manuals for Naxa NX-669

Summary of Contents for Naxa NX-669

  • Page 1 NX-669 Instruction Manual D OLBY USB/DVD/VCD/MP3/CD PLAYER D I G I T A L BAND MODE MENU SETUP THIS PRODUCT INCORPORATES COPYRIGHT PROTECTION Fully Compatible to These TECHNOLOGY THAT IS PROTECTED BY U.S. PATENTS AND OTHER INTELLECTUAL PROPERTY RIGHTS. USE OF THIS...
  • Page 2 PRECAUTION WARNING: TO REDUCE THE CAUTION RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE RISK OF ELECTRIC SHOCK THIS APPLIANCE TO RAIN OR DO NOT OPEN MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 3: Table Of Contents

    Contents 1. Before Operation...................3 8. Specification 1.1 Glossary....................3 1.2 Precautions....................3 1.3 Maintenance and Cleaning of Discs............4 1.4 Battery Information of the Remote Control..........4 General Specification 1.5 The Remote Control Description..............5 1.6 Description of the Face of the Front Panel..........6 Power Supply Requirement..........DC 12V 1.7 Description of the Unit Chassis Facet After removing the Front Panel..6 Maximum Power Output....4 x 25W(measured at DC 14.4 V)

  • Page 4: Before Operation

    7. The Trouble Shooting 1. Before Operation Please read the user ’s manual carefully before using the DVD player. If you have any troubles in using this player, try to solve the problems by the suggestions mentioned below. If you can 1.1 Glossary not remove the trouble after using all the suggestions, please contact the company or the technical service center authorized by us.

  • Page 5: Maintenance And Cleaning Of Discs

    1.3 Maintenance and Cleaning of Discs .20 The Region Code Disc Maintenance 1. To keep the disc clean, andle the disc by its edge, do not touch the disc Q: Not begin to playback but to display REGION ERROR after inserting disc into surface of the play side.

  • Page 6: The Remote Control Description

    1.5 The Remote Control Description It is for adjusting the hue of the video output. 1. TILT BUTTON SATURATION It is for adjusting the saturation of the video output. 2. MENU BUTTON SHARPNESS It is for adjusting the sharpness of the video output. 3.

  • Page 7: Description Of The Face Of The Front Panel

    6.19.2 LANGUAGE SETUP 1.6 Description of the Face of the Front Panel 14 15 16 LANGUAGE SETUP OSD LANGUAGE AUDIO LANG SUBTITLE LANG MENU LANG EXIT SETUP OSD LANGUAGE This item is for selecting the language of the SYSTEM MENU and all operating prompt interface displayed during playback.

  • Page 8: Description Of The Rear Cabinet

    1.9 Description of the Rear Cabinet For the DVD System Menu, there are 6 setup pages in all. They display as follows: Fixing Screw Bolt Reversal line White Parking Line GREEN 5 .19.1 SYSTEM SETUP SYSTEM SETUP TV Antenna TV SYSTEM BLACK BLACK YELLOW...

  • Page 9: Unit Installation

    3. During JPEG playback, press one of the >/</^/v buttons to change the angle of viewing picture that is displaying as follows: >: 90 deg cw; <: 90deg ccw; ^:UP<-->DOWN; v: LEFT<-->RIGHT During JPEG playback, press the PROG button to change the mode of refresh picture. 1.11 UNIT INSTALLATION During JPEG playback, press the STOP button to stop playing and return to the root menu.

  • Page 10: Common Operation

    .14 Program Playback 2. Common Operation It allows you to enter the order in which you want some chapters/tracks in 1. To turn on/off the unit DVD/VCD/MP3/WMA/CD disc to play. Under power off mode, press the POWER button to turn on the unit. 1 During playback, press the PROG button to enter a program interface as Under power on mode, long press the POWER button on the front panel or follows:...

  • Page 11: Radio Operation

    ZOOMx2,ZOOMx3,ZOOMx4,ZOOMx1/2,ZOOMx1/3,ZOOMx1/4,ZOOM OFF. Press one of the ^/v/>/< buttons to select the area you want to enlarge. 3. Radio Operation .10 Change the Caption Language 1. BAND BUTTON In RADIO mode, press the BAND button on the remote control or on the front panel to In the state of DVD disc playing, press the SUBTITLE button repeatedly to select your desired radio band of FM1, FM2, FM3, AM1...

  • Page 12: Tv Operation

    6.5 Playback in Scan Mode 4. TV Operation 1. In the state of VCD(PBC OFF)/CD disc playing, press the INT button to play the previous 10 seconds part of each track on the disc. Press the INT button again to resume normal playback. 1.

  • Page 13: Basic Disc, Usb Or Mmc/Sd Operation

    During slow forward, press the PLAY button to resume normal playback. 5. Basic Disc, USB or MMC/SD Operation The function is only for video. 5.1 Begin playback .3 Playback with still frame 1. Press the POWER button briefly to turn on the DVD player. After turning on the DVD player, please turn on the monitor, and ensure that If the unit is currently running DVD/VCD disc, press the STEP button the video output of the monitor is the video input from the DVD player...

  • Page 14: Pause Playback

    5.2 Pause Playback In VCD mode In the state of DVD/VCD/CD/MP3/WMA disc playing, press the PAUSE 1. When starting to turn on the PBC function, it will play from the beginning of button on IR remote control to pause the playback, press the PLAY the disc till it display the PBC menu on TV screen if the disc include the PBC button to resume normal playback.

Table of Contents
