  • Page 1 U.S.A U.S.A. GE Lighting E N T E R T A I N M E N T L I G H T I N G • S T A G E • S T U D I O • D I S C O • P H O T O G R A P H I C...
  • Page 2 Introduction For many years GE Lighting has been a leading supplier to the various sectors which make up the entertainment lighting industry. GE Lighting have an ongoing strategy of product innovation and improvement to meet the demands and applications of O.E.M.s and end users.

  • Page 3: Table Of Contents

    Obscured top Due to integral dichroic reflector nominal lumens not shown Axial coiled coil single ended lamps will generally give better reliability against premature arcing if orientations in which the main support spine is under the filament are avoided Contents...

  • Page 4: Symbols

    Capacitor Capaciteur Condensatore CRI rd Índice di resa cromatica Description Description Descrizione Diameter Diamètre Diametro GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Español Deutsch English ANSI ANSI-Code Finish Haz 10% Austrahlwinkel 10% Gap (mm) Haz 50% Austrahlwinkel 50% Lámpara/bulbo Lampe...
  • Page 5 Temps de Tempo di Tiempo de Réamorçage riaccensione reencendido Distance de Distanza Focale Distancia de trabajo Betriebsabstand Montage /Distancia focal /Distance Focale GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Deutsch Strom (A) Halbwerts- winkel Zehntwerts- winkel Anfangslicht- strom (lm) Nutzlebens- dauer Anlaufzeit Anzünden...
  • Page 6 PAR 56 11 - 12 PAR 64 13 - 17 PAR lamps provide a robust and flexible design solution for a wide range of theatre, studio and nightclub applications. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Twister, Wilhelmshafen, Germany By Fischer Art of Light & Sound GmbH, Bremen...
  • Page 7 Designlösung für eine Las lamparas PAR son una solución umfangreiche Anwendung anTheater-, robusta y a la vez flexible cuando se Studio- und Nachtclub-Anwendungen realizan diseños de iluminación en todo tipo de teatros, escenarios, discotecas. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE PAR 64...

  • Page 8: Par Lamps

    PAR Lamps PAR 36 Ferrule cap PAR 36 Ferrule cap Peak Intensity Watts Volts Order Code 24000 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Approx. Beam Spread Colour Temp. K Peak CD Peak CD 3200 – 60x55 3200 – 40x30 PAR 36 Screw Terminal cap...
  • Page 9 – 24663 15133 24673 – 43576 – 24678 42838 2000 12892 2000 16540 2000 16541 4000 – 19880 2000 16542 – 24627 – 24640 – 24650 – 41503 – 24742 – 24892 – 24882 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 10 Intensity Watts Volts Order Code 4593 4594 70000 4626 25000 4627 4587 4596 150000 24000 35000 75000 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Colour Temp. K Peak CD Peak CD 1500 – 80x30 – – 13x7 – – 40x9 –...
  • Page 11 Life Hours Quantity Notes Code 24735 24577 – 24726 43591 – 40822 – 24828 – 24830 – 24833 – 24795 24799 – 24859 – 24862 – 33284 – 37706 1000 – 37372 – 36271 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 12 PAR Lamps continued PAR 46 Medium Side Prong cap Peak Intensity Watts Volts Order Code 150PAR46/3MFL 8000 200PAR46/3MFL 11500 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Approx. Beam Spread Colour Temp. K Peak CD Peak CD Life Hours 2750 39x25 26x13 2750...
  • Page 13 – 50x27 35x18 – – – Rated Average Pack Product Quantity Notes Code 24768 2000 – 19023 2000 – 19024 2000 – 19025 – 20122 2000 20575 2000 20576 2000 20577 1000 – 23427 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 14 Watts Volts Order Code 300PAR56/NSP 300PAR56/MFL 300PAR56/WFL 300PAR56/NSP 300PAR56/MFL 300PAR56/WFL 300PAR56/NSP 300PAR56/MFL 300PAR56/WFL Q500PAR56/NSP Q500PAR56/MFL Q500PAR56/WFL GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Approx. Beam Spread Colour Temp. K Peak CD Peak CD 68000 2750 20x14 10x8 24000 2750 34x19 23x11...
  • Page 15 Peak CD Peak CD 500000 – – 600000 – 11x12 – 600000 – 12x8 – 765000 – 11x7.5 – 192±1 188±1 Rated Average Pack Product Life Hours Quantity Notes Code – 40576 40578 40579 42552 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 16 PAR Lamps continued 204±1.5 192±1 188±1 177±1.4 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 17 Average Pack Product Life Hours Quantity Notes Code 30280 30282 30283 30286 30287 30288 2000 39411 2000 39414 35118 35117 35130 35111 35116 35110 19909 19910 19911 19912 19913 19914 30277 30278 35482 35483 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 18 PAR Lamps continued 204±1.5 192±1 177±1.4 188±1 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 19 31x14 15x8 80000 3000 45x22 28x12 33000 3000 72x45 48x24 Rated Average Pack Product Life Hours Quantity Notes Code 2000 39406 2000 39409 13233 13229 13228 13227 13225 4000 43497 4000 43498 4000 43499 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...

