American Dynamics Tyco ADSPOT Specifications

SPECIFICATIONS
Model Number
ADSPOT . . . . . . . . . . . . . . . . . . . . .240 VAC (field changeable to 120 VAC)
Transformer jumpers are field changeable to
support either 120 VAC or 240 VAC
ADSPOT is used with any American Dynamics dome or fixed camera
Electrical
Power Source . . . . . . . . . . . . . . . . .100-120 VAC or 200-240 VAC @ 50/60 Hz
Operational Limits . . . . . . . . . . . .90-135 VAC or 180-265 VAC @50/60 Hz
Input Current . . . . . . . . . . . . . . . .1.0A/0.5A
Output . . . . . . . . . . . . . . . . . . . . . . .24 VAC, 2.5A max.
UL Listed Class 2
Certified Limited Power Source
Mechanical
Dimensions (H x W x D) . . . . . . .175 x 125 x 75 mm
(6.9 x 4.9 x 3.0 in)
Weight . . . . . . . . . . . . . . . . . . . . . . .3.7 kg (8.2 lbs)
Enclosure Material . . . . . . . . . . . .Impact-resistant polycarbonate
Color . . . . . . . . . . . . . . . . . . . . . . . .Light gray
Wall Mounting Options . . . . . . .Concrete, wood or sheet rock
Mounting Area (H x W) . . . . . . . .281 x 200 mm
(11.1 x 7.9 in)
Cover Fasteners . . . . . . . . . . . . . . .Four captive screws
Cable Access Knockouts . . . . . . .Eight 21 mm or 15.5 mm
(0.83 in or 0.61 in)
Four 29 mm or 23 mm
(1.14 in or 0.91 in)
Environmental
Weatherproof Standard . . . . . . . .NEMA 4, IP66
Operating Temperature . . . . . . . .-40˚ to 50˚ C (-40˚ to 122˚ F)
Storage Temperature . . . . . . . . . .-40˚ to 50˚ C (-40˚ to 122˚ F)
Humidity . . . . . . . . . . . . . . . . . . . . .0% to 95% RH (non condensing)
Regulatory
Safety . . . . . . . . . . . . . . . . . . . . . . . .UL 60950
CSA C22.2 No. 60950
EN60950
IEC 60950
Product specifications and availability subject to change without notice.
Certain product names mentioned herein may be trade names and/or
registered trademarks of other companies.
ADSPOT
SINGLE POSITION OUTDOOR POWER SUPPLY
This weather-tight box provides Class 2 LPS
power to the SpeedDome
Optima outdoor camera housings. It is designed
for use in the harshest of outdoor environments.
Features
•
Supports both 120
VAC and 230 VAC
•
Small, compact
design
www.americandynamics.net
®
Ultra and SpeedDome
•
Weatherproof design:
NEMA 4 and IP66
rated
•
Euro-style terminal
blocks make for
quick and simple
installation
VS352-01 03/04 L
©2004 Sensormatic Electronics Corporation
