Husqvarna MRT6 Illustrate Parts List

Husqvarna MRT6 Illustrate Parts List

Rear tine tiller
Hide thumbs

Advertisement

Table of Contents

ILLUSTRATED PARTS LIST

MODEL NUMBER MRT6
PRODUCT NUMBER 960 91 00-21
MFG. ID NO. 96091002104
581 81 83-27 Rev. 4 08.14.13 BY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MRT6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Husqvarna MRT6

Summary of Contents for Husqvarna MRT6

  • Page 1: Illustrated Parts List

    ILLUSTRATED PARTS LIST MODEL NUMBER MRT6 PRODUCT NUMBER 960 91 00-21 MFG. ID NO. 96091002104 581 81 83-27 Rev. 4 08.14.13 BY...
  • Page 2 HUSQVARNA REAR TINE TILLER - MODEL NO. MRT6 (MFG. ID. NO. 96091002104) HANDLE ASSEMBLY 12 13 handle_assy_107 PART PART DESCRIPTION DESCRIPTION 819 13 16-11 Washer 13/32 x 1 x 11 Gauge 532 18 94-82 Control, Throttle 532 42 76-43 Grip, Handle...
  • Page 3 HUSQVARNA REAR TINE TILLER - MODEL NO. MRT6 (MFG. ID. NO. 96091002104) MAINFRAME, LEFT SIDE 28 3 mainframe_left_24pita3 PART PART DESCRIPTION DESCRIPTION 873 93 06-00 Nut, Hex 3/8-16 28 532 10 46-79 Pulley, Idler 583 87 77-01 Shield, Inner Belt Guard, R.H.
  • Page 4 HUSQVARNA REAR TINE TILLER - MODEL NO. MRT6 (MFG. ID. NO. 96091002104) MAINFRAME, RIGHT SIDE PART PART DESCRIPTION DESCRIPTION 873 97 05-00 Locknut, Hex, Flanged 5/16-18 - - - Engine, Briggs & Stratton 581 86 47-01 Bracket, Reinforcement Model Number 121002-3423-H8 581 01 04-01 Counter Weight, R.H.
  • Page 5 HUSQVARNA REAR TINE TILLER - MODEL NO. MRT6 (MFG. ID. NO. 96091002104) TRANSMISSION PART PART DESCRIPTION DESCRIPTION 532 18 85-54 Transmission Assembly 532 15 07-37 Ground Shaft Assembly (In cludes Key Numbers 2–53) 532 14 30-08 Bearing, Shaft, Ground Drive, R.H.
  • Page 6 HUSQVARNA REAR TINE TILLER - MODEL NO. MRT6 (MFG. ID. NO. 96091002104) TINE SHIELD 28 24 tine_shield-rear_17_pita2 PART PART DESCRIPTION DESCRIPTION 532 15 53-77 Locknut, Hex, Flanged 5/16-18 532 00 44-40 Hinge 532 19 57-97 Shield, Side, Outer, L.H. 872 14 04-04...

  • Page 7: Tine Assembly

    HUSQVARNA REAR TINE TILLER - MODEL NO. MRT6 (MFG. ID. NO. 96091002104) TINE ASSEMBLY tine_ipb_1 PART PART DESCRIPTION DESCRIPTION 532 00 44-59 Tine, Outer, L.H. 10 581 81 37-01 Assembly, Hub and Plate, R.H. 532 13 26-73 Clevis Pin 11 532 00 65-55 Tine, Inner, R.H.
  • Page 8 HUSQVARNA REAR TINE TILLER - MODEL NO. MRT6 (MFG. ID. NO. 96091002104) DECALS PART DESCRIPTION 532 15 98-77 Decal, Hand Placement 532 10 21-80 Decal, Shift Indicator 532 14 54-37 Decal, Euro, C.E. 532 43 53-35 Decal, Engine, B&S 532 17 65-57...
