GE WB48X10056 Owner's Manual

Self-cleaning electric coil ranges
Hide thumbs Also See for WB48X10056:

Advertisement

Thank you for purchasing a GE cooking product! The broiler pan
referred to in the enclosed literature is not included and is
available as an optional accessory. You can order your broiler pan
(a $25 value) at a discount using the redemption coupon below or
by calling 1-800-626-2002 toll free.
Limited Time Offer!
Free Shipping
When you order your broiler pan within 30 days
of purchasing your GE cooking product
Get the Most out of your Broiler Pan!
Use your pan and grid cover to:
Broil hamburgers, seafood, steaks, vegetables, bacon,
chops, and so much more! The pan below catches the
excess fat and oils!
• Genuine GE Part
• Easy to Clean
• One Year Warranty
Small
Part #
WB48X10055
8-3/4" W
Dimensions
1-1/4" H
13-1/2" D
Price
$10.50
FREE SHIPPING!!
*The large (standard) broil pan does not fit in compact ranges.
**The XL pan does not fit in 24 inch wall ovens, 27 inch drop-ins, or compact ranges.
Call 1-800-626-2002 or
Use this mail-in form to place your order
Experience these other great products to keep your kitchen looking great!
Ceramic Cooktop
Cleaning Kit:
Includes cleaner,
scraper and pad
WX10X117GCS
$12.75
.
Large*
WB48X10056 WB48X10057
12-3/4" W
1-1/4" H
1-1/4" H
16-1/2" D
19-1/4" D
$14.50
$16.75
Ceramic Cooktop
Cleaning Wipes
WX10X305
$4.25
Broiler Pan Order Form
Customer Information
First
Name________________________
_
Last
Name________________________
_
Address
___________________________
City
_____________________________
_
State _______
Zip_______________
Phone __________________________
E-mail
_____________________________
I would like to order:
XL**
Quantity
________
17" W
________
________
Product Information
Model#
____________________________
Serial#
____________________________
Brand
_____________________________
Date of Purchase
Stainless Steel
Appliance Polish Wipes
WX10X10001
$5.25
Part #
_____________
_____________
_____________
Stainless Steel
Appliance Cleaner
PM10X311
$6.00

Advertisement

Table of Contents
loading

Summary of Contents for GE WB48X10056

  • Page 1 Thank you for purchasing a GE cooking product! The broiler pan referred to in the enclosed literature is not included and is available as an optional accessory. You can order your broiler pan (a $25 value) at a discount using the redemption coupon below or by calling 1-800-626-2002 toll free.
  • Page 2: Table Of Contents

    Safety Instructions Troubleshooting . . . 2–4 Tips Operating Instructions Accessories Clock and Timer ..10 Controls ... . .6, 7 Consumer Support Oven ....8, 9 Consumer Power Outage .
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire, electric shock, or to prevent property damage, personal injury, or loss of life. WARNING ANTI-TIP DEVICE All ranges can tip and injury could result.
  • Page 4 Use proper pan size—select cookware having flat bottoms large enough to cover the surface unit heating element. The use of undersized cookware will expose a portion of the surface unit to direct contact and may result in ignition of clothing. Proper relationship of cookware to surface unit will also improve efficiency.
  • Page 5 Care should be taken not to rub, damage or move the gasket. Before self-cleaning the oven, remove the broiler pan, grid and other cookware. Be sure to wipe up excess spillage before starting the self-cleaning operation.
  • Page 6: Surface Units

    Surface Cookware Tips Use medium- or heavy-weight cookware. Aluminum cookware conducts heat faster than other metals. Cast-iron and coated cast-iron cookware are slow to absorb heat, but generally cook evenly at low to medium heat settings. Steel pans may 1″...
  • Page 7 Using the oven controls. Throughout this manual, features and appearance may vary from your model. Oven Control, Clock and Timer Features and Settings BAKE/TEMP RECALL Pad Touch this pad to select the bake function. BAKE Light Flashes while in edit mode—you can change the oven temperature at this point.
  • Page 8: Power Outage

    BAKE/TEMP RECALL pad light will light up). To reset the clock, touch the CLOCK pad. Enter the correct time of day by touching the + or – pads. Touch the START/ON pad. ge.com...
  • Page 9: Using The Oven

    (A through F), they will stop before coming completely out, and will not tilt. When placing and removing cookware, pull the shelf out to the bump on the shelf support. To remove a shelf, pull it toward you, tilt the front end up and pull it out.
  • Page 10 2 (1″ thick) ″ thick) ″ thick 1″ thick ″ thick) 2 (1″ thick) about 1 lb. ge.com Touch the BROIL HI/LO pad once for HI Broil. To change to LO Broil, touch the BROIL HI/LO pad again. Touch the START pad.
  • Page 11: Clock And Timer

    Using the clock and timer. Not all features are on all models. To Set the Clock The clock must be set to the correct time of day for the automatic oven timing functions to work properly. The time of day cannot be changed during a delayed cooking or a delayed self-cleaning cycle.
  • Page 12: Roasting Features

