DIGITAL PROCESSOR
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
Important
When the YA-304 power cord is attached to the DP-0206 unit, the power voltage must be under
125 V. If the power voltage exceeds 125 V, prepare a different power cord.
When the power cord other than the YA-304 is attached, the unit can be used in areas where
the power voltage is 230 V.

OPERATING INSTRUCTIONS

DP-0206

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP-0206 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Toa DP-0206

  • Page 1: Operating Instructions

    OPERATING INSTRUCTIONS DIGITAL PROCESSOR DP-0206 Please follow the instructions in this manual to obtain the optimum results from this unit. We also recommend that you keep this manual handy for future reference. Important When the YA-304 power cord is attached to the DP-0206 unit, the power voltage must be under 125 V.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. SAFETY PRECAUTIONS ................3 2. GENERAL DESCRIPTION ................5 3. FEATURES ......................5 4. HANDLING PRECAUTIONS ................5 5. ABOUT THE SIGNAL PROCESSING FUNCTION ......... 5 6. NOMENCLATURE AND FUNCTIONS Front ........................6 Inside of the Security Cover ..................7 Rear ........................
  • Page 3: Safety Precautions

    • Should you detect smoke or a strange smell coming from the unit during use, immediately disconnect the power supply plug from the AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the unit in this condition as this may cause fire or electric shock.
  • Page 4 When the Unit is in Use • Unplug the power supply plug from the AC outlet for safety purposes when cleaning or leaving the unit unused for 10 days or more. A fire or electric shock may result. • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
  • Page 5: General Description

    2. GENERAL DESCRIPTION The TOA DP-0206 is a 2-rack unit size Digital Processor provided with signal processing function necessary for sound systems. The settings of each function are performed from a PC using dedicated software, and can be stored in the unit's memory. The stored settings can be recalled from the unit without connecting the PC.
  • Page 6: Nomenclature And Functions Front

    6. NOMENCLATURE AND FUNCTIONS [Front] 1. Input Level Indicator [INPUTS 1 – 6] 3. Power Indicator [POWER] Indicates the input level and status of each input Lights when the power is switched on. channel. Note: The DP-0206 unit is not equipped with a power switch.
  • Page 7: Inside Of The Security Cover

    [Inside of the Security Cover] 10. Reset Key [RESET] 12. RS-232C Communications Port [RS-232C] Returns the unit to the initial setting at the time This port is a 9-pin (female) D-sub connector for when the power has been switched on. RS-232C communications and is connected in Notes parallel with the rear panel-mounted D-sub...
  • Page 8: Analog Input Module Dq-A01 (Optional Product)

    • Analog Input Module DQ-A01 (Optional product) Expands the inputs by 2 channels. 21. Input Connector [INPUTS (+4 dB) 3 – 4 or 5 – 6] Electronically-balanced input with a terminal block type 4-pole connector. • Analog Output Module DQ-A02 (Optional product) Expands the outputs by 2 channels.
  • Page 9: Installation

    7. INSTALLATION Follow the procedures below to install the unit: Step 1. Installation of option modules (Refer to p. 9.) Step 2. Input/output and control cable connections (Refer to p. 12.) Step 3. Connections between units (Refer to p. 13.) Step 4.
  • Page 10 Step 1. Remove the power cord from the DP-0206. Step 2. Remove 5 screws to detach the top panel. Step 3. Detach the cover of the module slot to be used (AUDIO 1 or AUDIO 2) depending on the input/output configuration by removing two screws.
  • Page 11: Remote Control Module Installation

    7.1.2. Remote control module installation External equipment control can be performed with the addition of an optional DQ-C01 Remote Control Module. Step 1. Remove the power cord from the DP-0206. Step 2. Remove 5 screws to detach the top panel. Step 3.
  • Page 12: Input/Output And Control Cable Connections

    7.2. Input/Output and Control Cable Connections Connect external input/output cables to the unit's rear panel-mounted input/output connectors (terminal block type connectors). Perform the following connections depending on the type of equipment to be connected. • Input connector Input connector pin No. Balanced connection Cold Ground (Use only when...
  • Page 13 Cautions • Be sure to use shielded cables for audio signal lines. • When using stranded or shielded cables, avoid tin-lead plating over the stripped cable end Solid or stranded cable Shielded cable 7 mm 7 mm 20 mm Connector connections Slotted screwdriver Step 1.
  • Page 14: Connections Between Units

    7.3. Connections between Units Using the unit's rear panel-mounted RS-485 port, up to 30 units can be connected. It is possible to control such connected units with a single PC or simultaneously switch their pattern memories from the master unit. Connection method Using 2-core shielded cables, connect the unit's RS-485 port connector to that of other unit as shown below.
  • Page 15: Input/Output Configuration Settings And Confirmation

