GE JVM2052 Installation Instructions Manual
Above the cooktop oven
Hide thumbs
Also See for JVM2052:
- Owner's manual (40 pages) ,
- Installation instructions manual (24 pages) ,
- Installation instructions manual (16 pages)
Table of Contents
Advertisement
Quick Links
Installation
Instructions
Questions? Call 800.GE.CARES (800.432.2737)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT –
•
instructions for local inspector's use.
IMPORTANT –
•
governing codes and ordinances.
Note to Installer –
•
instructions with the Consumer.
MFL57007101
49-40587-1
07-09 JR
Save these
Observe all
Be sure to leave these
Above the
Cooktop Oven
Model JVM2052
or Visit our Website at:
Note to Consumer –
•
for future reference.
• Skill level – Installation of this appliance requires basic
mechanical and electrical skills.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
KEEP THESE INSTRUCTIONS.
GEAppliances.com
Keep these instructions
READ CAREFULLY.
Advertisement
Table of Contents
Related Manuals for GE JVM2052
Summary of Contents for GE JVM2052
-
Page 1: Installation Instructions
Installation Instructions Questions? Call 800.GE.CARES (800.432.2737) BEFORE YOU BEGIN Read these instructions completely and carefully. IMPORTANT – • Save these instructions for local inspector’s use. IMPORTANT – • Observe all governing codes and ordinances. Note to Installer – • Be sure to leave these instructions with the Consumer. -
Page 2: Table Of Contents
Adapt Microwave Oven Blower for Outside Back Exhaust ...16, 17 Mount the Microwave Oven...18 Installation Instructions Before You Use Your Microwave Oven ... 23 Recirculating ... 19–22 Attach Mounting Plate to Wall ...19 Preparation of Top Cabinet ...19 Adapt Microwave Oven Blower for Recirculation ...20... -
Page 3: Important Safety Instructions
It must be mounted to BOTH a top cabinet AND a wall. injury (back injury or other injuries due to excessive weight of the microwave oven) or property damage, you will need two people to install this microwave oven. CAUTION: For personal safety, CAUTION:... -
Page 4: Hood Exhaust
HOOD EXHAUST NOTE: Read these next two pages only if you plan to vent your exhaust to the outside. If you plan to recirculate the air back into the room, proceed to page 6. OUTSIDE TOP EXHAUST (EXAMPLE ONLY) The following chart describes an example of one possible ductwork installation. - Page 5 NOTE: If you need to install ducts, note that the total duct length of 3 ⁄ " x 10" rectangular or 6" diameter round duct should not exceed 120 equivalent feet. Outside ventilation requires a HOOD EXHAUST DUCT. Read the following carefully. NOTE: It is important that venting be installed using the most direct route and with as few elbows as possible.
-
Page 6: Damage - Shipment/Installation
Installation Instructions DAMAGE – SHIPMENT/ INSTALLATION • If the unit is damaged in shipment, return the unit to the store in which it was bought for repair or replacement. • If the unit is damaged by the customer, repair or replacement is the responsibility of the customer. -
Page 7: Tools You Will Need
TOOLS YOU WILL NEED Phillips screwdriver Flat blade screwdriver Tin snips (for cutting damper, if required) Scissors (to cut template, if necessary) Gloves Saw (saber, hole or keyhole) Safety goggles MOUNTING SPACE 30" min. ⁄ " 30" 2" 66" or more from the floor to the top of the oven... -
Page 8: Placement Of Mounting Plate
The center of any adjacent studs should be 16″ or 24″ from this mark. Draw a line down the center of the studs. IMPORTANT: The microwave oven must be connected to at least one wall stud. Wall Studs... -
Page 9: Determining Wall Plate Location
Mounting Plate Tabs Touching the Cabinet Bottom Your cabinets may have decorative trim that interferes with the microwave oven installation. Remove the decorative trim to install the microwave oven properly and to make it level. Mounting Plate with Tabs Below Cabinet THE MICROWAVE OVEN MUST BE LEVEL. -
Page 10: Aligning The Wall Plate
