Advertisement

ThinkCentre
Hardware Maintenance Manual
Machine Types: 3026, 3029, 3039, 3054, 3137, 3139, 3149, 3219,
3245, 3246, 3245, 3282, 3319, 3349, 3394, 3421, 3491, 3544, 3627,
3652, 3699, 3769, 3878, 3934, 4972, 4992, 5132, 5206, 5261, 5267,
5297, 5325, 5384, 5391, 5450, 5472, 5474, 5485, 5498, 5536, 5548,

Advertisement

   Related Manuals for Lenovo ThinkCentre

   Summary of Contents for Lenovo ThinkCentre

  • Page 1

    ThinkCentre Hardware Maintenance Manual Machine Types: 3026, 3029, 3039, 3054, 3137, 3139, 3149, 3219, 3245, 3246, 3245, 3282, 3319, 3349, 3394, 3421, 3491, 3544, 3627, 3652, 3699, 3769, 3878, 3934, 4972, 4992, 5132, 5206, 5261, 5267, 5297, 5325, 5384, 5391, 5450, 5472, 5474, 5485, 5498, 5536, 5548,...

  • Page 3

    ThinkCentre Hardware Maintenance Manual Machine Types: 3026, 3029, 3039, 3054, 3137, 3139, 3149, 3219, 3245, 3246, 3245, 3282, 3319, 3349, 3394, 3421, 3491, 3544, 3627, 3652, 3699, 3769, 3878, 3934, 4972, 4992, 5132, 5206, 5261, 5267, 5297, 5325, 5384, 5391, 5450, 5472, 5474, 5485, 5498, 5536, 5548,...

  • Page 4

    “Safety information” on page 3 and Appendix A “Notices” on page 395. Sixth Edition (April 2013) © Copyright Lenovo 2010, 2013. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software are delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No.

  • Page 5: Table Of Contents

    Power Supply Problems ... Lenovo Solution Center ... Diagnostic error codes ...

  • Page 6: Table Of Contents

    Security features ....Windows 7 Home Premium 32 Recovery Hardware-controlled passwords ..CD ....ThinkCentre Hardware Maintenance Manual...

  • Page 7: Table Of Contents

    Recovering from a POST/BIOS update failure . . Index....Power management ... . © Copyright Lenovo 2010, 2013...

  • Page 8

    ThinkCentre Hardware Maintenance Manual...

  • Page 9: Chapter 1. About This Manual, Important Safety Information, Important Information About Replacing Rohs Compliant Frus

    Chapter 1. About this manual This manual contains service and reference information for ThinkCentre® computer machine types listed on the front cover. This manual is intended only for trained servicers who are familiar with Lenovo® computer products. Note: Be sure to read and understand the Chapter 2 “Safety information” on page 3 before using the information in this manual.

  • Page 10

    Lenovo plans to transition to RoHS compliance well before the implementation date and expects its suppliers to be ready to support Lenovo's requirements and schedule in the EU. Products sold in 2005 will contain some RoHS compliant FRUs. The following statement pertains to these products and any product Lenovo produces containing RoHS compliant parts.

  • Page 11: Chapter 2. Safety Information, General Safety, Electrical Safety

    Observe the following rules when working on electrical equipment. © Copyright Lenovo 2010, 2013...

  • Page 12

    (This practice ensures correct grounding of the units.) • If an electrical accident occurs: – Use caution; do not become a victim yourself. – Switch off power. – Send another person to get medical aid. ThinkCentre Hardware Maintenance Manual...

  • Page 13: Voltage-selection Switch, Safety Inspection Guide

    Voltage-selection switch Some computers are equipped with a voltage-selection switch located near the power-cord connection point on the computer. If your computer has a voltage-selection switch, ensure that you set the switch to match the voltage available at your electrical outlet. Setting the voltage-selection switch incorrectly can cause permanent damage to the computer.

  • Page 14: Handling Electrostatic Discharge-sensitive Devices, Grounding Requirements, Safety Notices (multi-lingual Translations)

    Safety notices (multi-lingual translations) The caution and danger safety notices in this section are provided in the following languages: • English • Arabic • Brazilian/Portuguese • Chinese (simplified) • Chinese (traditional) ThinkCentre Hardware Maintenance Manual...

  • Page 15

    • French • German • Hebrew • Italian • Korean • Spanish DANGER Electrical current from power, telephone and communication cables is hazardous. To avoid a shock hazard: • Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm.

  • Page 16

    The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source. ThinkCentre Hardware Maintenance Manual...

  • Page 17

    Chapter 2 Safety information...

  • Page 18

    ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) PERIGO ThinkCentre Hardware Maintenance Manual...

  • Page 19

    A corrente elétrica proveniente de cabos de alimentação, de telefone e de comunicações é perigosa. Para evitar risco de choque elétrico: • Não conecte nem desconecte nenhum cabo ou execute instalação, manutenção ou reconfiguração deste produto durante uma tempestade com raios. •...

  • Page 20

    O dispositivo também pode ter mais de um cabo de alimentação. Para remover toda a corrente elétrica do dispositivo, assegure que todos os cabos de alimentação estejam desconectados da fonte de alimentação. ThinkCentre Hardware Maintenance Manual...

  • Page 21

    Chapter 2 Safety information...

  • Page 22

    ThinkCentre Hardware Maintenance Manual...

  • Page 23

    Chapter 2 Safety information...

  • Page 24

    (sauf instruction contraire mentionnée dans les procédures d'installation et de configuration). • Lorsque vous installez, que vous déplacez, ou que vous manipulez le présent produit ou des périphériques qui lui sont raccordés, reportez-vous aux instructions ci-dessous pour connecter et déconnecter les différents cordons. ThinkCentre Hardware Maintenance Manual...

  • Page 25

    Connexion Déconnexion 1. Mettez les unités HORS TENSION. 1. Mettez les unités HORS TENSION. 2. Commencez par brancher tous les cordons sur les 2. Débranchez les cordons d'alimentation des prises. unités. 3. Débranchez les câbles d'interface des connecteurs. 3. Branchez les câbles d'interface sur des connecteurs. 4.

  • Page 26

    Schutzkontakt anschließen. • Die Signalkabel nach Möglichkeit einhändig anschließen oder lösen, um einen Stromschlag durch Berühren von Oberflächen mit unterschiedlichem elektrischem Potenzial zu vermeiden. • Geräte niemals einschalten, wenn Hinweise auf Feuer, Wasser oder Gebäudeschäden vorliegen. ThinkCentre Hardware Maintenance Manual...

  • Page 27

    • Die Verbindung zu den angeschlossenen Netzkabeln, Telekommunikationssystemen, Netzwerken und Modems ist vor dem Öffnen des Gehäuses zu unterbrechen, sofern in den Installations- und Konfigurationsprozeduren keine anders lautenden Anweisungen enthalten sind. • Zum Installieren, Transportieren und Öffnen der Abdeckungen des Computers oder der angeschlossenen Einheiten die Kabel gemäß...

  • Page 28

    Mit dem Netzschalter an der Einheit und am Netzteil wird die Stromversorgung für die Einheit nicht unterbrochen. Die Einheit kann auch mit mehreren Netzkabeln ausgestattet sein. Um die Stromversorgung für die Einheit vollständig zu unterbrechen, müssen alle zum Gerät führenden Netzkabel vom Netz getrennt werden. ThinkCentre Hardware Maintenance Manual...

  • Page 29

    Chapter 2 Safety information...

  • Page 30

    • Collegare tutti i fili elettrici a una presa di alimentazione correttamente cablata e dotata di messa a terra. • Collegare alle prese elettriche appropriate tutte le apparecchiature che verranno utilizzate per questo prodotto. ThinkCentre Hardware Maintenance Manual...

  • Page 31

    • Se possibile, utilizzare solo una mano per collegare o scollegare i cavi di segnale. • Non accendere assolutamente apparecchiature in presenza di incendi, perdite d'acqua o danno strutturale. • Scollegare i cavi di alimentazione, i sistemi di telecomunicazione, le reti e il modem prima di aprire i coperchi del dispositivo, salvo istruzioni contrarie relative alle procedure di installazione e configurazione.

  • Page 32

    Il pulsante di controllo dell'alimentazione presente sull'unità e l'interruttore dell'alimentatore non disattivano l'alimentazione corrente fornita all'unità. E' possibile che l'unità disponga di più cavi di alimentazione. Per disattivare l'alimentazione dall'unità, accertarsi che tutti i cavi di alimentazione siano scollegati dalla fonte di alimentazione. ThinkCentre Hardware Maintenance Manual...

  • Page 33

    Chapter 2 Safety information...

  • Page 34

    • Cualquier equipo que se conecte a este producto también debe conectarse a tomas de corriente debidamente cableadas. • Siempre que sea posible, utilice una sola mano para conectar o desconectar los cables de señal. • No encienda nunca un equipo cuando hay señales de fuego, agua o daños estructurales. ThinkCentre Hardware Maintenance Manual...

  • Page 35

    • Desconecte los cables de alimentación, los sistemas de telecomunicaciones, las redes y los módems conectados antes de abrir las cubiertas de los dispositivos, a menos que se indique lo contrario en los procedimientos de instalación y configuración. • Conecte y desconecte los cables, como se describe en la tabla siguiente, cuando instale, mueva o abra las cubiertas de este producto o de los dispositivos conectados.

  • Page 36

    Además, el dispositivo podría tener más de un cable de alimentación. Para suprimir toda la corriente eléctrica del dispositivo, asegúrese de que todos los cables de alimentación estén desconectados de la toma de corriente. ThinkCentre Hardware Maintenance Manual...

  • Page 37: Chapter 3. General Information, Thinkvantage Productivity Center, Lenovo Solution Center, Simpletap, Additional Information Resources

    The Lenovo Solution Center program enables you to troubleshoot and resolve computer problems. It combines diagnostic tests, system information collection, security status, and support information, along with hints and tips for maximum system performance. See “Lenovo ThinkVantage Toolbox” on page 35 for detailed information.

  • Page 38: Specifications, And 6590, And 6213

    Operating: -50 to 10 000 ft (-15.2 to 3 048 m) Non-operating: -50 to 35 000 ft (-15.2 to 10 668 m) Electrical input • Input voltage: – Low range: Minimum: 100 V ac Maximum: 127 V ac ThinkCentre Hardware Maintenance Manual...

  • Page 39

    Input frequency range: 50 to 60 Hz Voltage-selection switch setting: 115 V ac – High range: Minimum: 200 V ac Maximum: 240 V ac Input frequency range: 50 to 60 Hz Voltage-selection switch setting: 230 V ac Chapter 3 General information...

  • Page 40

    ThinkCentre Hardware Maintenance Manual...

