Summary of Contents for Beko CS5533APW
- Page 1 Fridge Freezer Combi CS5533APW...
- Page 2 Please read this manual first! Dear Customer, We hope that your product, which has been produced in modern factories and checked under the most meticulous quality control procedures, will provide you with many years of good service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future reference.
-
Page 3: Table Of Contents
5 Using your refrigerator 14 1 Your refrigerator TEMPERATURE CONTROL AND ADJUSTMENT ......... 14 2 Warnings SUGGESTED ARRANGEMENT OF ELECTRICAL REQUIREMENTS ..5 FOOD IN THE FRIDGE/FREEZER ..15 WARNING! THIS APPLIANCE MUST STORING FROZEN FOOD ....16 BE EARTHED ........5 FREEZING FRESH FOOD .... -
Page 4: Your Refrigerator
Your refrigerator Congratulations on your choice of a BEKO quality Appliance which has been designed to give you service for many years. 1. Temperature setting knob 10.Door shelves 2. Interior light 11.Egg tray 3. Cabinet shelves 12.Bottle shelf 4. Defrost water collection channel 13.Bottle and can rack... -
Page 5: Warnings
• Do not dispose of the appliance on a • Do not use mechanical devices fire. At BEKO, the care and protection or other means to accelerate the of our environment is an ongoing defrosting process, other than those commitment. -
Page 6: Electrical Requirements
3. Connect the brown (Live) wire to from a BEKO Authorised Service the terminal in the plug marked ‘L’ or Agent. coloured red. WARNING! THIS APPLIANCE... -
Page 7: Energy Saving Tips
With alternative plugs a 13 A fuse must be fitted either in the plug or adaptor or in the main fuse box. If in doubt contact a qualified electrician. ENERGY SAVING TIPS 1- Ensure your appliance is installed in a well ventilated area. 2- Ensure the time between buying chilled/frozen food and placing them in your appliance is kept to a minimum,... -
Page 8: Installation
Do not allow children to play with against rain, moisture and other the appliance or tamper with the atmospheric influences. controls. BEKO declines to accept any 5.When positioning your appliance liability should the instructions not be take care not to damage your flooring, followed. - Page 9 and 90 degrees F) Therefore if the the floor. Correct adjustment of feet appliance is installed in an unheated/ avoids excessive vibration and noise. cold room (eg: conservatory/annex/ 6. Refer to cleaning and care section shed/garage etc) then the appliance to prepare your appliance for use.
-
Page 10: Replacing The Interior Light Bulb
REPLACING THE INTERIOR LIGHT BULB Should the light fail to work, proceed as follows. 1. Switch off at the socket outlet and pull out the mains plug. • You may find it useful to remove shelves for easy access. 2. Use a flat tipped screwdriver to remove the light diffuser cover by inserting the blade in each of the two recesses to prise off each side. -
Page 11: Reversing The Doors
REVERSING THE DOORS 4.Gently tilt the appliance back against a strong wall on its rear side We recommend that you reverse doors sufficiently to allow the lower hinge before switching on for the first time. to be removed. Take care to protect Tools required: Small and medium size the appliance, your wall and floor flat and cross-headed screwdrivers, a... - Page 12 12.Reposition left hand side feet on 21.Carefully stand the appliance the opposite side.(10) upright and adjust the two front feet if necessary. 13.Unscrew and remove the bottom door hinge pin bushing/door stopper 22.Check that doors open and close using a cross-headed screwdriver. (11) easily, they are aligned correctly and that there are no gaps allowing ir into Unscrew and remove the upper door...
- Page 13 (13) 45 ° 180°...