    Touch the CLEAR/OFF pad to clear the display if necessary. Remove the food from the oven. Remember, even though the oven shuts off automatically, foods continue cooking after controls are off. ge.com...
  • Page 13: Special Features

    Special features of your oven control. Your new touch pad control has additional features that you may choose to use. The following are the features and how you may activate them. The special feature modes can only be activated while the display is showing the time of day. They remain in the control’s memory until the steps are repeated.
  • Page 14 The cooking time that you entered will be displayed. Touch the START/ON pad. Touch the BAKE pad. No signal will be given. ge.com Touch the START/ON pad. After a random delay period of approximately 30 seconds to 1 minute, ⊃...
  • Page 15: Thermostat

    Using the Sabbath Feature. (Designed for use on the Jewish Sabbath and Holidays) (on some models) How to Exit the Sabbath Feature Adjust the oven thermostat—Do it yourself! You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks to become more familiar with it.
  • Page 16 Remove the broiler pan, broiler grid, all cookware and any aluminum foil from the oven. NOTE: Wipe up heavy soil on the oven bottom.
  • Page 17 Using the self-cleaning oven. How to Delay the Start of Cleaning (on some models) Make sure the clock shows the correct time of day. To Stop a Clean Cycle Touch the CLEAR/OFF pad. Wait until the oven has cooled below the locking temperature to unlatch the door.
  • Page 18: Control Knobs

    Do not clean the bake element or the broil element. Any soil will burn off when the elements are heated. ge.com To assure no damage is done to the finish of the product, the safest way to remove the adhesive from packaging tape on new appliances is an application of a household liquid dishwashing detergent.
  • Page 19: Shelves

    Care and cleaning of the range. Oven Shelves If your oven is equipped with shiny, silver-colored oven shelves, they should be removed from the oven before beginning the self-cleaning cycle. Clean with an abrasive cleanser or plastic scrubbing pad. After cleaning, rinse the shelves with clean water and dry with a clean cloth.
  • Page 20: Lift-Off Oven Door

    Lift door up and out until the hinge arm is clear of the slot. Firmly grasp both sides of the door at the top. ge.com To clean the outside of the door: Use soap and water to thoroughly clean the top, sides and front of the oven door.
  • Page 21: Broiler Pan And Grid

    Care and cleaning of the range. Oven Light Replacement CAUTION: oven light bulb, disconnect the electrical power to the range at the main fuse or circuit breaker panel. Be sure to let the light cover and bulb cool completely. Wire cover holder. To remove the cover: Broiler Pan and Grid Do not clean the broiler pan or grid in a...
  • Page 22: Drip Pans

    Lift the surface unit about 1 inch above the drip pan and pull it out. ⁄ cup ammonia to ge.com To replace a surface unit: Replace the drip pan into the recess in the cooktop. Make sure the opening in the pan lines up with the receptacle.
  • Page 23 Food does not bake Oven controls improperly set. or roast properly Shelf position is incorrect or the shelf is not level. Incorrect cookware or cookware of improper size being used. Oven thermostat needs adjustment. Clock and timer do Plug on range is not completely •...
  • Page 24 SELF CLEAN pad goes off. Wipe up the excess soil and reset the self-cleaning cycle. • Allow the oven to cool below locking temperature. • Clean up heavy spillovers before starting the self-cleaning cycle. Heavily soiled ovens may need to self-clean again or for a longer period of time. ge.com...
  • Page 25 Before you call for service… Troubleshooting Tips Problem Possible Causes “F – and a number You have a function or letter” flash error code. in the display Display flashes “bAd” The installed connection then “linE” with a from the house to the unit loud tone is miswired.
  • Page 26 You can rest easy, knowing that all your valuable household products are protected against expensive repairs. Place your confidence in GE and call us in the U.S. toll-free at for more information. *All brands covered, up to 20 years old, in the continental U.S.
  • Page 27 Check here if you do not want to receive communications from GEA’s carefully selected partners. FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR WARRANTY RIGHTS. For more information about GEA’s privacy and data usage policy, go to ge.com and click on “Privacy Policy” or call 800.626.2224. Read your Owner’s Manual carefully.
  • Page 28 Notes.
  • Page 29 Notes.
  • Page 30 Notes.
  • Page 31 Accessories. Looking For Something More? You can find these accessories and many more at ge.com, or call 800.626.2002 (during normal business hours). Have your model number ready. Surface Elements & Drip Pans Oven Elements Cleaner Tired of discolored shelves? Wishing you had extra-heavy-duty oven shelves? GE’s innovative, self-cleanable porcelain-coated oven shelves!
  • Page 32 This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. If the product is located in an area where service by a GE Authorized Servicer is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE Service location for service.
  • Page 33 Caution must be exercised, since improper servicing may cause unsafe operation. Contact Us If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including your phone number, or write to: General Manager, Customer Relations Register Your Appliance Register your new appliance on-line—at your convenience! Timely product registration will allow for...