  • Page 41: Chapter 4. General Checkout

    • If you receive an error, replace the part that the diagnostic program calls out or go to “Diagnostic error codes” on page 46. • If the test stops and you cannot continue, replace the last device tested. © Copyright Lenovo 2010, 2013...

  • Page 42: Problem Determination Tips

    6. Have the same diagnostic diskettes (version) 7. Have the same configuration options set in the system 8. Have the same setup for operating-system-controlled files Comparing the configuration and software set-up between “working and non-working” systems will often lead to problem resolution. ThinkCentre Hardware Maintenance Manual...

  • Page 43: Chapter 5. Diagnostics, Lenovo Thinkvantage Toolbox, Lenovo Solution Center

    4. If you are unable to isolate and repair the problem yourself after running the programs, save and print the log files created by the programs. You will need the log files when you speak to a Lenovo technical support representative.

  • Page 44: Lenovo System Toolbox, Pc-doctor For Rescue And Recovery, Pc-doctor For Dos

    Note: If you are unable to isolate and repair the problem yourself after running the program, save and print the log files created by the program. You will need the log files when you speak to a Lenovo technical support representative.

  • Page 45: Creating A Diagnostic Disc, Running The Diagnostic Program From A Diagnostic Disc

    To create a diagnostic disc, do the following: 1. Download a self-starting bootable CD/DVD image (known as an ISO image) of the diagnostic program from:http://www.lenovo.com/support 2. Use any CD/DVD burning software to create a diagnostic disc with the ISO image.

  • Page 46: Test Results

    • Performs all the steps in Quick Erase. • Provides a DOS utility that writes random data to all sectors of the hard disk drive. • Provides an estimate of time to completion along with a visual representation of completion status. ThinkCentre Hardware Maintenance Manual...

  • Page 47: Viewing The Test Log

    • Provides messages that warn the user about a non-recoverable process. Important: Make sure that all data is backed up before using the Quick or Full Erase functions. To select the Quick Erase Hard Drive or Full Erase Hard Drive utility, do the following: 1.

  • Page 48

    ThinkCentre Hardware Maintenance Manual...

  • Page 49: Program, Starting The Setup Utility Program, Viewing And Changing Settings, Using Passwords, Password Considerations

    • Have at least eight characters in length • Contain at least one alphabetic character and one numeric character • Setup Utility program and hard disk drive passwords are not case sensitive © Copyright Lenovo 2010, 2013...

  • Page 50: Power-on Password, Administrator Password, Hard Disk Password, Setting, Changing, And Deleting A Password

    When this option is set to Disable, the device connected to the External SATA connector cannot be accessed. To enable or disable a device, do the following: 1. Start the Setup Utility program. See “Starting the Setup Utility program” on page 41. ThinkCentre Hardware Maintenance Manual...

  • Page 51: Selecting A Startup Device, Selecting A Temporary Startup Device

    2. From the Setup Utility program main menu, select Devices. 3. Depending on the device you want to enable or disable, do one of the following: • Select USB Setup to enable or disable a USB device. • Select ATA Drive Setup to enable or disable an internal or external SATA device. 4.

  • Page 52

    ThinkCentre Hardware Maintenance Manual...

  • Page 53: Chapter 7. Symptom-to-fru Index, Hard Disk Drive Boot Error, Power Supply Problems

    1. Attempt to back-up the data on the failing hard disk drive. 2. Using the operating system programs, format the hard disk drive. The drive is defective. Replace the hard disk drive. Power Supply Problems If you suspect a power problem, use the following procedures. © Copyright Lenovo 2010, 2013...

  • Page 54: Diagnostic Error Codes

    1. Flash the system. See “Updating (flashing) BIOS from a disc” on page 392. 2. System board 000-036-XXX BIOS Register error 1. Flash the system. See “Updating (flashing) BIOS from a disc” on page 392. 2. System board ThinkCentre Hardware Maintenance Manual...

  • Page 55

    Diagnostic Error Code FRU/Action 000-038-XXX BIOS Extension failure 1. Flash the system. See “Updating (flashing) BIOS from a disc” on page 392. 2. Adapter card 3. System board 000-039-XXX BIOS DMI data error 1. Flash the system. See “Updating (flashing) BIOS from a disc”...

  • Page 56

    001-254-XXX 001-255-XXX 001-256-XXX 001-257-XXX System board System DMA error 001-260-XXX 001-264-XXX System IRQ error System board 001-268-XXX System IRQ1 failure 1. Device on IRQ1 2. System board 001-269-XXX System IRQ2 failure 1. Device on IRQ2 2. System board ThinkCentre Hardware Maintenance Manual...

  • Page 57

    Diagnostic Error Code FRU/Action 001-270-XXX System IRQ3 failure 1. Device on IRQ3 2. System board 001-271-XXX System IRQ4 failure 1. Device on IRQ4 2. System board 001-272-XXX System IRQ5 failure 1. Device on IRQ5 2. System board 001-273-XXX System IRQ6 (diskette drive) failure 1.

  • Page 58

    1. Make sure the component that is called out is connected and/or enabled. See “” on page . 2. Re-run the test. 3. Replace the component called out in warning statement. 4. Replace the component under test. ThinkCentre Hardware Maintenance Manual...

  • Page 59

    Diagnostic Error Code FRU/Action 005-198-XXX Video test aborted 1. If a component is called out, make sure it is connected and/or enabled. See “” on page . 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 392. 3.

  • Page 60

    1. PCI card 2. Information only Restart the test, if necessary. 018-196-XXX PCI Card test halt, error threshold exceeded 1. Press F3 to review the log file. 2. Restart the test to reset the log file. ThinkCentre Hardware Maintenance Manual...

  • Page 61

    Diagnostic Error Code FRU/Action 1. Make sure the component that is called out is 018-197-XXX PCI Card test warning connected and/or enabled. See “” on page . 2. Re-run the test. 3. Replace the component that is called out in warning statement.

  • Page 62

    3. Replace component under function test. 030-000-XXX SCSI interface Test Passed No action 030-00X-XXX 030-01X-XXX SCSI interface failure 1. SCSI signal cable 2. Check AC/DC power adapter 3. SCSI device 4. SCSI adapter card, if installed 5. System board ThinkCentre Hardware Maintenance Manual...

  • Page 63

    Diagnostic Error Code FRU/Action 030-027-XXX SCSI interface Configuration/Setup error 1. SCSI signal cable 2. Flash the system. See “Updating (flashing) BIOS from a disc” on page 392 3. SCSI device 4. SCSI adapter card, if installed 5. System board 030-03X-XXX 030-04X-XXX SCSI interface error 1.

  • Page 64

    071-25X-XXX Audio port failure 1. Speakers 2. Audio card, if installed 3. System board 080-000-XXX Game Port interface Test Passed No action 1. Remove the game port device and re-test the system. 080-XXX-XXX Game Port interface Error ThinkCentre Hardware Maintenance Manual...

  • Page 65

    Diagnostic Error Code FRU/Action 080-195-XXX Game Port interface Test aborted by user Information only Restart the test, if necessary. 080-196-XXX Game Port interface test halt, error 1. Press F3 to review the log file. threshold exceeded 2. Restart the test to reset the log file. 080-197-XXX Game Port interface test warning 1.

  • Page 66

    170-199-XXX Voltage Sensor(s) test failed, cause 1. See “Undetermined problems” on page 64. unknown 2. Flash the system and re-test. See “Updating (flashing) BIOS from a disc” on page 392. 3. Replace component under function test. ThinkCentre Hardware Maintenance Manual...

  • Page 67

    Diagnostic Error Code FRU/Action 170-250-XXX 170-251-XXX Voltage Sensor(s) Voltage 1. AC/DC power adapter limit error 2. System board 170-254-XXX Voltage Sensor(s) Voltage Regulator 1. Voltage Regulator Module (VRM) Module error 2. Microprocessor 3. System board 175-000-XXX Thermal Sensor(s) Test Passed No action 175-0XX-XXX Thermal Sensor(s) failure 1.

  • Page 68

    302-XXX-XXX Mouse error 1. Mouse 2. Check and test Keyboard 3. System board 303-000-XXX Joystick Test Passed No action 303-XXX-XXX Joystick error Remove the Joystick and re-test the system 305-000-XXX Monitor DDC Test Passed No action ThinkCentre Hardware Maintenance Manual...

  • Page 69: Beep Symptoms, Post Error Codes

    Diagnostic Error Code FRU/Action 305-250-XXX Monitor DDC self test failure 1. Run the Setup Utility program to enable DDC 2. Cable 3. Monitor 4. Video card 5. System board 415-000-XXXModem Test Passed No action 415-XXX-XXX Modem error Remove the Modem and re-test the system Beep symptoms Beep symptoms are tones or a series of tones separated by pauses (intervals without sound) during POST.

  • Page 70

    Press F10 to exit. 0662 Configuration change has occurred This error message is displayed when a floppy drive change has been made. Press F10 to exit. ThinkCentre Hardware Maintenance Manual...

  • Page 71: Miscellaneous Error Messages

    Error code POST error message Description/Action 1820 More than one external fingerprint If more than one external fingerprint reader is attached. Power off and reader is connected to a computer, remove all but the reader that you this error message will be displayed set up within your main operating to inform you to remove all of the system.

  • Page 72: Undetermined Problems

    1. Turn off the computer and the power. 2. Remove or disconnect the following components (if installed) one at a time. a. External devices (modem, printer, or mouse) b. Any adapter cards c. Memory modules d. Extended video memory ThinkCentre Hardware Maintenance Manual...

  • Page 73

    e. External Cache f. External Cache RAM g. Hard disk drive h. Diskette drive 3. Turn on the power and the computer to re-test the system. 4. Repeat steps 1 through 3 until you find the failing device or adapter cards. If all devices and adapter cards have been removed, and the problem continues, replace the system board.

  • Page 74

    ThinkCentre Hardware Maintenance Manual...

  • Page 75: Locating Connectors On The Front Of The Computer

    The following illustration shows the location of the connectors on the front of your computer. Note: Not all computer models will have the following connectors. Figure 1. Front connector locations USB connector Microphone connector Headphone connector USB connector © Copyright Lenovo 2010, 2013...

  • Page 76: Locating Connectors On The Rear Of The Computer, Removing The Computer Cover

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to:http://www.lenovo.com/support...

  • Page 77: Locating Components

    This section provides instructions on how to remove the computer cover. CAUTION: Turn off the computer and wait three to five minutes to let the computer cool before removing the computer cover. To remove the computer cover, do the following: 1.

  • Page 78: Locating Parts On The System Board

    Cover presence switch (also called intrusion switch) Rear system fan Optical drive Front bezel assembly Power supply Locating parts on the system board Figure 5 “System board parts locations” on page 71 shows the location of parts on the system board. ThinkCentre Hardware Maintenance Manual...