    7.4. Input/Output Configuration Settings and Confirmation 7.4.1. Input/Output configuration settings Follow the procedures below to set the I/O configuration when an optional DQ-A01 Analog Input Module or DQ-A02 Analog Output Module has been mounted or detached: Caution If the I/O configuration setting is performed, the Unit ID numbers and all other parameters will be initialized and reset to the factory-preset mode.
  • Page 16: Default Signal Flow

    7.4.3. Default signal flow Signal flow is factory-preset as follows depending on the input/output configuration: Note: For signal flow changes, refer to the software instruction manual. Input Output Input Output Input Output 2-IN/6-OUT 2-IN/8-OUT 2-IN/10-OUT Input Output Input Output Input Output 4-IN/6-OUT 4-IN/8-OUT...
  • Page 17: Changing The Unit Id Number

    [Multiple units] Set consecutive ID numbers beginning with "1", which are automatically assigned to the units in setting order. Notes • Make connections of the rear panel-mounted RS-485 port before using. (Refer to p. 14 "Connections between Units.") • The unit set for ID No. 1 functions as a master unit. Step 1.
  • Page 18: Pc Connections

    7.6. PC Connections The DP-0206 processor is not provided with on-board parameter setting functions. To set parameters, a PC with dedicated software installed is required. Up to 30 units can be simultaneously controlled from the PC. After the parameters set with the PC are stored in each unit's memory, the unit can be used without the PC connecting to the unit.
  • Page 19: Rs-485 Connections

    Caution When multiple units are connected, if the PC is connected to the unit set for Unit ID number other than "1," only the PC-connected unit can be controlled. Other units cannot be controlled. Unit ID No. 3 System control from Master unit Unit ID No.
  • Page 20: Pattern Memory Recall

    7.7. Pattern Memory Recall The setting of the unit's parameter requires a PC with dedicated software installed. However, after storing the setting status in 16 memories, the pattern memory can be recalled from the unit even if the PC is not connected.
  • Page 21: Appendix

    8. APPENDIX 8.1. System Lock Function Two different types of system lock are made available to disable specific front panel functions. [System Lock 1] Operations to be disabled: Initialization (p.22), Unit ID number change (p.17), and communication speed change (p.23) How to lock: Shift the System Lock switch to the right.
  • Page 22: Error Indications

    These errors were detected by the unit's internal CPU. If these error indications continue to be displayed after the power has been switched off and on, contact your nearest TOA dealer or the dealer from where the unit was purchased.
  • Page 23: Changing The Rs-485 Communication Speed

    8.10. Changing the RS-485 Communication Speed The unit's RS-485 communication speed is preset to 115200 bps by the factory. To increase the cable distance, decreasing the communication speed permits highly-reliable transmissions. It is recommended that the communication speed be changed when the cable length exceeds 100 m. Cautions •...
  • Page 24: Recalling Pattern Memory Using The Memory Selector

    8.11. Recalling Pattern Memory Using the Memory Selector The DK-1608 Memory Selector is used to recall pattern memory stored in the DX-0808 Matrix Unit, etc. The two methods used to recall the unit's stored pattern memory using the DK-1608 will be explained. (Refer to the DK-1608 Instruction Manual for information on the DK-1608's specifications and operation.) 8.11.1.
  • Page 25 Follow the below procedure to return the unit's RS-232C communication port to its factory-preset condition. Step 1. Shift the System Lock switch to the left. Step 2. Press the Reset key while holding down the Memory/Unit ID Number selector's Up ( key.
  • Page 26 When the distance between the Master unit and the DK-1608 is 10 m or more, use an RS-232C/RS-485 converter to convert to RS-485, then connect to the DK-1608's RS-485 communication port. DP-0206 9-pin D-sub (male) Place the RS-232C/RS-485 converter near the DP-0206, then connect the DP-0206's RS-232C port to the converter's RS-232C port using the 9-pin D-sub (male) reverse cable.
  • Page 27: Using The Remote Control Module

    8.11.2. Using the Remote Control Module Note This method can only be used when the DX-0808 Matrix Unit or DI-1616 Interface Unit is connected to the DK-1608 Memory Selector. When only the unit is connected to the DK-1608, use the unit's RS-232C communication port to recall the pattern memory as explained above.
  • Page 28: Controlling The Remote Control Module's Terminals

    8.12. Controlling the Remote Control Module's Terminals This section describes how to control the DQ-C01 Remote Control Module's terminals when recalling the pattern memory, adjusting output sound volume, or controlling output signal muting by way of connected external equipment. (For the settings of each function, please refer to the accompanying Software Instruction Manual.) 8.12.1.
  • Page 29 [Binary mode] The following tables show the relationship between the state to be assigned to the terminal and the pattern memory to be recalled: (In the tables, [O] stands for a short circuit, and [–] stands for an open circuit. ) •...
  • Page 30: Output Volume Adjustment

