OverView NSL4621
46" nearseamless LCD video wall
Narrow bezel display for tiled video walls
The OverView NSL4621 46" tiled LCD video wall uses durable LED backlights
positioned directly behind the LCD panel and has a super narrow bezel,
resulting in excellent tiled visual performance. This video wall series was
designed for 24/7 use in control rooms. Its deep dark levels are perfect for
visualizing datadriven information, including process control schematics. The
OverView NSL4621's exceptionally high brightness levels allow these video
walls to be used in any lighting condition.
Advertisement
Related Manuals for Barco OverView NSL-4621
Summary of Contents for Barco OverView NSL-4621
- Page 1 OverView NSL4621 46" nearseamless LCD video wall Narrow bezel display for tiled video walls The OverView NSL4621 46" tiled LCD video wall uses durable LED backlights positioned directly behind the LCD panel and has a super narrow bezel, resulting in excellent tiled visual performance. This video wall series was designed for 24/7 use in control rooms. Its deep dark levels are perfect for visualizing ...
- Page 2 ⋅ Traffic management and surveillance centers ⋅ C4ISR environments ⋅ Utilities and process control centers ⋅ Broadcast & telecom monitoring Available as a complete video wall bundle Barco also offers complete preconfigured packages, containing four, six or eight OverView NSL4621 displays to create a 2x2, 3x2 or 4x2 video wall respectively. You can choose between three types of highquality controllers, depending on the main usage (choice between a Legacy Input package, a Monolithic package, and a Highperformance Networked package). All other needed equipment, including wall mounts, software and cables, are included...
- Page 3 26 kg | 57.3 lbs (net) 36 kg | 79.4 lbs (gross) Cooling Low noise fans AC input voltage 100240 VAC, 6050 Hz Power consumption 190 W (max) | 90 W (typ) | 20 W (sleep) | 2.5 W (stdby) Heat dissipation 819 BTU/h (max) Separate sync DSUB15P in/out Single link DVID in/out with HDCP Display port Display port input (Out via DVI) HDMI HDMI Type A with HDCP (Out via DVI) CVBS BNC in/out Svideo MiniDIN Sterminal in/out Barco NSL control manager Server connected via RS232 chain Remote client application: on/off, wall setup, source selection, status, brightness, contrast and color adjustments Component video 3xBNC in/out Control signal RS232 DSUB9 PIN in/out Operating humidity 2080% noncondensing Operational temperature 040°C | 32104°F Regulation Compliance CE, TÜV, cTÜVus, CCC, ROHS, WEEE Storage humidity 1090% noncondensing Storage temperature 2060°C | 4140°F Generated on: 23 Dec 2013 Technical specifications are subject to change without prior notice.