  • Page 79

    Figure 5. System board parts locations 4-pin power connector Front panel connector Microprocessor Clear CMOS (Complementary Metal Oxide Semiconductor) /Recovery jumper Microprocessor fan connector Front USB connectors (2) Memory slot 2 Serial (COM2) connector Memory slot 1 Front audio connector Memory slot 4 Internal speaker connector Memory slot 3...

  • Page 80: Removing And Reinstalling The Front Bezel

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 81: Replacing A Memory Module

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 82: Replacing The Power Supply Assembly

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 83: Replacing The Heat Sink And Fan Assembly

    Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy Chapter 8 Replacing FRUs (Machine Types: 3029, 3054, 3139, 3219, 3246, 3282, 3349, 3421, 3544, 3652, 3769, 3934,...

  • Page 84

    ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the heat sink and fan assembly. CAUTION: The heat sink and fan assembly might be very hot. Turn off the computer and wait three to five minutes to let the computer cool before removing the computer cover.

  • Page 85: Replacing The Microprocessor

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkStation Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkStation Safety and Warranty Guide, go to: http://www.lenovo.com/support This section provides instructions on how to replace the microprocessor. CAUTION: The heat sink and microprocessor might be very hot.

  • Page 86

    Touch only the sides of the microprocessor. Do not touch the gold contacts on the bottom. d. Do not drop anything onto the microprocessor socket while it is exposed. The socket pins must be kept as clean as possible. ThinkCentre Hardware Maintenance Manual...

  • Page 87: Replacing The System Board

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 88

    3. Note the orientation of the socket cover. Align the notches of the microprocessor socket cover with the alignment keys of the microprocessor socket. 4. Install one side of the socket cover into the microprocessor socket as shown. ThinkCentre Hardware Maintenance Manual...

  • Page 89: Replacing The Battery

    Attention Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy Chapter 8 Replacing FRUs (Machine Types: 3029, 3054, 3139, 3219, 3246, 3282, 3349, 3421, 3544, 3652, 3769, 3934,...

  • Page 90

    If the battery fails, the date, time, and configuration information (including passwords) are lost. An error message is displayed when you turn on the computer. Refer to the “Lithium battery notice” in the ThinkCentre Safety and Warranty Guide for information about replacing and disposing of the battery.

  • Page 91: Replacing A Pci Card

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 92

    Note: If you are installing a PCI Express x16 graphics card, make sure the memory slot retaining clips are closed before you install the graphics card. 7. Pivot the card latch to the closed position to secure the PCI card. ThinkCentre Hardware Maintenance Manual...

  • Page 93: Replacing The Primary Hard Disk Drive

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 94

    12. Connect the signal cable and the power cable to the new hard disk drive. 13. Press down on the metal latch and pivot the drive cage into place, and then slide it to the front of the computer until it snaps into position. ThinkCentre Hardware Maintenance Manual...

  • Page 95: Replacing The Secondary Hard Disk Drive

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 96

    10. Slide the new hard disk drive into the hard disk drive cage until it snaps into position. 11. Install the hard disk drive cage into the chassis until it snaps into position underneath the metal tab. Make sure that the hard disk drive cage release button is secured in the chassis. ThinkCentre Hardware Maintenance Manual...

  • Page 97: Replacing The Optical Drive

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 98

    5. Install the optical drive retainer on the side of the new optical drive. Figure 27. Installing the optical drive retainer 6. Slide the new optical drive into the drive bay from the front of the computer until the optical drive snaps into position. ThinkCentre Hardware Maintenance Manual...

  • Page 99: Replacing The Front Fan Assembly

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 100

    6. Insert the two tabs of the new front fan assembly into the corresponding holes in the chassis, and press the other two tabs through the holes until the front fan assembly is secured in place. ThinkCentre Hardware Maintenance Manual...

  • Page 101: Replacing The Rear Fan Assembly

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 102

    Note: The new rear fan assembly you received will have four new rubber mounts attached. 7. Pull on the tips of the rubber mounts until the rear fan assembly is secured in place. ThinkCentre Hardware Maintenance Manual...

  • Page 103: Replacing The Front Audio And Usb Assembly

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 104: Replacing The Internal Speaker

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 105

    3. Locate the internal speaker connector on the system board. See “Locating parts on the system board” on page 70. 4. Disconnect the internal speaker cable from the system board. 5. Push the metal tab on the top of the internal speaker outward and slide the internal speaker upward to completely remove it from the chassis.

  • Page 106: Completing The Parts Replacement

    4. Position the computer cover on the chassis so that the rail guides on the bottom of the computer cover engage the rails on the chassis. Then, push the cover to the front of the computer until it snaps into position. ThinkCentre Hardware Maintenance Manual...

  • Page 107

    Figure 37. Reinstalling the computer cover 5. If the computer cover is secured with thumbscrews, install them. 6. Reconnect the external cables and power cords to the computer. See “Locating connectors on the rear of the computer” on page 68. Chapter 8 Replacing FRUs (Machine Types: 3029, 3054, 3139, 3219, 3246, 3282, 3349, 3421, 3544, 3652, 3769, 3934, 4992, 5206, 5267, 5325, 5384, 5450, 5474, 5498, 5554, 5852, 6232, and 6590.)

  • Page 108

    ThinkCentre Hardware Maintenance Manual...

  • Page 109

    Rear connector locations shows the location of connectors on the rear of the computer. Some connectors on the rear of the computer are color-coded to help you determine where to connect the cables on your computer. © Copyright Lenovo 2010, 2013...

  • Page 110: Opening The Computer Cover

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to:http://www.lenovo.com/support This section provides instructions on how to open the computer cover.

  • Page 111

    To open the computer cover, do the following: 1. Remove any media from the drives and turn off all attached devices and the computer. 2. Disconnect all power cords from electrical outlets. 3. Disconnect the power cords, Input/Output (I/O) cables, and any other cables that are connected to the computer.

  • Page 112

    Internal speaker (installed in some models) Power supply assembly System fan assembly Locating parts on the system board Figure 42 “System board parts locations” on page 105 shows the locations of the parts on the system board. ThinkCentre Hardware Maintenance Manual...

  • Page 113

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 114

    If the battery fails, the date, time, and configuration information (including passwords) are lost. An error message is displayed when you turn on the computer. Refer to the “Lithium battery notice” in the ThinkCentre Safety and Warranty Guide for information about replacing and disposing of the battery.

  • Page 115

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 116

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 117

    3. Rotate the PCI card retainer to the open position. 4. If you are installing a PCI card, remove the appropriate metal slot cover. If you are replacing an old PCI card, grasp the old card that is currently installed and gently pull it out of the slot. Figure 48.

  • Page 118

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 119

    Figure 50. Removing the retaining screws for the power supply assembly 4. Open the computer cover. See “Opening the computer cover” on page 102. 5. Pivot the optical drive bay assembly upward to gain access to the power supply assembly. 6.

  • Page 120: Replacing The Heat Sink

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 121

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 122

    Note the orientation of the microprocessor in the socket. You can either look for the small triangle on one corner of the microprocessor or note the orientation of the notches on the microprocessor. This is important when installing the new microprocessor on the system board. ThinkCentre Hardware Maintenance Manual...

  • Page 123

    c. Touch only the sides of the microprocessor. Do not touch the gold contacts on the bottom. d. Do not drop anything onto the microprocessor socket while it is exposed. The socket pins must be kept as clean as possible. Figure 55.

  • Page 124

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 125

    The failing system board must be returned with a microprocessor socket cover to protect the pins during shipping and handling. To install the microprocessor socket cover, do the following: 1. Release the lever securing the microprocessor retainer and open the retainer to access the microprocessor.

  • Page 126: Replacing The Hard Disk Drive

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 127

    6. Disconnect the signal cable and the power cable from the hard disk drive to completely remove the hard disk drive from the chassis. 7. Flex the sides of the bracket to remove the hard disk drive from the bracket. 8.

  • Page 128

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 129

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 130

    See “Locating parts on the system board” on page 104. 7. Push the two tabs on the bottom of the internal speaker as shown to release the internal speaker, and then lift the internal speaker up to completely remove it from the chassis. ThinkCentre Hardware Maintenance Manual...

  • Page 131

    Figure 65. Removing the internal speaker 8. Remove the attached thermal sensor cable from the old internal speaker and install it on the new internal speaker. 9. Insert the two tabs on the bottom of the new internal speaker into the corresponding holes in the chassis, and push the speaker straight down until the other two tabs snap into position.

  • Page 132

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 133: Replacing The System Fan

    Do not open your computer or attempt any repair before reading and understanding the “Important safety information” in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre Safety and Warranty Guide, go to: http://www.lenovo.com/support...

  • Page 134

    “Locating parts on the system board” on page 104. 7. Release the four tabs on the bottom of the system fan as shown, and then lift the system fan straight up to completely remove it from the chassis. ThinkCentre Hardware Maintenance Manual...

  • Page 135

    Figure 69. Removing the system fan 8. Align the four tabs on the bottom of the new system fan with the corresponding holes in the chassis, and push the new system fan straight down until it snaps into position. 9. Connect the system fan cable to the microprocessor fan connector on the system board. See “Locating parts on the system board”...

  • Page 136

    4. Lower the optical drive bay assembly. 5. Close the computer cover. 6. Reconnect the external cables and power cords to the computer. See “Locating connectors on the rear of the computer” on page 101. ThinkCentre Hardware Maintenance Manual...

  • Page 137: Chapter 10. Fru Lists, And 6590

    The following replaceable components are available for the 3029, 3054, 3139, 3219, 3246, 3282, 3349, 3421, 3544, 3652, 3769, 3934, 4992, 5206, 5267, 5325, 5384, 5450, 5474, 5498, 5554, 5852, 6232, and 6590 machine type models. © Copyright Lenovo 2010, 2013...

  • Page 138

    A3Y A3G A5U A5F A5S A5P A5D A5Y D1Q D6V D7V F3M F4M • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 139

    Item # FRUs FRU # Microprocessor, Clarkdale Core i3-540 3.06G 1333MHz 4T\Dual core\4M\73W LGA 1156 (Gfx core speed 733MHz ) • MT 3246: B5G • MT 3282: • MT 3544: A4G • MT 3652: 71Y5304 • MT 5474: F8U F8F F8L G1V G2V •...

  • Page 140

    • MT 3282: • MT 3544: • MT 3652: 71Y5306 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 141

    Item # FRUs FRU # Microprocessor, Lynnfield Quad Core i7-870 2.93G 1333MHz 8T\4 core\8M\95W\Turbo LGA 1156 • MT 3246: • MT 3282: B3U B3F B3S • MT 3544: • MT 3652: 71Y5307 • MT 5474: • MT 5498: • MT 5554: •...

