OPERATION & PARTS MANUAL
SERIES
MODEL MVH-R60H
REVERSABLE PLATE COMPACTOR
(HONDA GASOLINE ENGINE)
Revision #1 (09/09/04)
THIS MANUAL MUST ACCOMPANY
THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVH-R60H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MULTIQUIP MVH-R60H

Summary of Contents for MULTIQUIP MVH-R60H

  • Page 1 OPERATION & PARTS MANUAL SERIES MODEL MVH-R60H REVERSABLE PLATE COMPACTOR (HONDA GASOLINE ENGINE) Revision #1 (09/09/04) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 PAGE 2 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 3 © COPYRIGHT 2004, MULTIQUIP INC. Multiquip Inc and the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of thier respective owners and used with permission.

  • Page 4: Table Of Contents

    Vibrator Assembly ..........36-37 Body Assembly ..........38-41 Vibrating Plate Assembly ........42-43 Water Tank/Sprinkler Assembly......44-45 NOTE Specification and part number are subject to change without notice. PAGE 4 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)

  • Page 5: Here's How To Get Help

    Parts Department: POST OFFICE BOX 6254 CARSON, CALIFORNIA 90749 310-537-3700 • 800-421-1244 Toll-free nationwide — 800-427-1244 FAX: 310-537-3927 Toll-free FAX — 800-6-PARTS-7 E-MAIL: mq@multiquip.com (800/672-7877) INTERNET: www.multiquip.com MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 5...

  • Page 6: Specifications

    - y l i t r l i o t r a . n i s b l ) . g PAGE 6 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)

  • Page 7: Dimensions

    MVH-R60H — DIMENSIONS Figure 1. MVH-R60H Dimensions . n i . n i . n i i s n MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 7...

  • Page 8: Safety Message Alert Symbols

    You CAN be KILLED or SERIOUSLY injured if you DO NOT follow directions. CAUTION - Respiratory Hazard CAUTION ALWAYS wear approved respiratory protection when required. You CAN be INJURED if you DO NOT follow directions. PAGE 8 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 9 CAUTION - Sight and Hearing Hazards ALWAYS wear approved eye and hearing protection. MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 9...

  • Page 10: Rules For Safe Operation

    These devices are intended for operator safety. Disconnection running. of these devices can cause severe injury, bodily harm or even death! Disconnection of any of these devices will void all warranties. PAGE 10 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 11 . Also know the phone numbers of the nearest ambulance , doctor and fire department . This information will be invaluable in the case of an emergency. MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 11...

  • Page 12: Operation And Safety Decals

    Machine Safety Decals The MVH-R60H Reversible Plate Compactor is equipped with a number of safety decals. These decals are provided for operator safety and maintenance information. The illustration below shows these decals as they appear on the machine. Should any of these decals become unreadable, replacements can be obtained from your dealer.
  • Page 13 Due to their weight and force, reversible plates are ideal for semi-cohesive soils. MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 13...

  • Page 14: Components (Plate Compactor)

    Ataches to the front of the R60's frame. position for full throttle (max RPM's), for engine idle, move the throttle lever to the turtle position. PAGE 14 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 15 10. Fuel Tank – Holds unleaded gasoline. For additional smoothly. information refer to engine owner's manual. 5. Fuel Valve Lever – OPEN to let fuel flow, CLOSE to stop the flow of fuel. MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 15...

  • Page 16: Inspection

    NOT start the engine near spilled fuel or combustible fluids. DO NOT smoke while refueling. DO NOT attempt to refuel the pump if the engine is hot! or running . PAGE 16 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 17 7. Before the compactor is put into operation run the engine for mixture for normal operation after 3-5 minutes. starting, and for restarting a warm engine. 8. Check for abnormal engine noises or fuel leaks. MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 17...
  • Page 18 2. Place the Engine ON/OFF switch (Figure 13) in the OFF position. Figure 13. Engine ON/Off Switch (OFF Position) 3. Place the fuel valve lever (Figure 14) in the OFF position. Figure 14. Fuel Valve Lever (OFF Position) PAGE 18 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)

  • Page 19: Operation

    5. Slowly walk behind the compactor and be on the lookout for any large objects or foreign matter that might cause damage to the compactor or bodily injury. MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 19...

  • Page 20: Maintenance

    PAGE 20 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 21 4. Remember to refill engine crankcase with the recommended type of oil as listed in Table 4 (For more details, see separate Figure 18. Air Filter Honda Owner's Manual). Figure 17. Engine Oil Plug MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 21...
  • Page 22 3. If the V-belt becomes worn or loose, replace the belt. A loose V-belt will decrease the power transmission output, causing reduced compaction and premature wear of the belt. PAGE 22 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 23 Oil #46 or equivalent. 4. Removing the vibrator cylinder breather plug causes oil to flow out of breather hole for a while. When aeration disappears, replace the plug and tighten securely. MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 23...