  • Page 20: Single Ended Halogen Lamps

    GY16 base G22 base P28s base G38 base GX38q base E40 base P40s base GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE 22 - 23 24 - 25 28 - 29 30 - 31 An extensive range of lamps designed to optimal performance in today’s precision range of...
  • Page 21 óptimo rendimiento dentro de los aparatos de iluminación de precisión utilizados actualmente en la iluminación espectacular. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Einseitig-gesockelte Halogenlampen Eine umfassende Auswahl an Lampen wurde entworfen, um eine optimale Leistung in der heutigen Präzisionsauswahl an...
  • Page 22 12360 HPL 750 19750 HPL 750 19750 HPL 750 22000 The HPL 750w version has a pinned base to ensure correct application GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Colour Filament Type Length Diameter Temp. K Form H x W 3200 10 x 9.5...
  • Page 23 39739 60.5 – 39750 60.5 1500 – 39751 60.5 1500 – 39752 60.5 39734 60.5 39735 60.5 39771 60.5 2000 39770 60.5 – 39753 60.5 – 39754 60.5 35607 60.5 39738 60.5 39736 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Fig.
  • Page 24 GY9.5 base - Grid-form Filament Watts Volts Code Order Code CP81 220/230 CP81 240/250 CP81 CP82 CP82 CP82 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Continued Fig. 1 Approx. Initial Colour Filament Type Length Diameter LCL Lumens Temp. K Form H x W...
  • Page 25 CC-8 16x6 Rated Average Pack Product Notes Code – 39717 – 39629 – 39455 – 39262 – 39456 – 39457 – 39630 – 39635 – 39636 – 39637 – 39640 – 39642 2000 30475 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Fig.
  • Page 26 Single Ended Halogen Continued Fig. 1 Fig. 2 Fig. 3 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 27 Notes Code – 39661 – 39663 – 39654 – 39660 – 39651 – 39653 – 29331 – 39656 – 39659 39657 39658 39241 39242 – 39647 – 39723 – 39667 39724 – 39725 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Fig.
  • Page 28 CP43 2000 CP79 – 2000 CP79 – 2000 CP79 – Burning position VBD ±90 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Continued Fig. 2 Fig. 3 Approx. Initial Colour Filament Type Length Diameter LCL Lumens Temp. K Form H x W...
  • Page 29 24x18 3200 24x18 Rated Average Pack Product Notes Code – 30373 – 20320 – 20321 – 39191 – 39655 – 20286 – 30384 – 30391 – 30394 – 30397 – 30415 – 30423 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Fig.
  • Page 30 Fig. 1 P28s base (medium prefocus) Watts Volts Code ANSI Code – – – – Burning position VBU ±90 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Continued Fig. 2 Fig. 3 Approx. Initial Colour Filament Type Length Diameter LCL Lumens Temp. K...
  • Page 31 17.5x17.5 160 88.9 3200 18.5x17.5 130 55.5 Rated Average Pack Product Notes Code – 39733 – 30541 – 30542 – 20323 – 20324 38853 30533 – 20385 30534 – 20388 – 30532 – 30546 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Fig.
  • Page 32 Single Ended Halogen Continued Fig. 1 Fig. 2 Fig. 3 Fig. 4 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 33 41x52 Rated Average Pack Product Notes Code – 35234 – 35233 – 36636 – 31844 – 31849 – 30499 – 30500 30503 30504 – 41736 – 30505 – 30506 – 30507 – 30508 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Fig.
  • Page 34 27000/59000/91000 3200 1250/2500 240 CP58 27000/59000/91000 3200 2500/2500 230 CP32 59000/127000 2500/2500 240 CP32 59000/127000 Burning position VBD ±45 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Continued Colour Filament Type Length Diameter LCL Temp. K Form H x W 3050 24x18.5 3050 24x18.5...
  • Page 35 CC-8 40x7 3200 CC-8 40x7 3200 CC-8 – 3200 CC-8 – 3200 CC-8 40x8 – Fig. 2 Rated Average Pack Product Notes Code 29424 29426 – – 34377 – 1000 – 40357 19000 30491 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Fig.
  • Page 36 1000 – 1000 – 1500 2000 CP53 – 2000 CP53 – Burning position VBD ±90 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Continued Fig. 1 Approx. Initial Colour Filament Type Length Diameter LCL Lumens Temp. K Form H x W 23000 3050 17.5x17.5 180...
  • Page 37 Notes GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...

