GSM2200N
GE Spacemaker Under-the-Sink Dishwasher
®
Note: A close-fitting elbow or special
shallow sink strainer is necessary to
provide clearance between sink drain
and dishwasher. Dishwasher furnished
with 1/2" I.D. drain hose, 78" long. If using
copper tubing, 2" length of 1/2" I.D. rubber
hose must be provided to connect copper
tubing to pump outlet. Disposer should
have 7/8" I.D. dishwasher drain connector.
Rough-In for Installation with Disposer Dimensions
(in inches)
Directional flow tee
FRONT VIEW
Drain
connection
4
1-1/2" MAX.
dia. hole
12" From wall
6
10"
Allow a 5"
from
radius to
cabinet
prevent kinking
6" Double-bowl
stainless steel sink
GFC290/300/700
Disposall
®
unit
1-1/2"
Directional
flow tee
Cold water
Hot water
Valve to shut off
water to dishwasher
Hot water supply
Dishwasher
to dishwasher
drain hose
Rear View Plumbing Arrangement Dimensions
(in inches)
Waste air gap
To
air
GFC290/300/700
gap
Waste tee
or disposer
Remove hopper plug
before connecting
dishwasher drain
Sink
Countertop
strainer
25" deep
assembly
1-1/2" thick
1-1/2" Close
elbow
Spacemaker
®
dishwasher
Dishwasher
water inlet
valve
Electrical
junction box
(on dishwasher)
10"
Allow a 5"
from
radius to
cabinet
prevent kinking
6" Double-bowl
stainless steel sink
Disposall
®
unit
1-1/2"
Directional
Spacemaker
flow tee
dishwasher
Cold water
Hot water
Valve to shut off
water to dishwasher
Hot water supply
Dishwasher
to dishwasher
drain hose
Listed by
Underwriters
Laboratories
Specification Created 4/07
Sink
Countertop
strainer
25" deep
assembly
1-1/2" thick
1-1/2" Close
elbow
®
Dishwasher
water inlet
valve
Electrical
junction box
(on dishwasher)