  • Page 142

    • MT 3282: • MT 3544: • MT 3652: 03T6010 • MT 5474: G5M • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 143

    Item # FRUs FRU # Microprocessor, Pentium G6960 2.93G 1066MHz Dual core\3M\73W LGA 1156 (Gfx core speed 533MHz ) • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T9021 • MT 5474: G7M • MT 5498: • MT 5554: •...

  • Page 144

    • MT 3282: • MT 3544: • MT 3652: 89Y9224 • MT 5474: F7M • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 145

    Item # FRUs FRU # Optical drive, DVD-ROM Drive - 16x/48x - SATA • MT 3246: A6V • MT 3282: A5V A7V • MT 3544: • MT 3652: 71Y5543 • MT 5474: B1J A1U A1F A1S A1P A1D A1Y D3J D6V D8V •...

  • Page 146

    • MT 3282: • MT 3544: • MT 3652: 53Y6837 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 147

    Item # FRUs FRU # Hard disk drive, SATA 250GB 7200RPM / 3Gb / 8M • MT 3246: A1U A1F A1S A1P A1D A1Y A2U A2F A2S A2P A2D A2Y B1U B1F B1S • MT 3282: • MT 3544: A1G A3G •...

  • Page 148

    • MT 5498: B3G B4G B7G B8G A7M A8J A9J A2U A2F A2S A2P A2D A2Y A3U A3F A3S A3P A3D A3Y E5J E6J E7U E7F E7S E7Y E8U E8F E8S E8Y E1V E3V F3M F5M F6M • MT 5554: • MT 5852: ThinkCentre Hardware Maintenance Manual...

  • Page 149

    Item # FRUs FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Hard disk drive, SATA 1TB 7200RPM / 3Gb / 32M • MT 3246: • MT 3282: • MT 3544: • MT 3652: 45C5973 •...

  • Page 150

    A4P A4D A4Y A4A A4T E5J E6J E7U E7F E7S E7Y E8U E8F E8S E8Y E9U E9F E9S E9Y B9V E1V E2V E3V E4V F1M F2M F3M F4M F5M F6M F7M F8V F9M • MT 5554: A1G ThinkCentre Hardware Maintenance Manual...

  • Page 151

    Item # FRUs FRU # • MT 5852: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1CA1B A1H A1V A1K A1R A1E A1J • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB C2 intrusion switch •...

  • Page 152

    F3M F4M F5M F6M F8U F8F F8L F7M G1V G2V G4P G5M G6U G6F G6S G7M • MT 5498: A8J A9J E5J E6J B9V E1V E2V E3V E4V F1M F2M F3M F4M F5M F6M F7M F8V F9M ThinkCentre Hardware Maintenance Manual...

  • Page 153: Mechanical Frus

    Item # FRUs FRU # • MT 5554: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J • MT 5852: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1B A1H A1V A1K A1R A1E A1J •...

  • Page 154

    • MT 3652: all models 41R3308 • MT 5474: all models • MT 5498: all models • MT 5554: all models • MT 5852: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 155

    FRUs FRU # Parallel cable 280mm ROHS (optional) • MT 3246: all models • MT 3282: all models • MT 3544: all models • MT 3652: all models 43N9022 • MT 5474: all models • MT 5498: all models • MT 5554: all models •...

  • Page 156

    • MT 3652: all models 45J9573 • MT 5474: all models • MT 5498: all models • MT 5554: all models • MT 5852: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 157

    FRUs FRU # PS2 cable_R_170mm_knockout (with screw) • MT 3246: all models • MT 3282: all models • MT 3544: all models • MT 3652: all models 43N9149 • MT 5474: all models • MT 5498: all models • MT 5554: all models •...

  • Page 158

    • MT 3652: all models 45K6260 • MT 5474: all models • MT 5498: all models • MT 5554: all models • MT 5852: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 159

    FRUs FRU # FRU, FDD/card reader cover • MT 3246: all models • MT 3282: all models • MT 3544: all models • MT 3652: all models 45K6262 • MT 5474: all models • MT 5498: all models • MT 5554: all models •...

  • Page 160

    • MT 3652: all models 45K6368 • MT 5474: all models • MT 5498: all models • MT 5554: all models • MT 5852: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 161

    FRUs FRU # FRU, cable clip FCW-29 • MT 3246: all models • MT 3282: all models • MT 3544: all models • MT 3652: all models 45K6365 • MT 5474: all models • MT 5498: all models • MT 5554: all models •...

  • Page 162: Keyboard And Mouse

    • MT 5852: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Keyboard and Mouse Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # US English • MT 3246: A3Q A1U A2U A5Q A9U A6V A7V A8V B3G B5G B6G B7Q B8G B9U •...

  • Page 163

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3246: • MT 3282: • MT 3544: A1G A2G A3G A4G • MT 3652: A1G A2G A3G A4G A5G 41A5291 • MT 5474: B2G B3G A2G A3G • MT 5498: B1G B2G B3G B4G B5G B6G B7G B8G A1G •...

  • Page 164

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Bulgarian • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: A1G A2G A3G A4G •...

  • Page 165

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Danish • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: A1G A2G A3G A4G • MT 3652: A1G A2G A3G A4G A5G 41A5298 •...

  • Page 166

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB French Canadian • MT 3246: A1F A2F A9F B9F • MT 3282: A1F A2F B1F A8F B3F B6F •...

  • Page 167

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Greek/US • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: A1G A2G A3G A4G • MT 3652: A1G A2G A3G A4G A5G 41A5305 •...

  • Page 168

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Italy • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: A1G A2G A3G A4G •...

  • Page 169

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # LA Spanish • MT 3246: A1S A1D A1Y A2S A2D A2Y B9S • MT 3282: A1S A1D A1Y A2S A2D A2Y B1S A8S B3S B6S • MT 3544: • MT 3652: •...

  • Page 170

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Portuguese • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: A1G A2G A3G A4G • MT 3652: A1G A2G A3G A4G A5G 41A5315 •...

  • Page 171

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Serbian/Cyrillic • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: A1G A2G A3G A4G •...

  • Page 172

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Swedish/Finnish • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: A1G A2G A3G A4G • MT 3652: A1G A2G A3G A4G A5G 41A5322 •...

  • Page 173

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Turkish • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: A1G A2G A3G A4G •...

  • Page 174

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Slovenian • MT 3246: B3G B5G B6G B8G • MT 3282: A9G B2G B4G B5G • MT 3544: • MT 3652: 41A5329 • MT 5474: • MT 5498: • MT 5554: A1G •...

  • Page 175

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--US English • MT 3246: • MT 3282: •...

  • Page 176

    • MT 3282: • MT 3544: • MT 3652: 41A5045 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 177

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--Chinese/US • MT 3246: • MT 3282: • MT 3544: • MT 3652: 41A5046 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--Czech (ABB) •...

  • Page 178

    • MT 3282: • MT 3544: • MT 3652: 41A5053 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 179

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--Greek • MT 3246: • MT 3282: • MT 3544: • MT 3652: 41A5054 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--Greek/US •...

  • Page 180

    • MT 3282: • MT 3544: • MT 3652: 41A5060 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 181

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--LA Spanish • MT 3246: • MT 3282: • MT 3544: • MT 3652: 41A5061 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--Norwegian •...

  • Page 182

    • MT 3282: • MT 3544: • MT 3652: 41A5068 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 183

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--Spanish • MT 3246: • MT 3282: • MT 3544: • MT 3652: 41A5069 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--Swedish/Finnish •...

  • Page 184

    • MT 3282: • MT 3544: • MT 3652: 41A5076 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 185

    • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Keyboard (Lenovo Fingerprint Reader USB) FRU # US English • MT 3246: • MT 3282: •...

  • Page 186

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8003 • MT 5474: • MT 5498: •...

  • Page 187

    Keyboard (Lenovo Fingerprint Reader USB) FRU # Brazilian Portuguese • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8006 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 188

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Danish • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8010 • MT 5474: • MT 5498: •...

  • Page 189

    Keyboard (Lenovo Fingerprint Reader USB) FRU # French Canadian • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8013 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 190

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Greek/US • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8017 • MT 5474: • MT 5498: •...

  • Page 191

    Keyboard (Lenovo Fingerprint Reader USB) FRU # Iceland • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8020 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 192

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB LA Spanish • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8024 • MT 5474: • MT 5498: •...

  • Page 193

    Keyboard (Lenovo Fingerprint Reader USB) FRU # Portuguese • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8027 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 194

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Serbian/Cyrillic • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8040 • MT 5474: • MT 5498: •...

  • Page 195

    Keyboard (Lenovo Fingerprint Reader USB) FRU # Swedish/Finnish • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8031 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 196

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Turkish • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03X8034 • MT 5474: • MT 5498: •...

  • Page 197

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Mice FRU # Optical wheel mouse (400DPI, USB) • MT 3246: A3Q A3H A4H A1U A1F A1S A1P A1D A1Y A2U A2F A2S A2P A2D...

  • Page 198

    A3F A3S A3P A3D A3Y A4U A4F A4S A4P A4D A4Y A4A A4T E5J E6J E7U E7F E7S E7Y E8U E8F E8S E8Y E9U E9F E9S E9Y B9V E1V E2V E3V E4V F1M F2M F3M F4M F5M F6M F7M F8V F9M ThinkCentre Hardware Maintenance Manual...

  • Page 199

    Mice FRU # • MT 5554: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J • MT 5852: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J •...

  • Page 200: Adapters And Miscellaneous Frus

    • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Speakers (2-piece) Lenovo Logo (secondary) • MT 3246: • MT 3282: • MT 3544: • MT 3652: 41A5334 •...

  • Page 201

    Adapters & miscellaneous FRUs FRU # Speaker power brick - US, Canada, LA low voltage, ASEAN • MT 3246: A1U A1S A2U A2S A9U • MT 3282: A1U A1S A2U A2S B1U B1S A8U A8S • MT 3544: • MT 3652: •...

  • Page 202

    • MT 3282: • MT 3544: • MT 3652: 40Y7611 • MT 5474: • MT 5498: E5J E6J • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 203

    Adapters & miscellaneous FRUs FRU # NVIDIA Quadro FX380 (DVI + DP) ATX • MT 3246: • MT 3282: • MT 3544: • MT 3652: 64Y8204 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB NVDIA GeForce NVS310 512MB DDR3 (VGA+DP) HP •...

  • Page 204: Power Cords

    • MT 5852: A1U A1F A1S A1L A1Y A1A • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Line Cord - China • MT 3246: 41R3256 • MT 3282: • MT 3544: ThinkCentre Hardware Maintenance Manual...