-
Page 14: Before Operating
Before operating Final Check Before you start using the fridge/ freezer check that: 1. The feet have been adjusted for perfect levelling. 2. The interior is dry and air can circulate freely at the rear of the cabinet. 3. Clean the interior as recommended under “CLEANING AND CARE.”... -
Page 15: Using Your Refrigerator
Using your refrigerator We recommend that you check TEMPERATURE CONTROL the temperature with an accurate AND ADJUSTMENT thermometer to ensure that the storage compartments are kept to the desired temperature. Remember you must take your reading very quickly since the thermometer temperature will rise very rapidly after you remove it from the freezer. -
Page 16: Suggested Arrangement Of Food In The Fridge/Freezer
SUGGESTED 2. The freezer compartment is ARRANGEMENT OF FOOD rated and suitable for the freezing of IN THE FRIDGE/FREEZER fresh food and storage of pre-frozen Arrangement Examples (See diagram) food. The recommendation for storage as stated on the food packaging should be observed at all times. -
Page 17: Storing Frozen Food
11. Shelves, racks, crisper bins, is best preserved when it is frozen drawers, flaps, bottle grippers are all right through to the core as quickly as removable. possible. 12. Do not leave frozen food at room Do not exceed the freezing capacity temperature to thaw;... -
Page 18: Defrosting
and stored in Ice Bank, they will B) FREEZER COMPARTMENT slowly reduce in size and eventually · Defrost twice a year or when a frost disappear completely. layer of around 7 mm (1/4”) has formed. DEFROSTING · To start defrosting procedure switch A) FRIDGE COMPARTMENT off the appliance at the socket outlet and pull out the mains plug.All food... -
Page 19: Maintenance And Cleaning
Maintenance and cleaning ** We recommend that you switch off the appliance at the socket outlet ** Removal of door rack and pull out the mains plug before • To remove door racks, remove cleaning. all the contents and then simply push the door rack upwards from the base. - Page 20 • Push the lug down with the tip of a screw driver & pull out with a jerk movement • Clean the drain tray and wipe it dry. • Reassemble reversing the sequence and operations. ** Avoid spillage of food particularly small items like rice, peas, beans through the fan guard as they may cause the cooling system to block and...
-
Page 21: Do's And Don'ts
Do's and Don'ts Do- Wrap all food in aluminium foil or Do- Clean your appliance regularly freezer quality polythene bags and (See “Cleaning and Care”) make sure any air is excluded. Do- Keep raw meat and poultry below Do- Wrap frozen food when you buy it cooked food and dairy products. -
Page 22: Problem Solving
PROBLEM SOLVING Don’t- Exceed the maximum freezing loads (4Kg in any 24 hours) when If the appliance does not operate when freezing fresh food. switched on, check whether: Don’t- Give children ice-cream and • The plug is inserted properly in the water ices direct from the freezer. -
Page 23: Guarantee Details
• The cost of functional replacement parts, but excluding consumable items. • The labour costs of a Beko approved repairer to carry out the repair. What is not covered? • Transit, delivery or accidental damage or misuse and abuse. -
Page 24: How To Obtain Service
Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Beko Customer Help-Line. Tel: 0845 6004911 e-mail: service@beko.co.uk... - Page 25 WARNING ! * DO NOT USE ANY COPPER POT, DISH INSIDE THE CABINET! * DO NOT LOAD ANY FOOD WITHOUT PACKAGE! WARNUNG ! * BENUTZEN SIE KEINERLEI KUPFERGESCHIRR IM GERÄT! * GEBEN SIE KEINE UNVERPACKTEN LEBENSMITTEL IN DAS GERÄT! AVERTISSEMENT ! * N'UTILISEZ PAS DE RECIPIENTS OU DE PLATS EN CUIVRE A L'INTERIEUR DES COMPARTIMENTS ! * N'INTRODUISEZ PAS DE DENREES NON EMBALLEES...
- Page 26 BEKO plc Beko House Caxton Way Watford Hertfordshire WD18 8UF Tel: 0845 6004911 Fax: 0845 6004922 Printed in Turkey e-mail: service@beko.co.uk 57 1231 0000 Part no: website: www.beko.co.uk Revision no:...