  • Page 38: Linear Halogen Lamps

    Length 119.1 mm Length 142.9 mm Length 189.1 mm This precision range of quartzline lamps are widely used in television broadcast studios around the world. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE CNBC Europe’s Studio. CNBC, the 24-hour global business television news channel...
  • Page 39 Lineales Este rango de lámparas de cuarzo de alta precisión es ampliamente utilizado en los estudios de televisión de todo el mundo. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Stabförmige Halogenlampen Die Genauigkeit der Quarzlampen sind weltweit in den Fernsehstudios verbreitet.
  • Page 40 Linear Halogen Double-Ended Quartzline ® Lamps with R7s Caps Length 79.4mm Watts Volts Code Order Code P2/6 P2/13 P2/13 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE 11.4 Approx. Initial Colour Filament Lighted Length Diameter Lumens Temp. K Form Length 16500 3200 CC-8 15.9...
  • Page 41 28000 1000 26000 12.4 Filament Lighted Length Diameter Form Length 3200 CC-8 22.2 95.3 3200 CC-8 22.2 95.3 Fig. 2 Rated Average Pack Product Fig. Life Hours Quantity Notes Code – 30157 Frost 30374 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 42 Linear Halogen Length 119.1mm - Burn Horizontal ±4° Watts Volts Code Order Code – – – P2/11 P2/11 1000 P2/28 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Continued 10.2 Approx. Initial Colour Filament Lighted Length Diameter Lumens Temp. K Form Length 5950 2950 58.7...
  • Page 43 57000 Filament Lighted Length Diameter Form Length 3200 CC-8 142.9 3200 CC-8 142.9 3200 CC-8 142.9 Fig. 2 Rated Average Pack Product Fig. Life Hours Quantity Notes Code – 35338 – 35339 – 33761 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 44 Order Code P2/10 – P2/10 – 1000 P2/7 1000 P2/7 1250 P2/12 – 1250 P2/12 – GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Continued 10.2 Approx. Initial Colour Filament Lighted Length Diameter Lumens Temp. K Form Length 16900 3200 189.1 16900 3200 189.1...
  • Page 45 Notes GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...