  • Page 24: Troubleshooting (Engine)

    . r o l i f r e t t l i f . r e r i A n i l n i l PAGE 24 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 25 . r e i o c r a t r e t u f l o i t a i r i r p l a i n i r MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 25...

  • Page 26: Troubleshooting (Plate Compactor)

    . t a i l y t s i t s i i r a n i l v i t n i r PAGE 26 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 27 NOTE PAGE MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 27...

  • Page 28: Explanation Of Codes In Remarks Column

    NOTE one listed indicates newest (or latest) part available. NOTE The contents of this catalog are subject to change without notice . PAGE 28 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)

  • Page 29: Suggested Spare Parts

    1 ..28462ZH8003 ... ROPE, RECOIL STARTER 3 ..17210ZE0822 ... ELEMENT, AIR CLEANER 1 ..17620ZH7023 ... FUEL CAP 1 ..17672ZE2W01 . FUEL FILTER, FUEL TANK MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 29...
  • Page 30 MVH-R60H — NAME PLATES AND DECALS NAME PLATES ASSY. PAGE 30 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 31 DECAL, SHELL TELLUS OIL 46 DECAL, SERIAL NO........1 ....CONTACT PARTS DEPT. 920110000 DECAL, MVH-R60 920207420 DECAL, V-BELT RPF-3320 920209520 DECAL, OPERATIONAL CAUTION 920201650 DECAL, OIL SAE 10W30 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 31...
  • Page 32 MVH-R60H — CONTROL HANDLE ASSY. CONTROL HANDLE ASSY. PAGE 32 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 33 CLAMP SA120-18 001220620 BOLT 6X20 T 020306050 NUT M6 030206150 WASHER, LOCK M6 031106100 WASHER, FLAT M6 463455940 BREATHER CAP 463455960 THROTTLE NUT 001520510 SOCKET HEAD BOLT 5X10 T MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 33...
  • Page 34 MVH-R60H — CONTROL HANDLE ASSY. (CONTINUED) CONTROL HANDLE ASSY. (CONTINUED) PAGE 34 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 35 096208020 SOCKET HEAD SCREW 8X20 020408050 NUT M8, H+5 956100047 THROTTLE WIRE 845-925 001220625 BOLT 6X25 T 030206150 WASHER, LOCK M6 031106100 WASHER, FLAT M6 511010040 CLAMP TC-300 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 35...
  • Page 36 MVH-R60H — VIBRATOR ASSY. VIBRATOR ASSY. PAGE 36 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 37 SOCKET HEAD BOLT 6X40 T 001521030 SOCKET HEAD BOLT 10X30 T 001521060 SOCKET HEAD BOLT 10X100 T 463456200 SPRING 1.2X15.6X130 080100190 STOP RING R-19 031108160 WASHER, FLAT M8 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 37...
  • Page 38 MVH-R60H — BODY ASSY. BODY ASSY. PAGE 38 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 39 458450860 STOPPER 458450861 STOPPER ..........1..... USE W/ ITEM 23 ................... (GUARD FRAME W/ WATER TANK) 458450880 SPRING 1.2-10-29 458450850 GRIP 025402516 SPRING PIN 2.5X16 458450830 RUBBER COVER MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 39...
  • Page 40 MVH-R60H — BODY ASSY. BODY ASSY. PAGE 40 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 41 15550ZK8P90 DRAIN JOINT 15552ZB9000 DRAIN HOSE 954010070 HOSE BAND 11.5D 90601ZE1000 WASHER, DRAIN PLUG 90131ZE1000 BOLT, DRAIN PLUG 458450840 JOINT 001220820 BOLT 8X20 T 030208200 WASHER, LOCK M8 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 41...
  • Page 42 MVH-R60H — VIBRATING PLATE ASSY. VIBRATING PLATE ASSY. PAGE 42 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 43 SHOCK ABSORBER TAK-50 020310080 NUT M10 030210250 WASHER, LOCK M10 001221030 BOLT 10X30 T 030210250 WASHER, LOCK M10 952401660 WASHER 103045 460449160 OIL GAUGE 953405260 PACKING 1/4 (CU) MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 43...
  • Page 44 MVH-R60H — WATER TANK/SPRINKLER ASSY. WATER TANK/SPRINKLER ASSY. PAGE 44 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 45 SPRINKLING PIPE ..........1 ..... INCLUDES ITEMS W/$ 458450830 RUBBER COVER 001220825 BOLT 8X25 031108160 WASHER, FLAT 458450810 PLATE, RUBBER COVER 022710809 NYLON NUT M8 001221230 BOLT 12 X30 030212300 WASHER, LOCK M12 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 45...
  • Page 46 HONDA GX120K1SM12 ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. PAGE 46 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)