  • Page 205

    Power Cords --primary FRU # • MT 3652: • MT 5474: • MT 5498: • MT 5554: A1C • MT 5852: A1C • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Line Cord - Japan •...

  • Page 206

    • MT 3652: 41R3224 • MT 5474: • MT 5498: • MT 5554: A1G A1A A1B A1H • MT 5852: A1H A1B • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 207

    Power Cords --primary FRU # Line Cord - Taiwan • MT 3246: A6V A7V A8V • MT 3282: A4V A5V A6V A7V • MT 3544: • MT 3652: 41R3278 • MT 5474: G1V G2V • MT 5498: F8V • MT 5554: A1V •...

  • Page 208

    • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Line Cord - India • MT 3246: A3Q A5Q B7Q • MT 3282: • MT 3544: 41R3341 • MT 3652: • MT 5474: D1Q • MT 5498: • MT 5554: A1Q • MT 5852: A1Q ThinkCentre Hardware Maintenance Manual...

  • Page 209

    Power Cords --primary FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Line Cord - Austria, Belgium, Croatia, Czechoslovakia, Finland, France, Germany, Hungary, Netherlands, Norway, Poland, Portugal, Romania, Spain, Sweden • MT 3246: A1U A1F A1S A1Y A2U A2F A2S A2Y A9U A9F B4U B4F B4S B1U B1F B1S B2U B2F B2S •...

  • Page 210

    • MT 3544: • MT 3652: 41R3249 • MT 5474: • MT 5498: • MT 5554: A1J A1E • MT 5852: A1J • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 211

    Power Cords --secondary FRU # Line Cord - Brazil • MT 3246: • MT 3282: • MT 3544: • MT 3652: 41R3271 • MT 5474: A1P A2P A3P A4P A5P D4P D5P G4P • MT 5498: • MT 5554: A1P •...

  • Page 212

    • MT 3544: • MT 3652: 41R3233 • MT 5474: • MT 5498: • MT 5554: A1S A1Y A1L A1G • MT 5852: A1G • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 213

    Power Cords --secondary FRU # Line Cord - Indonesia, Laos, Cambodia, and Vietnam A models • MT 3246: • MT 3282: • MT 3544: • MT 3652: 41R3209 • MT 5474: • MT 5498: • MT 5554: • MT 5852: A1G •...

  • Page 214

    E7Y E8U E8F E8S E8Y E9U E9F E9S E9Y • MT 5554: A1A • MT 5852: A1U A1F A1S A1L A1Y A1A A1T • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 215: Recovery Discs, Windows Vista Home Basic 32 Recovery Cd

    Power Cords --secondary FRU # Line Cord- UK, Ireland • MT 3246: • MT 3282: • MT 3544: A1G A2G A3G A4G • MT 3652: 41R3225 • MT 5474: • MT 5498: • MT 5554: A1B A1H • MT 5852: A1G •...

  • Page 216: Windows Vista Home Basic 32 With Ie9 Recovery Cd

    FRU # US English • MT 3246: CTO • MT 3282: CTO • MT 3544: CTO 03T1582 • MT 3652: CTO • MT 5474: CTO • MT 5498: CTO • MT 5554: CTO • MT 5852: CTO ThinkCentre Hardware Maintenance Manual...

  • Page 217: Windows Vista Business 32 Recovery Cd

    Windows Vista Home Basic 32 with IE9 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB India English • MT 3246: CTO • MT 3282: CTO • MT 3544: CTO • MT 3652: CTO 03T1581 •...

  • Page 218

    • MT 3544: CTO • MT 3652: CTO 03T5079 • MT 5474: CTO • MT 5498: CTO • MT 5554: CTO • MT 5852: CTO • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 219

    Windows Vista Business 32 FRU # Italy • MT 3246: CTO • MT 3282: CTO • MT 3544: CTO • MT 3652: CTO 03T5080 • MT 5474: CTO • MT 5498: CTO • MT 5554: CTO • MT 5852: CTO •...

  • Page 220: Ie9 Recovery Cd

    • MT 3544: CTO • MT 3652: CTO 03T1576 • MT 5474: CTO • MT 5498: CTO • MT 5554: CTO • MT 5852: CTO • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 221

    Windows Vista Business 32 Recovery CD with IE9 FRU # Italy • MT 3246: CTO • MT 3282: CTO • MT 3544: CTO • MT 3652: CTO 03T1577 • MT 5474: CTO • MT 5498: CTO • MT 5554: CTO •...

  • Page 222: Windows 7 Home Basic 32 Recovery Cd

    • MT 3282: • MT 3544: • MT 3652: 03T5121 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 223

    Windows 7 Home Basic 32 FRU # Russian • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T5120 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Russian English •...

  • Page 224

    • MT 3282: • MT 3544: • MT 3652: 03T5117 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 225: Windows 7 Home Basic 32 Sp1 Recovery Cd

    Windows 7 Home Basic 32 SP1 Recovery CD Windows 7 Home Basic 32 SP1 FRU # Arabic Localized • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T1610 • MT 5474: • MT 5498: • MT 5554: •...

  • Page 226

    • MT 3282: • MT 3544: • MT 3652: 03T1617 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 227: Windows 7 Home Premium 32 Recovery Cd

    Windows 7 Home Basic 32 SP1 FRU # Turkish • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T1618 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB English •...

  • Page 228

    • MT 3282: • MT 3544: • MT 3652: 03T5134 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 229

    Windows 7 Home Premium 32 FRU # Romanian • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T5135 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Hebrew •...

  • Page 230

    • MT 3652: 03T5138 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB C&L2 EMEA: NL/FR/GR/IT/EN 03T5139 • MT 3246: ThinkCentre Hardware Maintenance Manual...

  • Page 231

    Windows 7 Home Premium 32 FRU # • MT 3282: • MT 3544: • MT 3652: • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Windows 7 Home Premium 32 SP1 Recovery CD Windows 7 Home Premium 32 SP1 FRU #...

  • Page 232

    • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Hebrew • MT 3246: • MT 3282: • MT 3544: 03T1625 • MT 3652: • MT 5474: • MT 5498: • MT 5554: • MT 5852: ThinkCentre Hardware Maintenance Manual...

  • Page 233

    Windows 7 Home Premium 32 SP1 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Hong Kong • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T1626 • MT 5474: •...

  • Page 234

    • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB C&L1 Nordics: DK/FI/SV/NO/EN • MT 3246: • MT 3282: • MT 3544: 03T1632 • MT 3652: • MT 5474: • MT 5498: • MT 5554: • MT 5852: ThinkCentre Hardware Maintenance Manual...

  • Page 235: Windows 7 Professional 32 Recovery Cd

    Windows 7 Home Premium 32 SP1 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB C&L2 EMEA: NL/FR/GR/IT/EN • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T1633 • MT 5474: •...

  • Page 236

    • MT 3652: 89Y0556 • MT 5474: B2G B3G • MT 5498: B4G B5G • MT 5554: A1G • MT 5852: A1G • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 237

    Windows 7 Professional 32 FRU # Czech • MT 3246: B3G B6G • MT 3282: A9G B4G • MT 3544: B2G B3G A2G A3G A4G • MT 3652: A1G A2G A3G A4G A5G 03T5091 • MT 5474: B2G B3G • MT 5498: B4G B5G •...

  • Page 238

    • MT 3282: • MT 3544: • MT 3652: 03T5101 • MT 5474: • MT 5498: • MT 5554: A1K • MT 5852: A1R • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 239

    Windows 7 Professional 32 FRU # Slovenian • MT 3246: B3G B6G • MT 3282: A9G B4G • MT 3544: • MT 3652: 03T5108 • MT 5474: B2G B3G • MT 5498: • MT 5554: A1G • MT 5852: A1G •...

  • Page 240

    • MT 3544: • MT 3652: 03T5090 • MT 5474: G1V G2V • MT 5498: F8V • MT 5554: A1V • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 241

    Windows 7 Professional 32 FRU # India English • MT 3246: A3Q A5Q • MT 3282: • MT 3544: • MT 3652: 03T5092 • MT 5474: D1Q • MT 5498: • MT 5554: A1G • MT 5852: A1Q • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Hong Kong •...

  • Page 242

    • MT 3652: A1G A2G A3G A4G A5G 03T5114 • MT 5474: B2G B3G • MT 5498: B4G B5G • MT 5554: A1G • MT 5852: A1G • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 243: Windows 7 Professional 32 Sp1 Recovery Cd

    Windows 7 Professional 32 SP1 Recovery CD Windows 7 Professional 32 SP1 FRU # US English • MT 3246: A6V A7V A8V B3G B1U B1S B2U B2F B2S B6G B7Q • MT 3282: A1U A2U A9G A8U B4G • MT 3544: A1U A2U A9G A8U B4G •...

  • Page 244

    • MT 3282: A9G B4G • MT 3544: A9G B4G 03T1598 • MT 3652: A1G A2G A3G A4G A5G • MT 5474: B2G B3G • MT 5498: B4G B5G • MT 5554: • MT 5852: A1G ThinkCentre Hardware Maintenance Manual...

  • Page 245

    Windows 7 Professional 32 SP1 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Russian • MT 3246: B3G B6G • MT 3282: A9G B4G • MT 3544: A9G B4G • MT 3652: A1G A2G A3G A4G A5G 03T1601 •...

  • Page 246

    • MT 3282: A9G B4G • MT 3544: A9G B4G 03T1603 • MT 3652: A1G A2G A3G A4G A5G • MT 5474: B2G B3G • MT 5498: B4G B5G • MT 5554: • MT 5852: A1G ThinkCentre Hardware Maintenance Manual...

  • Page 247

    Windows 7 Professional 32 SP1 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Russian English • MT 3246: B3G B6G • MT 3282: A9G B4G • MT 3544: A9G B4G • MT 3652: A1G A2G A3G A4G A5G 03T1599 •...

  • Page 248

    • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Traditional Chinese • MT 3246: A3Q A5Q • MT 3282: • MT 3544: 03T1586 • MT 3652: • MT 5474: D1Q • MT 5498: • MT 5554: • MT 5852: A1Q ThinkCentre Hardware Maintenance Manual...

  • Page 249

    Windows 7 Professional 32 SP1 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB India English • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T1588 • MT 5474: • MT 5498: •...

  • Page 250

    • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Japanese • MT 3246: • MT 3282: • MT 3544: 03T2102 • MT 3652: • MT 5474: • MT 5498: • MT 5554: • MT 5852: ThinkCentre Hardware Maintenance Manual...

  • Page 251: Windows 7 Professional 64 Recovery Cd

    Windows 7 Professional 32 SP1 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Windows 7 Professional 64 Recovery CD Windows 7 Professional 64 FRU # US English • MT 3246: B4U B5G B8G B9U •...