  • Page 46: Specialist Projector Lamps

    Mains volt single ended Linear projector MR16 projector MR11 projector MR13 projector MR14 projector High intensity arc GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE 46 - 47 53 -57 A full range of specialist projection lamps designed to deliver excellent optical performance and reliability.
  • Page 47 Eine komplette Auswahl an Un rango completo de speziellen Projektionslampen, lámparas especiales para entworfen um eine proyección, diseñadas para ausgezeichneten optischen proporcionar un excelente Performance und rendimiento óptico y una Verlässlichkeit zu bieten. gran fiabilidad. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 48 Specialist Projector Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 9 Fig. 10 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 49 18241 50 GY6.35* 19886 GY6.35 18238 GY6.35 30888 GX9.5 35484 GZ9.5 32955 – – 29592 GZ9.5 CMN 33248 GZ9.5 33250 GX9.5 32714 GX9.5 30949 GX9.5 35232 – – 29604 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE – – – – –...
  • Page 50 220/230 A1/249 7200 A1/249 7200 220/230 A1/244 13000 A1/244 13000 A1/247 17750 220/230 A1/245 21500 A1/245 21500 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Fig. 1 Operating Length Diam. Position Filament BDTH 16.3 BDTH 16.3 BDTH 16.3 BDTH 16.3 BDTH 28.5...
  • Page 51 Fig. 4 Approx. Operating Colour Length Position Filament Temp. K BDTH 3200 BDTH 3200 BDTH 3250 BDTH 3250 Fig. 5 Rated Average Pack Product Fig. Life Hours Quantity Notes Code MNSTQ 39727 36117 39728 39729 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 52 Specialist Projector Single-ended Tungsten Halogen Lamps Low Voltage single-ended capsule Length Diameter Watts Volts LIF Code M29/ESA M30/ESB M28/EVA GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Fig. 1 Fig. 2 Average Colour Lumens Temp. K 19.5 3200 19.5 3200 3000 G6.35...
  • Page 53 45.5 5000 2900 GY9.5 45.5 8500 2900 GY9.5 45.5 8500 2900 GY9.5 Fig. 5 Rated Average Pack Product Fig. Life Hours Quantity Notes Code 2000 39786 2000 39785 2000 39784 2000 39621 2000 39622 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 54 Specialist Projector Double-ended lamps with R7s caps Linear Projector Lamps ANSI Watts Volts Code Code Application – Microfilm A1/226 Overhead projector A1/227 Overhead projector GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Fig. 1 Rated Primary Average Length Diam. Life Hours Filament –...
  • Page 55 CC-6 44.45 50.67 1000 CC-6 44.45 50.67 Fig. 3 Pack Product Fig. Cap Quantity Notes Code 3100 GX5.3 36902 3150 GX5.3 44854 3300 GZ6.35 41251 3350 GZ6.35 41252 3350 GX5.3 43206 3125 GX5.3 43988 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 56 – Microfilm A1/252 16mm, Colour printer 50 A1/259 16mm, Colour printer 50 – Slide projection – Slide projection – Slide projection GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Rated Average Focal Length Diam. Colour Life Hours Distance Filament 1000 CC-6 44.45...
  • Page 57 Fig. Temp. K Cap Quantity Notes Code 3400 GX5.3 32886 3400 GX5.3 37412 3350 GX5.3 32882 3350 GX5.3 32831 Approx. Pack Product Fig. mm Temp. K Cap Qty Notes Code 3400 GX7.9 24 39742 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 58 Specialist Projector continued Fig. 1 Fig. 2 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 59 41882 3150 GX5.3 42614 3350 GY5.3 43756 3200 GY5.3 15477 3300 GX5.3 11132 3300 GY5.3 13152 3300 GY5.3 11110 3300 GY5.3 11750 3300 GX5.3 41874 3250 GY5.3 41702 3300 GY5.3 41705 3300 GY5.3 21613 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 60 Projection lamps MR-11 Faceted Dichroic Reflector ANSI Primary Watts Volts Code Code Application Microfilm 13.8 Microfilm GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Fig. 1 Rated Typical Approx. Average Working Length Diam. Colour Life Hours Distance Filament mm Temp. K...
  • Page 61 42.4 – CC-8 44.4 42.4 CC-8 44.4 42.4 CC-8 44.4 42.4 CC-8 44.4 42.4 Pack Product Fig. Quantity Notes Code 3200 GX5.3 12097 GX5.3 15832 3350 GX5.3 12092 3450 GX5.3 12095 3300 GX5.3 47614 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 62 MR-14 Dichroic Reflector ANSI Primary Watts Volts Code Code Application ELS/ELR – Microfilm EMM/EKS A1/258 16mm projection GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued ® Rated Typical Average Working Operating Length Diam. Colour Life Hours Distance Position Filament mm BDTH...
  • Page 63 76mm dichroic reflector polarized plug Gemini and Marc lamps should be operated with the plane of the reflector vertical. These lamps should not be operated for periods of less than three minutes since short operating cycles reduce life and degrade performance. Typical Rated Approx.
  • Page 64 CSI/CID G22 base G38 base Special bipin base G22 medium bipost Circuit diagrams Linear ultra violet GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE 64 - 65 ConstantColor™ CMH lamps represent the latest advance in discharge lighting technology for use in a...
  • Page 65 CMH son el último avance en la tecnología de iluminación de descarga de alta intensidad y pueden ser utilizadas en una amplia variedad de aplicaciones de estudio y teatro. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Hochdruckentladungslampen ConstantColor CMH Lampen vertreten den neuesten Fortschritt in der Hochdruckentladungstechnologie für die Nutzung einer großen...