  • Page 47: Cylinder Head Assembly

    TUBE, BREATHER 90013883000 BOLT, FLANGE 6X12 (CT200) 90043ZE1020 BOLT, STUD 6X109 90047ZE1000 BOLT, STUD 8X32 9430110160 PIN, A, DOWEL 10X16 957230805500 BOLT, FLANGE 8X55 9807956846 SPARK PLUG BPR6ES (NGK) MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 47...
  • Page 48 HONDA GX120K1SM12 ENGINE — CYLINDER BARREL ASSY. CYLINDER BARREL ASSY. PAGE 48 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 49 BEARING, RADIAL BALL 62/22 91202ZE6003 OIL SEAL 22X35X6 91353671004 O- RING 14mm 9405010000 NUT, FLANGE 10mm 9410106800 WASHER, PLAIN 6mm 9425108000 PIN, LOCK 8mm 957010601200 BOLT, FLANGE 6X12 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 49...
  • Page 50 HONDA GX120K1SM12 ENGINE — CRANKCASE COVER ASSY. CRANKCASE COVER ASSY. PAGE 50 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 51 CAP ASSY., OIL FILLER ......... 1 ....INCLUDES ITEMS W/ 11 # 15625ZE1003 PACKING, OIL FILLER CAP 90015883000 BOLT, FLANGE 6X28 91001878003 BEARING, RADIAL 62/22 91203ZE0003 OIL SEAL 22X41X6 9430108140 DOWEL PIN 8X14 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 51...
  • Page 52 HONDA GX120K1SM12 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PAGE 52 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 53 HONDA GX120K1SM12 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PART NO. PART NAME QTY. REMARKS 13310ZE0601 CRANKSHAFT MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 53...
  • Page 54 HONDA GX120K1SM12 ENGINE — PISTON/CONNECTING ROD ASSY. PISTON/CONNECTING RODASSY. PAGE 54 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 55 ROD ASSY, CONNECTING (UNDER SIZE) ..1 ..INCLUDES ITEMS W/ 13200ZE0000 ROD ASSY., CONNECTING ......1 ..INCLUDES ITEMS W/ 90001ZE1000 BOLT, CONNECTING ROD 90551ZE0000 CLIP, PISTON PIN 13MM MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 55...
  • Page 56 HONDA GX120K1SM12 ENGINE — CAMSHAFT ASSY. CAMSHAFT ASSY. PAGE 56 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 57 SPRING, VALVE 14771ZE1000 RETAINER, IN. VALVE SPRING 14773ZE1000 RETAINER, EX. VALVE SPRING 14781ZE1000 ROTATOR, VALVE 14791ZE0010 PLATE, PUSH ROD GUIDE 90012ZE0010 BOLT, PIVOT 8MM 90206ZE1000 NUT, PIVOT ADJ. MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 57...
  • Page 58 HONDA GX120K1SM12 ENGINE — RECOIL STARTER ASSY. RECOIL STARTER ASSY. PAGE 58 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 59 28433ZH8003 GUIDE, RATCHET 28441ZH8003 SPRING, FRICTION 28442ZH8003 SPRING, RECOIL STARTER 28443ZH8003 SPRING, RETURN 28461ZH8003 KNOB, RECOIL STARTER 28462ZH8003 ROPE, RECOIL STARTER 90003ZH8003 SCREW, SETTING 9008ZE2003 BOLT, FLANGE 6X10 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 59...
  • Page 60 HONDA GX120K1SM12 ENGINE — FAN COVER ASSY. FAN COVER ASSY. PAGE 60 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 61 SWITCH ASSEMBLY, ENGINE STOP 36101ZE1010 WIRE, STOP SWITCH 370MM 90013883000 BOLT, FLANGE 6X12 (CT200) 90022888010 BOLT, FLANGE 6X12 (CT200) 34150ZH7003 ALERT UNIT, OIL 95 7010600800 BOLT, FLANGE 6X8 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 61...
  • Page 62 HONDA GX120K1SM12 ENGINE — CARBURETOR ASSY. CARBURETOR ASSY. PAGE 62 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 63 16967ZE0811 CUP, FUEL STRAINER 93500030061H SCREW, PAN (3 X 6) 9430520122 PIN, SPRING (2 X 12) 99101ZH80600 JET, MAIN (#60) 99204ZE00350 JET, SET, PILOT (#35) 16016ZH7W01 SCREW SET MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 63...