E and draw a fifth circle to line up with the stud. It is important to use at least one wood screw mounted firmly in a stud to support the weight of the microwave oven. Set the mounting plate aside. Installation Instructions... -
Page 11: Installation Types
See page 12 See page 19 Installation Instructions (Choose A, B or C) NOTE: This microwave oven is shipped assembled for Outside Top Exhaust (except for non-vented models). Select the type of ventilation required for your installation and proceed to that section. -
Page 12: Aoutside Top Exhaust
INSTALLATION OVERVIEW A1. Attach Mounting Plate to Wall A2. Prepare Top Cabinet A3. Attach Exhaust Damper A4. Mount Microwave Oven ATTACH THE MOUNTING PLATE TO THE WALL Attach the plate to the wall using toggle bolts. At least one wood screw must be used to attach the plate to a wall stud. -
Page 13: Preparation Of Top Cabinet
Wear safety goggles when drilling holes in the cabinet bottom. ATTACH EXHAUST DAMPER Blower unit • Place the microwave oven in its upright position, with the top of the unit facing up. • This microwave oven is shipped assembled for top exhaust. - Page 14 Cabinet Front Cabinet Bottom Shelf Self-Aligning Screw Microwave Oven Top 5 Attach the microwave oven to the top cabinet. Insert 2 self-aligning screws through outer top cabinet holes. Turn two full turns on each screw. Tighten the two screws to the top of the microwave oven.
-
Page 15: Boutside Back Exhaust
B1. Prepare Rear Wall B2. Attach Mounting Plate to Wall B3. Prepare Top Cabinet B4. Adjust Blower B5. Mount the Microwave Oven PREPARE THE REAR WALL FOR OUTSIDE BACK EXHAUST You need to cut an opening in the rear wall for outside exhaust. -
Page 16: Attach Mounting Plate To Wall
Discard the knockouts. Be careful not to distort the plate. USE TOP CABINET TEMPLATE FOR PREPARATION OF TOP CABINET Wear safety goggles when ADAPT MICROWAVE OVEN BLOWER FOR OUTSIDE BACK EXHAUST Blower plate mounting screw (3 screws) -
Page 17: Adapt Microwave Oven Blower
Make sure the wires are not pinched. NOTE: The blower unit exhaust openings should match exhaust openings on rear of microwave oven. Reattach the blower plate to the cabinet so the exhaust ports and blower plate opening are aligned. -
Page 18: Mount The Microwave Oven
Install the power supply cord clamp, using a screw as shown, to the inside of the cabinet. 5 Attach the microwave oven to the top cabinet. Tighten the two screws to the top of the microwave oven. (While tightening screws, hold the microwave oven in place against the wall and the top cabinet.) -
Page 19: Recirculating
INSTALLATION OVERVIEW C1. Attach Mounting Plate to Wall C2. Prepare Top Cabinet C3. Adjust Blower C4. Mount the Microwave Oven C5. Install Charcoal Filter ATTACH THE MOUNTING PLATE TO THE WALL Attach the plate to the wall using toggle bolts. -
Page 20: Adapt Microwave Oven Blower For Recirculation
Carefully pull out the blower unit. The wires will extend far enough to allow you to adjust the blower unit. Roll the blower unit 90° so that fan blade openings are facing toward the front of the microwave oven. BEFORE: Fan Blade Openings Facing Up Roll... -
Page 21: Mount The Microwave Oven
CAUTION: To avoid the risk of personal injury (back injury or other injuries due to excessive weight of the microwave oven) or property damage, you will need two people to install this microwave oven. IMPORTANT: Do not grip or use handle during installation. -
Page 22: Install The Charcoal Filter
INSTALLING THE CHARCOAL FILTER Remove 2 screws on the top front of the grille using a Phillips screwdriver. Open the door. Remove the grille, pulling it straight off. Install the charcoal filter. When properly installed, the wire mesh of the filter should be visible from the front. -
Page 23: Before You Use Your Microwave Oven
BEFORE YOU USE YOUR MICROWAVE OVEN Make sure the microwave oven has been installed according to instructions. Remove all packing material from the microwave oven. Install turntable and ring in cavity. Replace house fuse or turn breaker back on. Plug power cord into a dedicated 15- to 20-amp electrical outlet. - Page 24 Printed in China...