  • Page 66: Discharge Lamps

    CCT ˚K CRI Ra Lamp Single Ended ‘Minis’ 3000 – 3000 – Single Ended 3000 3000 4200 3000 4200 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Fig. 1 Fig 2 Product Base Finish Position Rated Hours G8.5 CLEAR UNIVERSAL 9000 G8.5 CLEAR...
  • Page 67 15000 7000 CLEAR HORIZONTAL ± 45 15000 6200 CLEAR HORIZONTAL ± 45 15000 14500 CMH150/TD/UVC/830/Rx7s-24 CLEAR HORIZONTAL ± 45 15000 12500 CMH150/TD/UVC/942/Rx7s-24 Product Product Description Code Description Code CMH70/TD/UVC/830/Rx7s 36910 CMH70/TD/UVC/942/Rx7s 38698 36912 38692 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 68 Order Code Lumens CSS150/850/GY9.5 10000 CSS575/855/GY9.5 40250 Colour Chromacity Colour Burning Coordinates Rendering Position X0.346 Y0.358 X0.322 Y0.341 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Colour Length Diameter Temp. K 5000 5500 Run Up Restrike Current Time (mm) (amps) sec (max) 1.87...
  • Page 69 G53444 or G53371.T Bag Turgi SE15/7U 85±5 Fig. 6 Colour Rendering Burning Index Ra Position Width Base VBD±90 9±1 ±0.5 spacing 0.76 dia Product Capacitor Code 7xGC2331 30555 40µF 250V GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE 36.5±1 Lamp Volts Fig.
  • Page 70 100 hrs Maintenance 1000 99-0221 90000 Run Up Starting Current Time Pulse (nom) (amps) Sec. (max) 9 Peak GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Average Colour Life Colour Chromaticity Hours Temp. K Co-ordinates 85% at 500 hrs 4000±400 y0.395...
  • Page 71 Sec. (max) Mins 12 Peak Instant (hot restrike) *Measured between sphere gap of 7.5mm in air Circuit diagrams for these lamps can be found on pages 74-76 this includes other essential components Angle 1/10 Colour Peak Average Colour Chromaticity Rendering...
  • Page 72 Run Up Starting Current Time Pulse (nom) (amps) Sec. (max) 12 Peak Circuit diagrams for these lamps can be found on pages 74–76 this includes other essential components GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Average Colour Life Colour Chromaticity Hours Temp.
  • Page 73 Bag Turgi SE15/7U 127±2 Fig. 3 Colour Rendering Burning Index Ra Position Width X0.322 VBD±90 y0.341 X0.332 VBD±90 y0.341 Product Fig. Capacitor Code 4xGC2331 30563 80µF 250V 7xGC2346 30561 175µF 250V GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Lamp Volts 9±1 15±1.5...
  • Page 74 99-0431 200000 Run Up Starting Current Time Pulse (nom) (amps) Sec. (max) * Measured between sphere gap of 17mm in air GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued Average Colour Life Colour Chromaticity Hours Temp. K Co-ordinates 90% at 350 hrs 5500±400...
  • Page 75 Instant (hot restrike) Measured between sphere gap of 7.5mm in air ** Measured between sphere gap of 17mm in air Circuit diagrams for these lamps can be found on pages 74–76 this includes other essential components Angle 1/10 Peak Average...
  • Page 76 C-1 F 250V Sw - Normally open contacts - Manual switch or 2 second ON timer Maximum cable capacitance between igniter and lamp - 30pF (200mm length) GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued 400 Watt CSI Lamp Circuit Diagram HBC/MCB...
  • Page 77 Replace G53445 (or Bag Turgi SE600/D) igniter sparkgap element when replacing a failed lamp HBC/MCB Fuse Ballast G53307. T 1000W CSI Lamp G53444 or Bag Turgi SE 15/7U 175µF 250V Igniter 7xGC2346 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Ref 99-1222 or 99-0221 Lamp...
  • Page 78 250V Sw - Normally open contacts - Manual switch or 2 second ON timer Maximum cable capacitance between igniter and lamp - 30pF (200mm length) GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE continued 1000 Watt CSI/CID Hot-Restart Lamp Circuit Diagram 1000W CID Lamp...
  • Page 79 Blacklight Blue (produce long wave ultra-violet light) Nominal Watts Length mm Order Code F20T12/BLB 1200 F40BLB Fig. 1 Rated Average Description Life Hours Quantity Blacklight Blue 9000 Blacklight Blue 20000 Pack Product Fig. Code 34747 25618 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...

