- Page 1 TXX-BD2-12 TXX-BD2-15 All Audiopipe products are designed, manufactured and tested to perform in harsh environments. From our entry level products to our high end series, Audiopipe is your best choice for competition level performance. We welcome you to Team Audiopipe.
- Page 2 Warranty Building an Enclosure...
- Page 3 (a copy of the original receipt) listing the customer name, dealers name, invoice number and product purchased. Items sent freight collect or COD will be refused. Call the Audiopipe customer service number 9 am to 5pm eastern standard time at 1-877-AUDIOPIPE (1-877-283-4674) for a return authorization number (RMA).
- Page 4 TXX-BD2-10 TXX-BD2-12 TXX-BD2-15 Ø254mm Ø300mm Ø381mm Nominal Diameter 10” 12” 15” Ø266mm Ø321mm Ø398mm Overall Diameter(A) 10 1/2” 12 5/8” 15 11/16” Ø225mm Ø275mm Ø351mm Mounting Hole Diameter(B) 8 7/8” 10 7/8” 13 7/8” Ø242mm Ø370mm Ø294mm Bolt Hole Circle(C) 9 1/2”...
- Page 5 Features • Dual Voice Coil BASV • Powdered Black Paint Aluminum Basket • Patent Pipe Multi-Connect Terminal • Dual Magnet TXX-BD2-10 TXX-BD2-12 TXX-BD2-15 Fs (Hz) Re (Ohms) 2x3.6 2x3.6 2x3.6 Le (mH) 0.49 0.46 0.45 0.53 0.49 0.49 2.48 0.12 Cms (m/N) 0.13...
-
Page 6: Building An Enclosure
Building an enclosure When building an enclosure, the walls should be as rigid as possible and not flex. Flexing of the enclosure can drastically decrease your subwoofers performance. It is recommended that Enclosures be built using 3/4” MDF, be glued and secured with nails or screws. - Page 7 The TXX-BD2 series of subwoofers are available with dual 4 Ohms voice coils. Both coils must be connected to a source of amplification. A dual 4 Ohms woofer can be configured in parallel to provide a 1 Ohm load. A dual 4 Ohms woofer can be also configured in series to provide a 8 Ohms load.
-
Page 8: Calculating Volume
Sealed enclosure This type of enclosure is classic and the simplest to build among most installers. The box volume will directly impact the performance of the subwoofer, it is important to make sure the enclosure is properly sealed. Use some type of sealant on the seams as this will ensure a solid construction and prevent air leaks. - Page 9 Recommended Sealed Enclosure Everyday Bass Performer Competition Bass Performer TXX-BD2-10 1.0 cu ft. 1.5 cu ft. TXX-BD2-12 1.5 cu ft. 2.0 cu ft. TXX-BD2-15 2.5 cu ft. 3.0 cu ft.
- Page 10 Vented enclosure This type of enclosure is the installer’s top choice for high performance SPL levels and requires a deeper understanding in order to achieve maximum efficiency. The most notable difference between the sealed and vented enclosure is the port, this port is used to tune the enclosure.
- Page 11 Recommended Ported Enclosure Recommended Ported Enclosure Everyday Bass Performer Competition Bass Performer Volume Volume TXX-BD2-10 1.5 cu ft. 2” x 10” x 20” 2.0 cu ft. 2.5” x 11” x 20” TXX-BD2-12 2.5 cu ft. 2.5” x 12” x 14”...