  • Page 252

    • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Traditional Chinese • MT 3246: • MT 3282: • MT 3544: 03T5142 • MT 3652: • MT 5474: • MT 5498: • MT 5554: • MT 5852: ThinkCentre Hardware Maintenance Manual...

  • Page 253

    Windows 7 Professional 64 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Czech • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T5143 • MT 5474: • MT 5498: •...

  • Page 254

    • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB C&L2 EMEA: NL/FR/GR/IT/EN • MT 3246: B5G B8G • MT 3282: B2G B5G • MT 3544: 03T5153 • MT 3652: • MT 5474: • MT 5498: • MT 5554: • MT 5852: ThinkCentre Hardware Maintenance Manual...

  • Page 255: Windows 7 Professional 64 Sp1 Recovery Cd

    Windows 7 Professional 64 FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Hebrew • MT 3246: B5G B8G • MT 3282: B2G B5G • MT 3544: • MT 3652: 03T0696 • MT 5474: •...

  • Page 256

    • MT 3282: B2G B5G • MT 3544: • MT 3652: 03T1638 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 257

    French • MT 3246: B4F B5G B8G B9F • MT 3282: • MT 3544: • MT 3652: 03T1639 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB German •...

  • Page 258

    • MT 3282: B2G B5G • MT 3544: • MT 3652: 03T1646 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 259: Windows 7 Ultimate 32 Recovery Cd

    Hebrew • MT 3246: B5G B8G • MT 3282: B2G B5G • MT 3544: • MT 3652: 03T1647 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Portuguese •...

  • Page 260: Windows 7 Ultimate 64 Recovery Cd, Windows 7 Starter 32 Recovery Cd

    Windows 7 Starter 32 Recovery CD Windows 7 Starter 32 FRU # US English • MT 3246: • MT 3282: • MT 3544: 03T1651 • MT 3652: • MT 5474: • MT 5498: • MT 5554: ThinkCentre Hardware Maintenance Manual...

  • Page 261: Windows Xp Professional Recovery Cd

    Windows 7 Starter 32 FRU # • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Windows XP Professional Recovery CD Note: The Windows XP Professional recovery DVDs are available only for models with a valid Microsoft Windows XP Professional certificate of authenticity (COA) affixed to the system.

  • Page 262

    • MT 3282: • MT 3544: • MT 3652: 03T5060 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 263

    Windows XP Professional FRU # Polish • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T5066 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Portuguese •...

  • Page 264

    • MT 3282: • MT 3544: • MT 3652: 03T5064 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 265

    Windows XP Professional FRU # Simplified Chinese • MT 3246: • MT 3282: • MT 3544: • MT 3652: 03T5054 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Hong Kong Traditional Chinese •...

  • Page 266

    • MT 3544: • MT 3652: 03T5055 • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Slovenian 03T5070 • MT 3246: ThinkCentre Hardware Maintenance Manual...

  • Page 267: And 6213

    Windows XP Professional FRU # • MT 3282: • MT 3544: • MT 3652: • MT 5474: • MT 5498: • MT 5554: • MT 5852: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325,_SB Overall: 3026, 3039, 3137, 3149, 3245, 3269, 3319, 3394, 3491, 3627, 3699, 3878, 4972, 5132, 5261, 5297, 5391, 5472, 5485, 5536, 5548, 5567, 5864, and 6213.

  • Page 268

    A1D A1Y A2U A2F A2S A2P A2D A2Y E1J E2J E3U E3F E3S E3P E3Y D5V D6V F1M J5J J6J • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 269

    Item # FRUs FRU # Microprocessor, Clarkdale Core i3-530 2.93G 1333MHz 4T\Dual core\4M\73W LGA 1156 (Gfx core speed 733MHz ) • MT 3245: A3H A4H A1U A1F A1S A1P A1D A1Y A5V A6V B2G B3U B3S B3S A9U A9F A9S B5G •...

  • Page 270

    • MT 5485: B8G A4U A4F A4S A4P A4D A4Y E4U E4F E4S E4P E4Y D7V F9M J1M J2M J3M • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 271

    Item # FRUs FRU # Microprocessor, Lynnfield Quad Core i7-860 2.80G 1333MHz 8T\4 core\8M\95W\Turbo LGA 1156 • MT 3245: • MT 3269: • MT 3491: • MT 3627: 71Y5306 • MT 5485: • MT 5536: • MT 5567: • MT 5864: •...

  • Page 272

    • MT 3269: • MT 3491: • MT 3627: 03T7035 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 273

    Item # FRUs FRU # Microprocessor, Lynnfield LGA1156 i5-760 2.8GHz \ 1333MHz \ Quad Core \ 8M \ 95w B-1 stepping • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T6010 • MT 5485: K7M • MT 5536: •...

  • Page 274

    H5M H6M H7M H8M H9M J1M J2M J3M J4M J5M J6M J7M J8M J9M K1G K2J K3J K4V K6M K5S K5D K5Y K8P • MT 5567: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J ThinkCentre Hardware Maintenance Manual...

  • Page 275

    Item # FRUs FRU # • MT 5864: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1B A1H A1V A1K A1R A1E A1J • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Memory module, 4GB PC3-10600 1333MHz DDR3 UDIMM •...

  • Page 276

    • MT 3627: all models 45K6328 • MT 5485: all models • MT 5536: all models • MT 5567: all models • MT 5864: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 277

    Item # FRUs FRU # Hard disk drive, SATA 160GB 7200RPM / 3Gb / 8M • MT 3245: • MT 3269: • MT 3491: • MT 3627: 40Y9035 • MT 5485: • MT 5536: • MT 5567: • MT 5864: •...

  • Page 278

    • MT 5536: B2G A8J A9J B6J B7J B3V B5V F1M F2M F7M F8M F9M H1M H4M H7M H8M J7M J8M J9M K1G K2J K3J K6M K8P • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 279

    Item # FRUs FRU # Hard disk drive, SATA 500GB 7200RPM / 3Gb / 16M • MT 3245: A8U A8F A6V B1U B1F B1S B4G • MT 3269: A1U A1F A1S A1P A1D A1Y A2U A2F A2S A2P A2D A2Y A4H A4V A7G A6U A6F A6S A9G B3S B3D B3Y B2G B1U B1F B1S B4G B5U B5F B5S •...

  • Page 280

    • MT 5485: B9A B9T D1A D1T B2G B2A B2T B3G B4G B5G B6G B7G B8G A8M A9J B1J A1U A1F A1S A1P A1D A1Y A2U A2F A2S A2P A2D A2Y A3U A3F A3S A3P A3D A3Y A4U A4F A4S A4P A4D ThinkCentre Hardware Maintenance Manual...

  • Page 281

    Item # FRUs FRU # A4Y A5U A5F A5S A5P A5D A5Y D2Q D8J D9J E1J E2J E3U E3F E3S E3P E3Y E4U E4F E4S E4P E4Y D3V D4V D5V D6V D7V F1M F2M F3M F4M F5M F6M F7M F8M F9M J1M J2M J3M J4U J4F J4L J7S J7D J7Y J5J J6J J8V J9S J9D J9Y K2S K2D K2Y K3M K4P K5J K6J K7M K8U K8F K8S K9M •...

  • Page 282

    B9S B9Y E1U E1F E1S E1Y E2U E2F E2S E2Y F1M F2M F3M F4M F5M F6M F7M F8M F9M H1M H2M H3M H4M H5M H6M H7M H8M H9M J1M J2M J3M J4M J5M J6M J7M J8M J9M K1G K2J K3J K4V K6M K5S K5D K5Y K8P ThinkCentre Hardware Maintenance Manual...

  • Page 283

    Item # FRUs FRU # • MT 5567: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1Q A1T A1C A1B A1H A1V A1K A1R A1E A1J • MT 5864: A1U A1F A1S A1P A1L A1D A1Y A1G A1M A1A A1T A1K A1R •...

  • Page 284

    • MT 3627: all models 45J9579 • MT 5485: all models • MT 5536: all models • MT 5567: all models • MT 5864: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 285

    FRUs FRU # PS2 cable (170mm) • MT 3245: all models • MT 3269: all models • MT 3491: all models • MT 3627: all models 43N9149 • MT 5485: all models • MT 5536: all models • MT 5567: all models •...

  • Page 286

    • MT 3627: all models 43N9610 • MT 5485: all models • MT 5536: all models • MT 5567: all models • MT 5864: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 287

    FRUs FRU # Vertical stand • MT 3245: all models • MT 3269: all models • MT 3491: all models • MT 3627: all models 43N9644 • MT 5485: all models • MT 5536: all models • MT 5567: all models •...

  • Page 288

    • MT 3627: all models 45K6335 • MT 5485: all models • MT 5536: all models • MT 5567: all models • MT 5864: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 289

    FRUs FRU # FRU, universal slim +HDD bracket assembly • MT 3245: all models • MT 3269: all models • MT 3491: all models • MT 3627: all models 45K6336 • MT 5485: all models • MT 5536: all models •...

  • Page 290

    • MT 5536: all models • MT 5567: all models • MT 5864: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB FRU, power on/off cable bracket 03T9520 • MT 3245: all models ThinkCentre Hardware Maintenance Manual...

  • Page 291

    • MT 5864: all models • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Keyboard and Mouse Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # US English • MT 3245: A1U A2U A8U A5V A6V A7V B2G B4G B5G B6G B7U •...

  • Page 292

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3245: • MT 3269: • MT 3491: A1G A2G A3G A4G A5G • MT 3627: A1G A2G A3G A4G A5G A6G A7G 41A5291 • MT 5485: B2G B3G B4G B5G B6G B7G B8G •...

  • Page 293

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Bulgarian • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: A1G A2G A3G A4G A5G •...

  • Page 294

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Danish • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: A1G A2G A3G A4G A5G • MT 3627: A1G A2G A3G A4G A5G A6G A7G 41A5298 •...

  • Page 295

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB French Canadian • MT 3245: A1F A2F A8F B7F • MT 3269: A1F A2F A8F A6F B1F B5F •...

  • Page 296

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Greek/US • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: A1G A2G A3G A4G A5G • MT 3627: A1G A2G A3G A4G A5G A6G A7G 41A5305 •...

  • Page 297

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Italy • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: A1G A2G A3G A4G A5G •...

  • Page 298

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # LA Spanish • MT 3245: A1S A1D A1Y A2S A2D A2Y B7S • MT 3269: A1S A1D A1Y A2S A2D A2Y A8S A6S B3S B3D B3Y B1S B5S • MT 3491: •...