  • Page 64 HONDA GX120K1SM12 ENGINE — AIR CLEANER ASSY. AIR CLEANER ASSY. PAGE 64 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 65 COLLAR B, AIR CLEANER 17410ZE0030 ELBOW, AIR CLEANER ........1..... INCLUDES ITEMS W/ 90325044000 WINGNUT, TOOL BOX SETTING 957010602000 BOLT, FLANGE 6X20 9405006000 NUT, FLANGE 6MM 9410106800 PLAIN WASHER 6MM MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 65...
  • Page 66 HONDA GX120K1SM12 ENGINE — MUFFLER ASSY. MUFFLER ASSY. PAGE 66 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 67 PROTECTOR, MUFFLER 18340ZE1010 DEFLECTOR 18355ZE1000 ARRESTER, SPARK 18381ZH8800 GASKET, MUFFLER 90050ZE1000 SCREW, TAPPING 5X8 94001080000S NUT, HEX. 8MM 18522ZE1000 GUIDE, MUFFLER 90055ZE1000 SCREW, TAPPING 4X6 90002ZG0003 SCREW, TAPPING 4X8 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 67...
  • Page 68 HONDA GX120K1SM12 ENGINE — FUEL TANK ASSY. FUEL TANK ASSY. PAGE 68 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 69 GASKET, FUEL FILLER CAP 17672ZE2W01 FUEL FILTER 91353671004 O- RING 14MM 9405006000 NUT, FLANGE 6MM 950014514040 BULK HOSE, FUEL 4.5X140 9500202080 CLIP, TUBE (B8) 957010602500 BOLT, FLANGE 6X25 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 69...
  • Page 70 HONDA GX120K1SM12 ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PAGE 70 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 71 HONDA GX120K1SM12 ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PART NO. PART NAME QTY. REMARKS 13331357000 KEY, SPECIAL WOODRUFF 25X18 19511ZE0000 FAN, COOLING 28451ZH8003 PULLEY, STARTER 31100ZE0010 FLYWHEEL 90201878003 NUT, SPECIAL 14MM MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 71...
  • Page 72 HONDA GX120K1SM12 ENGINE — IGNITION COIL ASSY. IGNITION COIL ASSY. PAGE 72 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 73 HONDA GX120K1SM12 ENGINE — IGNITION COIL ASSY. IGNITION COIL ASSY. PART NO. PART NAME QTY. REMARKS 30500ZE1033 COIL ASSY., IGNITION 30700ZE1013 CAP ASSY., NOISE SUPPRESSOR 90121952000 BOLT, FLANGE 6X25 MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 73...
  • Page 74 HONDA GX120K1SM12 ENGINE — CONTROL ASSY. CONTROL ASSY. PAGE 74 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 75 26 # 90114SA0000 NUT, SELF- LOCK 6MM 28 # 93500040060H SCREW 4X6 30 # 93500050250H SCREW, PAN 5X25 32 # 93500050160A SCREW, PAN 5X16 9405006000 NUT, FLANGE 6MM MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 75...
  • Page 76 HONDA GX120K1SM12 ENGINE — LABELS ASSY. LABELS ASSY. PAGE 76 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 77 HONDA GX120K1SM12 ENGINE — LABELS ASSY. LABELS ASSY. PART NO. PART NAME QTY. REMARKS 87521ZH7020 EMBLEM 87522ZH9000 LABEL, CAUTION 87528ZE1810 MARK, CHOKE 87532ZH8810 MARK, OIL ALERT (E) MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 77...

  • Page 78: Terms And Conditions Of Sale - Parts

    Multiquip’s designated receiving point. on hand at the time of any price change. PAGE 78 — MVH-R60H— OPERATION AND PARTS MANUAL — REV. #1 (09/09/04)
  • Page 79 NOTE PAGE MVH-R60H —OPERATION AND PARTS MANUAL — REV. #1 (09/09/04) — PAGE 79...

  • Page 80: Please Have The Model And Serial

    800-421-1244 FAX: 310-631-5032 WARRANTY DEPARTMENT 800-421-1244, EXT. 279 FAX: 310-537-1173 310-537-3700, EXT. 279 Your Local Dealer is: MULTIQUIP INC..18910 WILMINGTON AVE. CARSON, CALIFORNIA 90746 800-421-1244 • 310-537-3700 FAX: 310-537-3927 E-mail:mq@multiquip.com Internet:multiquip.com Atlanta • Boise • Dallas • Houston • Newark Montreal, Canada •...