  • Page 80: Technical Information

    Operating notes Health and safety guide Filament designations Lamp comparison / construction Surge current Discharge lamps GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE 79 - 80 81 - 82 83 - 86 87- 88 89 - 90...
  • Page 81 CP Prefix - Lamps designed for use in conjunction with film balanced for 3200K. These are single ended types intended for use in Fresnel/ellipsoidal luminaires etc.
  • Page 82 In addition to these standard ranges, a number of similar types are available to special order and in most cases, a minimum order quantity will apply. These include non-standard voltage ranges of some types e.g. 100V, 100/115V, 120V and also a number of types which have the GE “HX” or “THE” prefix.
  • Page 83 T.F. - Twin Monoplane Grid - equivalent to ANSI 2C13 S.C.H - Single Coil Hexagonal - equivalent to ANSI 6-C8 S.C.S - Single Coil Square - equivalent to ANSI 4-C8 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 84 The increase in the use of the lamps we now manufacture is due to the GE policy of exploiting the important advantages of compact size offered by quartz halogen construction.
  • Page 85 Average life ratings of Projection Lamps are based on closely controlled laboratory tests of lamps, at their rated voltage, over a long period of production time. Rated Average Life is not necessarily the same as service life; mechanical shock and vibration, voltage fluctuation, temperature and other environmental factors may result in shorter service life.
  • Page 86 Maximum Overall Length (MOL) This dimension includes the lamp bulb and all rigid parts of the base. Since the listed lengths include maximum tolerances, actual lamps are generally slightly shorter. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 87 “blackbody” at specific colour temperatures. The Colour Temperatures shown are approximate initial values in Kelvin (K) for lamps operated at rated voltage. As the spectral distribution of MARC lamps does not conform to that of a “blackbody”, the values shown are ‘correlated’ colour temperatures expressed in Kelvin.
  • Page 88 This catalogue contains accumulated data to January 2000. Additional information is constantly being uncovered through research and testing, which may modify the data given herein. This is particularly true of newer lamps. For the latest lamp design data and information, contact your General Electric Lamp Representative.