  • Page 299

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Portuguese • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: A1G A2G A3G A4G A5G • MT 3627: A1G A2G A3G A4G A5G A6G A7G 41A5315 •...

  • Page 300

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Serbian/Cyrillic • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: A1G A2G A3G A4G A5G •...

  • Page 301

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Swedish/Finnish • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: A1G A2G A3G A4G A5G • MT 3627: A1G A2G A3G A4G A5G A6G A7G 41A5322 •...

  • Page 302

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Turkish • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: A1G A2G A3G A4G A5G •...

  • Page 303

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # Slovenian • MT 3245: B2G B4G B5G B6G • MT 3269: A7G A9G B2G B4G • MT 3491: • MT 3627: 41A5329 • MT 5485: • MT 5536: • MT 5567: A1G •...

  • Page 304

    Keyboard (Lenovo Preferred Pro USB -- without hub) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--US English • MT 3245: • MT 3269: •...

  • Page 305

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--B/F • MT 3245: • MT 3269: • MT 3491: • MT 3627: 41A5042 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--Belgium English •...

  • Page 306

    • MT 3269: • MT 3491: • MT 3627: 41A5048 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 307

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--Dutch • MT 3245: • MT 3269: • MT 3491: • MT 3627: 41A5049 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--French •...

  • Page 308

    • MT 3269: • MT 3491: • MT 3627: 41A5080 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 309

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--Hebrew • MT 3245: • MT 3269: • MT 3491: • MT 3627: 41A5055 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--Hungarian •...

  • Page 310

    • MT 3269: • MT 3491: • MT 3627: 41A5061 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 311

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--Norwegian • MT 3245: • MT 3269: • MT 3491: • MT 3627: 41A5062 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--Polish •...

  • Page 312

    • MT 3269: • MT 3491: • MT 3627: 41A5068 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 313

    Keyboard (Preferred Pro Full Size PS/2) FRU # PS/2--Spanish • MT 3245: • MT 3269: • MT 3491: • MT 3627: 41A5069 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB PS/2--Swedish/Finnish •...

  • Page 314

    • MT 3269: • MT 3491: • MT 3627: 41A5075 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 315

    • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Keyboard (Lenovo Fingerprint Reader USB) FRU # US English • MT 3245: • MT 3269: • MT 3491: 03X8001 •...

  • Page 316

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Arabic • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8002 • MT 5485: •...

  • Page 317

    Keyboard (Lenovo Fingerprint Reader USB) FRU # Belgium English • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8005 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 318

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Czech (ABB) • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8009 • MT 5485: • MT 5536: •...

  • Page 319

    Keyboard (Lenovo Fingerprint Reader USB) FRU # French • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8012 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 320

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Greek • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8016 • MT 5485: • MT 5536: •...

  • Page 321

    Keyboard (Lenovo Fingerprint Reader USB) FRU # Hungarian • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8019 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 322

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Korean • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8023 • MT 5485: • MT 5536: •...

  • Page 323

    Keyboard (Lenovo Fingerprint Reader USB) FRU # Polish • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8026 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 324

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Russian/Cyrillic • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8028 • MT 5485: • MT 5536: •...

  • Page 325

    Keyboard (Lenovo Fingerprint Reader USB) FRU # Spanish • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8030 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 326

    Keyboard (Lenovo Fingerprint Reader USB) FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Turkish • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8041 • MT 5485: • MT 5536: •...

  • Page 327

    Keyboard (Lenovo Fingerprint Reader USB) FRU # US European • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03X8036 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 328

    D4V D5V D6V D7V F1M F2M F3M F4M F5M F6M F7M F8M F9M J1M J2M J3M J4U J4F J4L J7S J7D J7Y J5J J6J J8V J9S J9D J9Y K2S K2D K2Y K3M K4P K5J K6J K7M K8U K8F K8S K9M ThinkCentre Hardware Maintenance Manual...

  • Page 329

    Mice FRU # • MT 5536: B1G B1A B1T B2G A7M A7A A7T A8J A9J A1U A1F A1S A1P A1D A1Y A2U A2F A2S A2P A2D A2Y A3U A3F A3S A3P A3D A3Y A4U A4F A4S A4P A4D A4Y B6J B7J B8U B8F B8S B8Y B9U B9F B9S B9Y E1U E1F E1S E1Y E2U E2F E2S E2Y B3V B4V B5V F1M F2M F3M F4M F5M F6M F7M F8M F9M H1M H2M H3M H4M H5M H6M H7M H8M H9M J1M J2M J3M J4M J5M J6M J7M J8M J9M K1G K2J K3J K4V K6M K5S K5D K5Y K8P...

  • Page 330

    H1M H2M H3M H4M H5M H6M H7M H8M H9M J1M J2M J3M J4M J5M J6M J7M J8M J9M K1G K2J K3J K4V K6M K5S K5D K5Y K8P • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 331

    Adapters and miscellaneous FRUs Adapters and miscellaneous FRUs FRU # USB2.0 media carder, 25 in 1, ROHS, slim • MT 3245: • MT 3269: • MT 3491: • MT 3627: 46R1529 • MT 5485: • MT 5536: • MT 5567: •...

  • Page 332

    Adapters and miscellaneous FRUs FRU # Speakers (2-piece) Lenovo Logo (secondary) • MT 3245: • MT 3269: • MT 3491: • MT 3627: 41A5334 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267,...

  • Page 333

    Adapters and miscellaneous FRUs FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Display port to VGA dongle • MT 3245: • MT 3269: • MT 3491: • MT 3627: 45J9524 • MT 5485: •...

  • Page 334

    • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB NVDIA GeForce 310 512MB DDR3 (VGA+DP) LP • MT 3245: • MT 3269: • MT 3491: 03T9009 • MT 3627: • MT 5485: K7M • MT 5536: • MT 5567: • MT 5864: ThinkCentre Hardware Maintenance Manual...

  • Page 335

    Adapters and miscellaneous FRUs FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Parallel port card • MT 3245: • MT 3269: • MT 3491: • MT 3627: 46R1519 • MT 5485: • MT 5536: •...

  • Page 336

    Line Cord - Japan • MT 3245: • MT 3269: • MT 3491: 41R3248 • MT 3627: • MT 5485: J5J J6J K5J K6J • MT 5536: K2J K3J • MT 5567: A1J A1E • MT 5864: A1E A1J ThinkCentre Hardware Maintenance Manual...

  • Page 337

    Power Cords --primary FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Line Cord - Brazil • MT 3245: • MT 3269: • MT 3491: • MT 3627: 45J9595 • MT 5485: A1P A2P A3P A4P A5P E3P E4P K4P •...

  • Page 338

    • MT 3269: B3D B3Y BIS A7G A9G B2G B4G • MT 3491: 41R3232 • MT 3627: • MT 5485: J7S J7Y J9S J9Y K2S K8S • MT 5536: K5S K5Y • MT 5567: A1S A1Y A1L A1G • MT 5864: ThinkCentre Hardware Maintenance Manual...

  • Page 339

    Power Cords --primary FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Line Cord - Indonesia, Laos, Cambodia, and Vietnam A models • MT 3245: • MT 3269: • MT 3491: • MT 3627: 41R3208 •...

  • Page 340

    • MT 3491: • MT 3627: 41R3341 • MT 5485: D2Q • MT 5536: • MT 5567: A1Q • MT 5864: A1Q • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 341

    Power Cords --primary FRU # Line Cord - Austria, Belgium, Croatia, Czechoslovakia, Finland, France, Germany, Hungary, Netherlands, Norway, Poland, Portugal, Romania, Spain, Sweden • MT 3245: A1U A1F A1S A1Y A2U A2F A2S A2Y A8U A8F B3U B3F B3S A9U A9F A9S B1U B1F B1S •...

  • Page 342

    • MT 5485: J5J J6J K5J K6J • MT 5536: K2J K3J • MT 5567: A1J A1E • MT 5864: A1E A1J • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 343

    Power Cords --secondary FRU # Line Cord - Brazil • MT 3245: • MT 3269: • MT 3491: • MT 3627: 41R3271 • MT 5485: A1P A2P A3P A4P A5P E3P E4P K4P • MT 5536: A1P A2P A3P A4P K8P •...

  • Page 344

    • MT 3269: B3D B3Y BIS A7G A9G B2G B4G • MT 3491: 41R3233 • MT 3627: • MT 5485: J7S J7Y J9S J9Y K2S K2Y K8S • MT 5536: K5S K5Y • MT 5567: A1S A1Y A1L A1G • MT 5864: ThinkCentre Hardware Maintenance Manual...

  • Page 345

    Power Cords --secondary FRU # • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Line Cord - Indonesia, Laos, Cambodia, and Vietnam A models • MT 3245: • MT 3269: • MT 3491: A1G A2G A3G A4G A5G •...

  • Page 346

    • MT 3491: • MT 3627: 41R3175 • MT 5485: D2Q • MT 5536: • MT 5567: A1Q • MT 5864: A1Q • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 347

    Power Cords --secondary FRU # Line Cord - Austria, Belgium, Croatia, Czechoslovakia, Finland, France, Germany, Hungary, Netherlands, Norway, Poland, Portugal, Romania, Spain, Sweden • MT 3245: A1U A1F A1S A1Y A2U A2F A2S A2Y A8U A8F B3U B3F B3S A9U A9F A9S B1U B1F B1S •...

  • Page 348: Windows Vista Home Basic 32 Recovery Cd, Recovery Discs

    • MT 3491: CTO • MT 3627: CTO 03T5084 • MT 5485: CTO • MT 5536: CTO • MT 5567: CTO • MT 5864: CTO • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 349: Windows Vista Home Basic 32 With Ie, Recovery Cd, Windows Vista Business 32 Recovery Cd

    Windows Vista Home Basic 32 with IE 9 Recovery CD Note: The Windows Vista recovery DVDs are available only for models with a valid Microsoft Windows Vista certificate of authenticity (COA) affixed to the system. Due to a Microsoft licensing limitation, if a model came with Windows Vista Business or Windows Vista Ultimate preinstalled from the factory, but has a Windows 7 COA affixed to the system, that model is eligible only for recovery DVDs that match the operating system specified on the COA.

  • Page 350

    • MT 3491: CTO • MT 3627: CTO 03T5078 • MT 5485: CTO • MT 5536: CTO • MT 5567: CTO • MT 5864: CTO • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 351

    Windows Vista Business 32 FRU # India English • MT 3245: CTO • MT 3269: CTO • MT 3491: CTO • MT 3627: CTO 03T5079 • MT 5485: CTO • MT 5536: CTO • MT 5567: CTO • MT 5864: CTO •...

