Toa DP-0206 Supplement Instruction Manual

DIGITAL PROCESSOR
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.

ABOUT THE DQ-D01 DIGITAL I/O MODULE

This supplementary manual explains the operation of the optional DQ-D01 Digital I/O Module when using it in
conjunction with the DP-0206 Digital Processor. Please also refer to the instruction manual for the DQ-D01.

Input Level Indicator

When the DQ-D01 is used in Input mode, the DP-0206's Input Level Indicator lights as follows:
RED:
GREEN:
OFF:
Flashing ORANGE:
ORANGE or flashing RED: The DQ-D01 Module is inserted into the wrong slot.
* 0 dB = Digital full scale level

Output Level Indicator

When the DQ-D01 is used in Output mode, the DP-0206's Output Level Indicator lights as follows:
RED:
GREEN:
OFF:
Flashing ORANGE:
ORANGE or flashing RED: The DQ-D01 Module is inserted into the wrong slot.
* 0 dB = Digital full scale level

Mounting the DQ-D01 Module

Refer to the chapter "4. INSTALLATION" in the DQ-D01 Instruction Manual.

I/O Configuration Setting and Confirmation

The instructions provided in the DP-0206 Instruction Manual also apply to the DQ-D01.

Specifications

(DP-0206 Instruction Manual, p. 42 – 44)
The DQ-D01's specifications are contained in the DQ-D01 Instruction Manual.
(DP-0206 Instruction Manual, p. 6)
Input signal level exceeds –6 dB*.
Input signal level is greater than –72* dB but less than –6 dB*.
Input signal level is less than –72 dB*.
Incorrect AES/EBU signal input.
→ Check that the output equipment is correctly connected, or that the
connected equipment is correctly providing an AES/EBU signal.
→ Reinsert the module correctly.
(DP-0206 Instruction Manual, p. 6)
Output signal level exceeds –6 dB*.
Output signal level is greater than –72* dB but less than –6 dB*.
Output signal level is less than –72 dB*.
Output signal is muted.
→ Reinsert the module correctly.
(DP-0206 Instruction Manual, p. 9 – 10)
INSTRUCTION MANUAL
(DP-0206 Instruction Manual, p. 15)
(Supplement)
DP-0206