    8.12.2. Output volume adjustment As with the pattern memory, Direct mode and Binary mode are also available. Notes • Output volume can only be adjusted for the unit in which the DQ-C01 Remote Control Module is installed. • The output volume adjustment is a function to provide the output attenuator setting with an offset. Switching off the power clears the offset value, and returns the output attenuator to the preset value.
  • Page 31 • Increasing/Decreasing the volume of 7 groups using Terminals 5 – 8 Group Terminal 5 Terminal 6 Terminal 7 Terminal 8 1 Up 1 Down – 2 Up – 2 Down – – 3 Up – 3 Down – – 4 Up –...
  • Page 32: Output Muting

    • Assign the state corresponding to Increase/Decrease of the group the volume of which is to be adjusted to the terminal to be used and maintain the state for 500 ms or more (less than 700 ms). Opening all terminals to be used varies the volume by 1 step.
  • Page 33: Firmware Update

    [Pulse operation] Shorting each terminal with the C terminal turns muting ON. Muting turns OFF 500 ms after the terminals are opened and then shorted again. Muting toggles between ON and OFF as the short-open operation is repeated. Open Short Open Short Open...
  • Page 34: Update Program Activation

    8.13.2. Update program activation Execute [Update DP-0206 Firmware] from the start menu. Note This program is also installed when the setting software is installed. Refer to the Software Instruction Manual for more information on setting software installation. 8.13.3. Update There are 2 methods: one for RS-232C use and one for RS-485 use. [Update using RS-232C] Step 1.
  • Page 35 Step 3. The following message will be displayed upon update completion.
  • Page 36 [Update using RS-485] Step 1. Press the Baud Rate Settings button to set the communication port and transmission rate. Match the transmission rate with that set for the unit. (Refer to P. 23, Changing the RS-485 Communication Speed.) Step 2. Pressing the Update button (U) begins to update the transfer firmware. Step 3.
  • Page 37 Step 4. Press the OK button as prompted by the message. The signal processing firmware update is then started. Step5. The following message is displayed. Step 6. Press the OK button as prompted by the message. The control firmware update is then started.
  • Page 38: Setting Restoration

    Step 7. The following message will be displayed upon update completion. 8.13.4. Setting restoration Updating firmware may invalidate settings made before the update. In such cases, restore the settings using the following procedure: Step 1. Delete all of the setting contents. (Refer to p. 22, Initialization.) Step 2.
  • Page 39: Memory/Unit Id Number Display Indication At Activation

    8.15. Memory/Unit ID Number Display Indication at Activation The Memory/Unit ID Number Display's indication changes in the following order after the power has been switched on or the Reset button pressed. (1) "8.8." (All indicators ON) (2) "dP" (3) "CH", "C1", "C2" or "C3" (Refer to p.23, RS-485 Communication Speed.) (4) "1.7", etc.
  • Page 40: Connection Example

    8.16. Connection Example Mixer DP-0206 4-IN/8-OUT configuration Contact control equipment (such as a timer) Power amplifier Speaker Power amplifier Speaker...
  • Page 41: Block Diagram

    9. BLOCK DIAGRAM SIGNAL/ SIGNAL/ – ∞ to 0 dB PEAK PEAK OUTPUT 1 INPUT 1 MUTE (+4 dB*) (+4 dB*) SIGNAL/ SIGNAL/ PEAK – ∞ to 0 dB PEAK INPUT 2 MUTE OUTPUT 2 (+4 dB*) (+4 dB*) SIGNAL/ –...
  • Page 42: Specifications

    10. SPECIFICATIONS Power Source 100 – 240 V AC, 50/60 Hz Power Consumption 30 W Frequency Response 20 – 20,000 Hz (±1 dB) Sampling Frequency 48 kHz Dynamic Range 110 dB (IHF-A weighted) Total Harmonic Distortion Less than 0.05%, 1 kHz, +4 dB* input/output (20 – 20,000 Hz BPF) Input 2 channels (expandable to up to 6 channels), +4 dB* (Max.
  • Page 43: Dq-A01, Dq-A02

    Finish Panel: Aluminum, hair-line finish, black Other sections: Pre-coated steel plate, black, 30% glossy Dimensions 482 (w) x 88.4 (h) x 331.1 (d) mm Weight 4.65 kg * 0 dB = 0.775 V Notes • Windows 95/98/NT are Microsoft Corporation's trademarks. •...
  • Page 44: Dq-C01

    [Remote Control Module DQ-C01] (optional product) Control Input COM/terminal 1 – 8: Open voltage: 5 V DC, short-circuit current: 25 mA, terminal block type connector (9 poles) Memory Selection Direct: Max. 8 memories, Binary: Max. 16 memories (Any one of 16 memories assignable to each terminal in "Direct" mode.) Control method: No-voltage make of over 500 ms/No-voltage make pulse of over 500 ms ("No-voltage make of over 500 ms"...