  • Page 89: Operating Notes

    Caution notices are included with all lamps. Users are urged to read and comply with these. Operating precautions All lamps in this catalogue must be operated with a series fuse in the circuit, as directed in the Technical Digest. Lamps of quartz construction use a gas filling at a pressure higher than atmospheric and as the lamp can in rare instances shatter in use, suitable shielding techniques should be employed where appropriate.
  • Page 90 VBD=105° HOR-4° Fig. 1 Axial coiled coil single ended lamps will generally give better reliability against premature arcing if orientations in which the main support spine is under the filament are avoided. GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE VBD=45° VBD=90°...
  • Page 91 Life expired lamps should be broken in a suitable robust container, or wrapping, to retain flying fragments. There is a toxic content in the fill gas and larger quantities should only be broken in a well ventilated area.
  • Page 92 10 Certain lamps generate ozone in use and should be operated only in well ventilated locations. 11 Metal halide lamps with quartz envelopes without glass outer bulbs may emit short wave ultra violet radiation which is harmful to eyes and skin.
  • Page 93 Filament designation The configuration of the filaments in all tungsten filament lamps is identified by a prefix letter or letters, followed by a number. The letter indicates whether the wire is a single coil (C) or coiled coil (CC); the number indicates the form or arrangement of the coil on its support structure. Note that the illustrations are not to scale.
  • Page 94 Lamp caps Typical caps used on the Photographic lamps listed in this catalogue are shown below along with their IEC codes and normal names or common abbreviations. The IEC codes are used in the majority of table entries. Note that the illustrations are not to scale.
  • Page 95 GE have therefore designed lamps intended for use in ellipsoidal spotlights where the size of the cap has been reduced and the neck length correspondingly increased, thus removing the critical seal area from the reflected radiation and ensuring that optimum lamp life is obtained.
  • Page 96 GE Lighting Ltd or your nearest Subsidiary Company. It is important to distinguish between hard glass lamps that merely have a halogen compound added to the filling gas and lamps such as those enumerated, which are of quartz construction. The former are from the point of view of life and performance identical to conventional glass lamps of the same rating, the halogen only serving to prolong the usefulness of the lamp by preventing internal blackening due to evaporated tungsten.
  • Page 97 The choice between a monoplane and a smaller equivalent biplane is, therefore, dependent on luminaire design and customer preference. GE pursue a policy of allowing the customers to make this choice by offering both monoplane and biplane versions of relevant lamp types.
  • Page 98 Arc Prevention in Tungsten Halogen Studio Lamp Applications Almost all production personnel in the film and television industry have at some time encountered sudden failure of incandescent studio lamps. When this occurs at a crucial moment and forces a re-shoot the cost can be considerable.
  • Page 99 The rated performances claimed in this catalogue have been achieved at nominal rated volts. Operating the lamps at other than the rated voltage will significantly affect performance, as shown graphically on pages 100 and 101. All lamps are designed for use with proprietary dimming equipment as required.
  • Page 100 Support Seal tube Pinch seal Flexible lead Ceramic base Contact pin GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE A typical 4 pin twin filament studio lamp Exhaust tip off Quartz bridge Quartz envelope Filament hook...
  • Page 101 End section of a typical quartz linear tungsten halogen lamp Tungsten support Tapered coiled tail plug Quartz envelope Fuse wire Silver plated contact GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Gas filling Molybdenum seal Outlead Fuse wire weld Inner ceramic...
  • Page 102 Lamp comparison and construction Variation of light output and wattage with applied voltage for a typical studio lamp % rated volts GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Colour temperature variation with voltage for typical studio lamp...
  • Page 103 This graph is based on the average achievement of numerous lamp tests, and thus should only be used as an approximate guide to performance. VioletBlue Green Yellow wavelength (nm) GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 104 Spectral energy distribution can be shown in absolute terms whereas radiation in terms of visible light is related to the response of the human eye. (Spectral distribution chart on previous page) GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Operating Temperature of Tungsten Halogen Studio Lamps The following maximum and minimum temperatures are suggested for optimum life.
  • Page 105 Turn on time of studio lamps From mains From constant current source From Typical Dimmer System time (sec) GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 106 (a) switch on does not always occur at the peak of the AC voltage, (b) the supply has some impedance which is comparable with the cold resistance of high wattage lamps, i.e. maximum possible surge current where V is the applied voltage and Z is the sum of the lamp cold resistance and the supply impedance.
  • Page 107 Fusing of Tungsten Halogen Studio and Theatre Lamps A lamp normally fails at end of life by fusing of the filament. Often an arc then forms and as there is little resistance to limit the current this rises to a very high value which if maintained can result in a serious overload on the envelope and seals.
  • Page 108 The potential for major cost savings is clear. GE Lighting has led the way in adapting discharge lamps for use in the performing arts. The company was the first and for many years the only manufacturer to offer metal halide lamps in the compact, single ended capsule format.
  • Page 109 For all personnel the working environment is much more comfortable. Of course, the running costs are correspondingly lower too. In the theatre CID discharge lamps are particularly useful in follow spotlights. The very high light output from a point source creates a very intense, sharp beam.
  • Page 110 Exhaust tip off Quartz envelope Tungsten electrode Metal Halide dose Pinch seal Molybdenum foil Ceramic base Contact pin GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE Nitrogen filling gas Contact pin Arctube Reflector Front lens...
  • Page 111 Cap/bulb interface capsule lamps - 450° maximum Above this figure the sealing foil oxidises at a rate increasing with temperature and is frequently the cause of short life due to seal failure.
  • Page 112 N.B. For sealed beam lamps - to ensure that the above conditions are met, it is important that the lamp does not operate above 400°C even in an enclosed fitting.
  • Page 113 Spectral distribution of luminous flux (lumens) for CSI discharge lamps wavelength (nm) Spectral distribution of luminous flux (lumens) for CID discharge lamps wavelength (nm) GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...

  • Page 114: Index

    Index Lamp type PAR lamps by order code 25PAR36 25PAR36/NSP 25PAR36/WFL 25PAR36/VWFL 50PAR36/VNSP 50PAR36/NSP 50PAR36/WFL 50PAR36/VWFL 50PAR36/WFL/H 150PAR46/3MFL 200PAR46/3MFL 120PAR56/VNSP 120PAR56/MFL 120PAR56/WFL 200PAR 240PAR56/VNSP 240PAR56/MFL 240PAR56/WFL GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • •...
  • Page 115 500PAR64/MFL Q500PAR56/NSP Q500PAR56/MFL Q500PAR56/WFL Q500PAR64/VNSP Q500PAR64/NSP Q500PAR64/MFL 500PAR64/WFL 500PAR64/MFL 800PAR/POWERSAVER Q1000PAR64/NSP Q1000PAR64/MFL Q1000PAR64/VNSP • • • • • • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 116 Lamp type 4405 4435 4502 4505 4509 4509X 4511 4515 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 117 4537 4537-2 4545 4546 4547 4551 4552 Q4554 4559 Q4559 Q4559X 4570 4571 4572 4580 • • • • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 118 Lamp type 4581 4587 4591 4593 4594 4595 4596 4626 4627 4635 Q4597 Q4681 H7604 H7616 H7635 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • • •...
  • Page 119 Lamp type page Theatre lamps by LIF code TV Film & Studio lamps by LIF code CP23 CP24 • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 120 CP32 CP39 CP40 CP41 CP43 CP51 CP52 CP53 CP58 CP59 CP60 CP61 CP62 CP70 CP77 CP79 CP81 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • • • •...
  • Page 121 CP91 CP92 CP93 CP94 CP95 CP105 HX48 HX270 HX800 • • • • • • • • • • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 122 Lamp type High Performance Lamps HPL575 HPL575-XLL HPL750 Theatre TV Film & Studio lamps by ANSI code DKX/DSF DKZ/DSE GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • •...
  • Page 123 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 124 Lamp type FLK/LL GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • • • • • • • • •...
  • Page 125 Lamp type page GKV/LL Linear TV & Studio lamps by LIF code P2/6 P2/7 P2/10 P2/11 P2/12 • • • • • • • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 126 Lamp type P2/13 P2/27 P2/28 Linear TV Film & Studio lamps by ANSI code GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • • • • • • •...
  • Page 127 Lamp type page SINGLE ENDED MINIS SINGLE ENDED DOUBLE ENDED Discharge lamps 99-0201 99-0221 99-1222 99-1422 99-0211 99-0222 99-0415 99-0431 99-1225 • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 128 Lamp type 99-1425 99-1435 150/850 575/855 Blacklight blue F20 T12/BLB F40 BLB Specialist Projector lamps by LIF code A1/215 A1/216 A1/220 A1/223 A1/226 A1/227 A1/229 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • •...
  • Page 129 A1/261 A1/262 A1/264 A1/266 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 130 Lamp type A1/268 A1/270 HX501 HX185 Specialist Projector lamps by ANSI code BRJ/EVB GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • • • • • • •...
  • Page 131 Lamp type page DZE/FDS ELD/EJN • • • • • • • • • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 132 Lamp type ELS/ELR EMM/EKS ENW/ENC GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 133 Lamp type page EZF/EZJ • • • • • • • • • • • • • • • • • • • • • • • • • • • GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 134 Lamp type GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE page • • • • • • • • • • • • • • • • • • • • • • • • • •...

  • Page 135: Ge Lighting World Addresses

    125-127 Long Street Smithfield, NSW 2164 Tel: (61) 2 9729 0011 Fax: (61) 2 9629 1144 AUSTRIA GE Lighting/Plastics Austria Gmbh & Co KG Altmannsdorfer Anger 70 1120 Wien Tel: (43) 1 80184-0 Fax: (43) 1 80184-4 BELGIUM / NETHERLANDS...
  • Page 136 Office Kosmodamianskaya nab.52 Building 1, 6th Floor Moscow 113054 Tel: (7) 095 935 7281 Fax: (7) 095 935 7279 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE COLOMBIA GEICO Ltda. Carrera 99#46A-46 Santafe de Bogota Tel: (57) 1 298 1764 Fax: (57) 1 415 3888 CZECH REPUBLIC GE Lighting spol.
  • Page 137 Tokyo 101-0041 Tel: (813) 5296 2911 Fax: (813) 5296 2920 KAZAKHSTAN GE Lighting Tungsram Representative Office 153 Abaya Avenue, ap. 13-14 480024 Almaty Tel: (7) 32 72 503 162 Fax: (7) 32 72 400 558 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 138 Skopskie Saem 81000 Skopje Tel: (389) 70 217 649 Fax: (389) 91 386 125 MEXICO GE Lighting Mexico, SA de CV Av. Churubusco No 3900 Norte Apartado Postal 216 64510 Monterrey, N.L. Mexico Tel: (52) 8 318 5600 Fax: (52) 8 318 5693...
  • Page 139 113 85 Stockholm Tel: (46) 8 457 96 00 Fax: (46) 8 457 96 50 SWITZERLAND GE Lighting AG Thurgauerstr. 40 8050 Zurich Tel: (41) 1 307 12 00 Fax: (41) 1 307 12 01 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 140 General Electrik T.A.S. Duvatpasa Cad. No.4. 34020 Topkapi Istanbul Tel: (90) 212 544 4400 Fax: (90) 212 576 0979 GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE UKRAINE General Electric Co. 42/44 Shelkovichnaya str. Kiev 252004 Tel: (38) 044 459 0483 Fax: (38) 044 459 0482 UNITED KINGDOM GE Lighting Ltd.
  • Page 141 Notes GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
  • Page 142 Notes GE LIGHTING - ENTERTAINMENT LIGHTING CATALOGUE...
