Summary of Contents for Alfresco ALSB-2
- Page 2 BARBEQUE SERIAL NUMBER LABEL: NOTES:...
-
Page 3: General Safety Precautions
ALFRESCO™ Gourmet Grills A division of Superior Equipment Solutions, Inc. 7039 East Slauson Avenue Commerce, CA. 90040 3020914 Ph.: (888) 383-8800 Fax: (323) 726-4700 Web: www.alfrescogrills.com GENERAL SAFETY PRECAUTIONS: WARNING WARNING ELECTRICAL PARTS FLAMMABLE GAS DISCONNECT ALL PROPANE AND COMPONENTS... - Page 4 SIDE BURNER TO REDUCE THE RISK OF FIRE, BURN HAZARD OR OTHER INJURY. KEEP THIS MANUAL FOR FUTURE REFERENCE. When properly cared for, your ALFRESCO™ Side Burner will give safe, reliable service for many years. However, extreme care must be used since the Side Burner produces intense heat, which can increase accident potential.
- Page 5 (Safety, cont.) When lighting a burner, always pay close attention to what you are doing. Be certain you are de- pressing the correct igniter button labeled for the burner you intend on using. When using the Side Burner do not touch the Side Burner grate or immediate surrounding area as these areas become extremely hot and could cause burns.
- Page 6 This appliance should NOT be located over, under or next to unprotected combustible construction. ASSEMBLY: BUILT-IN MODELS: To locate your ALFRESCO™ Side Burner into your Non-combustible enclosure, complete the following steps: 1. Remove all packaging materials 2. Install and secure the body of the Side Burner to your counter’s enclosure.
- Page 7 BURNER PARTS: TOP COVER EXTERNAL CAP GRATE INTERNAL CAP ELECTRODE ASSEMBLY ORIFICE REGULATOR VENTURI FUNNEL LOCATION PIPE FITTING SIDE BURNER BODY Figure # 1 GAS CONNECTION—LIQUID PROPANE (LP) NEVER CONNECT THE SIDE BURNER TO AN UNREGULATED GAS SUPPLY. Before proceeding, ensure the unit is fitted for LP gas. Connecting to an improper gas type will result in poor performance and increased risk of damage or injury.
- Page 8 20 Lb. LP cylinder. The LP gas pressure regulator and hose supplied with this unit must be used without alteration. If this assembly needs to be replaced use only the type specified by ALFRESCO™ for this appliance. To connect the regulator / hose assembly follow the next steps: Locate the regulator and gas connection point in the rear side of your Side Burner unit .
-
Page 9: Natural Gas Connection
Your ALFRESCO™ Side Burner for use with Natural Gas comes equipped with its own regulator which MUST NOT be removed. If this regulator needs to be replaced use only the type specified by ALFRESCO™ for this appliance. -
Page 10: Leak Testing
LEAK TESTING: GENERAL: Although all gas connections on your ALFRESCO™ Side Burner are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mis- handling in shipment, or excessive pressure unknowingly being applied to the unit. -
Page 11: Before Testing
BEFORE TESTING: Make sure that all packing material is removed from the Side Burner. Make sure the burner tie-down straps are removed from the unit. Do not smoke while leak testing. Never leak test with an open flame. Make a soap solution of one part liquid detergent and one part water for leak testing purposes. Apply the solution to the gas fittings by using a spray bottle, or brush. -
Page 12: Burner Adjustments
PUSH TO IGNITE Figure # 4 PUSH & TURN TO “HI” NOTE: The first burner may take longer to light while air is purged from the gas supply system. If the burner does not light in 4 seconds, turn knobs to “OFF” and wait 5 minutes to allow any accumulat- ed gas to dissipate before trying again. -
Page 13: Adjustment Steps
However, some care is required to ensure that the stainless steel can live up to this reputation. DAY TO DAY CARE: To maintain the original appearance of your ALFRESCO™ Side Burner, a regular cleaning routine should be carried out using the following guidelines: 1. -
Page 14: Troubleshooting
If the preceding guidelines are adhered to, your ALFRESCO™ Side Burner should offer excellent life and should live up to its reputation of being “stainless”. Neglect of this practice, however, can lead to deterioration of the surface and, in some extreme cases, corrosion of the steel itself. - Page 15 WHEN TO LOOK FOR SPIDERS: You should inspect the burners at least twice a year or immediately if any of the following conditions oc- cur: 1. The smell of gas in conjunction with the burner flames appearing yellow. 2. The Side Burner does not reach temperature. 3.
- Page 16 damage to your Side Burner. Rodents are known to chew on the insulation of wiring which will eventually cause permanent damage to the wiring and possibly electrical components. One final consideration for Side Burners located either along the coast or in a desert community: Wind driven sand is highly abrasive, therefore constant exposure will eventually pit and scratch almost anything;...
-
Page 18: How To Obtain Service
IN THIS AREA ONLY ALL OTHER AREAS CALL (866) 203-5607 INQUIRIES AND INFORMATION: For all other Alfresco™ Gourmet Grill information such as power, installation, cut-out requirements, or any other product inquiries, please contact: Alfresco Gourmet Grills. (888) 383-8800 or (323) 722-7900 Customer Service Department. - Page 19 Limitations & Exclusions: 1. Alfresco’s warranty applies only to the original purchaser and may not be transferred. 2. Alfresco’s warranty is in lieu of all other warranties, expressed or implied and all other obligations or liabilities related to the sale or use of its grill products. 3. Alfresco’s warranty shall not apply and Alfresco is not responsible for damage resulting from misuse, abuse, alteration of or tampering with the appliance, accident, hostile environment, flare-up fires, improper installation, or installation not in accordance with the instructions contained in the User Manual, or the local codes.
