Electra ER-280NF Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

FEATURE CHART

!
@
#
$
%
^
&
*
(
)
! ICE TRAY
@ F SHELF (MOVABLE)
# FREEZER TEMPERATURE
CONTROL KNOB
$ ICE BOX
% CHILLED CASE
^ LAMP COVER
& REFRIGERATOR TEMPERATURE
CONTROL SWITCH
* R SHELF (MOVABLE)
( VEGETABLE CASE COVER
) VEGETABLE CASE
1 FREEZER POCKET
2 UTILITY POCKET
3 EGG CASE
4 BOTTLE POCKET(LARGE)
5 BOTTLE POCKET(SMALL)
1
1
3
2
4
5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ER-280NF and is the answer not in the manual?

Questions and answers

Related Manuals for Electra ER-280NF

Summary of Contents for Electra ER-280NF

  • Page 1: Feature Chart

    FEATURE CHART & ! ICE TRAY * R SHELF (MOVABLE) @ F SHELF (MOVABLE) ( VEGETABLE CASE COVER # FREEZER TEMPERATURE ) VEGETABLE CASE 1 FREEZER POCKET CONTROL KNOB $ ICE BOX 2 UTILITY POCKET % CHILLED CASE 3 EGG CASE ^ LAMP COVER 4 BOTTLE POCKET(LARGE) &...
  • Page 2 Here are the features of your new refrigerator. Take a moment to know all the features designed for the convenience of the user. Ice Tray Fill 3/4 of the ice tray with water, as the volume expands when the water is frozen. Place the tray in the freezer compartment.
  • Page 3 Lamp cover To remove the lamp cover 1. Push up the bottom end of lamp cover gently, then pull out. 2. Reverse procedure to join together. Vegetable case May be used for fruit and vegetable storage. Both the vegetable case and its cover shelf are removable for easy cleaning.

  • Page 4: Methods Of Safe Installation

    METHODS OF SAFE INSTALLATION 1. SAFE INSTALLATION PLACE FOR YOUR REFRIGERATOR Place the refrigerator on a Place your refrigerator Place the refrigerator in an • • • strong and level floor. where there is no heat area where the humidity Unstable installation can source nearby.

  • Page 5: Installation Steps

    2. INSTALLATION STEPS Select a safe place to install Level the refrigerator by Install the parts in their own • • • your refrigerator. using the adjustable feet. place. Maintain ~ Level Check if the doors are Check the voltage. Put food in the refrigerator •...

  • Page 6: Relocating The Refrigerator

    3. WHAT YOU NEED TO KNOW BEFORE MOVING OR RELOCATING THE REFRIGERATOR! Unplug the power cord. Remove the grille with driver Take food out of the • • • and water from the defrost- refrigerator. drain vessel located at the rear of the refrigerator.

  • Page 7: Cleaning Your Refrigerator

    4. CLEANING YOUR REFRIGERATOR Before you clean the The refrigerator may smell Use a soft cloth for cleaning • • • refrigerator, unplug the during initial operation, but the interior and exterior of power cord. To clean, use a the odour will fade away the refrigerator.

  • Page 8: How To Install

    How to Install Location Install the refrigerator in a convenient location away from extreme heat and cold. Allow at least 6cm clearance between the refrigerator and side wall so that the door may open for a fully usable interior and the refrigerator may have good air circulation. The refrigerator is not designed for recessed installation.

  • Page 9: Temperature Control

    How to operate 1. TEMPERATURE CONTROL Temperature is controlled automatically by a thermostat. The Temperature Control inside the refrigerator controls the degree of cooling for each compartment. Freezer Temperature Control Refrigerator Temperature Control TEMP. CONTROL WINTER MAX WINTER TEMP. CONTROL The control has four settings from MIN to The control has four settings from MIN to WINTER.

  • Page 10: Defrosting The Refrigerator

    Turn the temperature control in the refrigerator and freezer compartments toward WINTER for colder temperature and toward MIN for warmer temperature. Allow approximately 12 hours or overnight for the temperature to stabilize, then check to see if further adjustments are necessary. To turn off the refrigerator Turn the power off at the wall.

  • Page 11: Power Cord Replacement

    WHAT TO DO... When not operating for a long time Remove the power supply cord. Dry your refrigerator by opening the door for 2-3 days. When you get ready to move Securely fasten movable interior parts (or remove and pack them separately) DO NOT lay down your refrigerator horizontally, or the compressor may be damaged.
  • Page 12 REFRIGERATOR INSTRUCTION MANUAL ER-280NF MODEL NO.: Thank you for selecting this refrigerator. Before using the refrigerator, please read this manual carefully.