  • Page 352

    • MT 3491: CTO • MT 3627: CTO 03T1575 • MT 5485: CTO • MT 5536: CTO • MT 5567: CTO • MT 5864: CTO • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 353

    Windows Vista Business 32 With IE9 FRU # Greek • MT 3245: CTO • MT 3269: CTO • MT 3491: CTO • MT 3627: CTO 03T1576 • MT 5485: CTO • MT 5536: CTO • MT 5567: CTO • MT 5864: CTO •...

  • Page 354

    • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Spanish • MT 3245: 03T5121 • MT 3269: • MT 3491: • MT 3627: ThinkCentre Hardware Maintenance Manual...

  • Page 355

    Windows 7 Home Basic 32 FRU # • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Russian • MT 3245: • MT 3269: •...

  • Page 356

    • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB India English • MT 3245: • MT 3269: • MT 3491: 03T5118 • MT 3627: • MT 5485: • MT 5536: • MT 5567: • MT 5864: ThinkCentre Hardware Maintenance Manual...

  • Page 357

    Windows 7 Home Basic 32 FRU # • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Simplified Chinese • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5117 • MT 5485: • MT 5536: •...

  • Page 358

    • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Russian • MT 3245: • MT 3269: • MT 3491: 03T1615 • MT 3627: • MT 5485: • MT 5536: • MT 5567: • MT 5864: ThinkCentre Hardware Maintenance Manual...

  • Page 359

    Windows 7 Home Basic 32 SP1 FRU # • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Spanish • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T1616 • MT 5485: • MT 5536: •...

  • Page 360

    • MT 3269: • MT 3491: • MT 3627: 03T5129 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 361

    Windows 7 Home Premium 32 FRU # Spanish • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5136 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Italian •...

  • Page 362

    • MT 3269: • MT 3491: • MT 3627: 03T5126 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 363

    Windows 7 Home Premium 32 FRU # India English • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5127 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Hong Kong •...

  • Page 364

    • MT 3269: • MT 3491: • MT 3627: 03T1621 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 365

    Windows 7 Home Premium 32 SP1 FRU # India English • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T1622 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB French •...

  • Page 366

    • MT 3269: • MT 3491: • MT 3627: 03T1629 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 367

    Windows 7 Home Premium 32 SP1 FRU # Spanish • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T1630 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB English •...

  • Page 368

    • MT 5485: A5F E3F E4F B2G B3G J4F K8F • MT 5536: A4F B8F B9F E2F K1G • MT 5567: A1F A1G • MT 5864: A1F A1G • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297_SB ThinkCentre Hardware Maintenance Manual...

  • Page 369

    Windows 7 Professional 32 FRU # German • MT 3245: B2G B5G • MT 3269: A7G B2G • MT 3491: A1G A2G A3G A4G A5G • MT 3627: A1G A2G A3G A4G A5G A6G A7G 03T5095 • MT 5485: B2G B3G •...

  • Page 370

    • MT 3627: A1G A2G A3G A4G A5G A6G A7G 03T5098 • MT 5485: B2G B3G • MT 5536: K1G • MT 5567: A1G • MT 5864: A1G • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297_SB ThinkCentre Hardware Maintenance Manual...

  • Page 371

    Windows 7 Professional 32 FRU # Greek • MT 3245: B2G B5G • MT 3269: A7G B2G • MT 3491: A1G A2G A3G A4G A5G • MT 3627: A1G A2G A3G A4G A5G A6G A7G 03T5094 • MT 5485: B2G B3G •...

  • Page 372

    • MT 3627: A1G A2G A3G A4G A5G A6G A7G 03T5107 • MT 5485: B2G B3G • MT 5536: • MT 5567: A1G • MT 5864: A1G • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297_SB ThinkCentre Hardware Maintenance Manual...

  • Page 373

    Windows 7 Professional 32 FRU # Arabic Localized • MT 3245: B2G B5G • MT 3269: A7G B2G • MT 3491: • MT 3627: 03T5087 • MT 5485: B2G B3G • MT 5536: • MT 5567: A1G • MT 5864: •...

  • Page 374

    • MT 3627: A1G A2G A3G A4G A5G A6G A7G 03T5109 • MT 5485: B2G B3G • MT 5536: • MT 5567: A1G • MT 5864: A1G • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297_SB ThinkCentre Hardware Maintenance Manual...

  • Page 375

    Windows 7 Professional 32 FRU # Simplified Chinese • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5089 • MT 5485: • MT 5536: • MT 5567: A1G • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297_SB C&L1 DK/FI/SV/NO/EN •...

  • Page 376

    • MT 5536: A4S A4D A4Y B8S B8Y B9S B9Y E2S E2Y K5S K5D K5Y • MT 5567: • MT 5864: A1S A1D A1Y • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 377

    Windows 7 Professional 32 SP1 FRU # Italian • MT 3245: B2G B5G • MT 3269: A7G B2G • MT 3491: • MT 3627: 03T1595 • MT 5485: B2G B3G • MT 5536: K1G • MT 5567: • MT 5864: A1G •...

  • Page 378

    • MT 3269: • MT 3491: • MT 3627: 03T1584 • MT 5485: • MT 5536: • MT 5567: • MT 5864: A1R • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 379

    Windows 7 Professional 32 SP1 FRU # Korean • MT 3245: • MT 3269: A7G B2G • MT 3491: • MT 3627: 03T1596 • MT 5485: B2G B3G • MT 5536: K1G • MT 5567: • MT 5864: A1G • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Slovenian •...

  • Page 380

    • MT 3269: • MT 3491: • MT 3627: 03T1592 • MT 5485: J8V • MT 5536: K4V • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 381

    Windows 7 Professional 32 SP1 FRU # Traditional Chinese • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T1586 • MT 5485: • MT 5536: • MT 5567: • MT 5864: A1G • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB India English •...

  • Page 382

    • MT 3269: • MT 3491: • MT 3627: 03T2102 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 383

    Windows 7 Professional 64 Recovery CD Windows 7 Professional 64 FRU # US English • MT 3245: B3U B4G B6G B7U • MT 3269: A8U A9G BIU B4G B5U • MT 3491: • MT 3627: 03T5151 • MT 5485: K7M •...

  • Page 384

    • MT 3269: • MT 3491: • MT 3627: 03T5143 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 385

    Windows 7 Professional 64 FRU # India English • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5144 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB Hong Kong •...

  • Page 386

    • MT 3269: A9G B4G • MT 3491: • MT 3627: 03T0697 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3029, 3054, 3139, 3219, 3349, 3421, 3769, 3934, 4992, 5206, 5267, 5325_SB ThinkCentre Hardware Maintenance Manual...

  • Page 387

    Windows 7 Professional 64 SP1 Recovery CD FRU # Windows 7 Professional 64 SP1 Brazilian Portuguese • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T1634 • MT 5485: • MT 5536: • MT 5567: • MT 5864: •...

  • Page 388

    • MT 3269: • MT 3491: • MT 3627: 03T1641 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297_SB ThinkCentre Hardware Maintenance Manual...

  • Page 389

    FRU # Windows 7 Professional 64 SP1 Italy • MT 3245: B4G B6G • MT 3269: A9G B4G • MT 3491: • MT 3627: 03T1642 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297_SB Spanish •...

  • Page 390

    • MT 3245: • MT 3269: • MT 3491: • MT 3627: • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297_SB ThinkCentre Hardware Maintenance Manual...

  • Page 391

    Windows 7 Ultimate 32 Recovery CD Windows 7 Ultimate 32 FRU # US English • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5829 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Windows 7 Ultimate 32 with MS SP1 Recovery CD Windows 7 Ultimate 32 with MS SP1...

  • Page 392: Windows 7 Starter 32 Recovery Cd, Windows Xp Professional Recovery Cd

    • MT 3269: • MT 3491: • MT 3627: 03T5057 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 393

    Windows XP Professional FRU # German • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5059 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Italian •...

  • Page 394

    • MT 3269: • MT 3491: • MT 3627: 03T5069 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 395

    Windows XP Professional FRU # Russian English • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5068 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB Hungarian •...

  • Page 396

    • MT 3269: • MT 3491: • MT 3627: 03T5065 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 397

    Windows XP Professional FRU # C&L1 EMEA -- English, Dutch, French, German, Italian • MT 3245: • MT 3269: • MT 3491: • MT 3627: 03T5075 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB C&L 2 Nordics -- English, Danish, Finland, Norwegian, Swedish •...

  • Page 398

    • MT 3269: • MT 3491: • MT 3627: 03T5070 • MT 5485: • MT 5536: • MT 5567: • MT 5864: • MT 3026, 3039, 3137, 3149, 3319, 3394, 3699, 3878, 4972, 5132, 5261, 5297,_SB ThinkCentre Hardware Maintenance Manual...

  • Page 399: Chapter 11. Additional Service Information, Security Features, Hardware-controlled Passwords, Operating System Password, Vital Product Data

    “Using passwords” on page 41. Operating system password Note: This section applies only to computer models that have an operating system preinstalled from Lenovo. An operating system password is very similar to a power-on password and denies access to the computer by an unauthorized user when the password is activated.

  • Page 400: Updating (flashing) Bios From A Disc, Updating (flashing) Bios From Your Operating System

    6. Follow the instructions on the screen to complete the update. Updating (flashing) BIOS from your operating system Note: Because Lenovo makes constant improvements to the Web site, the Web page contents are subject to change without notice, including the contents referenced in the following procedure.

  • Page 401: Power Management, Acpi) Bios, Automatic Power-on Features

    3. Access the system board. Refer to “Removing and reinstalling the front bezel” on page 72. 4. Locate the Clear CMOS /Recovery jumper on the system board. Refer to “Locating parts on the system board” on page 104. 5. Remove any cables that impede access to the Clear CMOS/Recovery jumper. 6.

  • Page 402

    ThinkCentre Hardware Maintenance Manual...

  • Page 403: Appendix A. Notices

    Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.

  • Page 404: Television Output Notice, Trademarks

    Macrovision Corporation. Reverse engineering or disassembly is prohibited. Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo Rescue and Recovery...

  • Page 405: Index

    85, 118 enabling or disabling heat sink and fan assembly, replacing selecting heat sink, replacing startup device temporary startup device setting password installing options settings PCI card 83, 108 changing internal speaker, replacing 96, 121 viewing © Copyright Lenovo 2010, 2013...

  • Page 406

    Setup Utility program startup device sequence, changing temporary, selecting system board connectors 71, 105 locating parts locations system fan, replacing temporary startup device updating (flashing) BIOS updating (flashing) BIOS using passwords Setup Utility viewing and changing settings ThinkCentre Hardware Maintenance Manual...

  • Page 408

    Part Number: 71Y7233 Printed in USA (1P) P/N: 71Y7233 *1P71Y7233*...

Comments to this Manuals

Symbols: 0
Latest comments:
