SL4210/SL4210-WH
Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker
Features
• High-performance, surface-mountable loudspeaker for
foreground music, AV playback and distributed sound
• Exceptional sound quality with wide frequency
bandwidth and uniform dispersion
• 10-Watt, 3.5" x 1.18" Loudspeaker driver provides
exceptionally wide frequency response and ultra-wide
150° dispersion
• Professional 5-pole Euroblock connector
• 70.7V taps @ 1.25, 2.5, 5 & 10 Watts,
100V taps @ 2.5, 5 & 10 Watts
• Contemporary composite enclosure for
low-resonance performance
• Included dual-axis mounting hardware provides
90° V and 180° H alignment
• Detachable powder-coated steel grille and
contemporary aesthetic compliments any decor
• Weather resistant design for use in indoors or
protected outdoor areas
• High-quality components and exceptionally rugged
construction ensure long life
Product Overview
The EUROCOM SL4210 is a professional surface-mount
loudspeaker system that is ideal for a wide variety of interior
fixed installation applications involving background music,
AV playback, or distributed sound reinforcement. Offered
as part of the SL Series of complementary surface-mount
loudspeakers, the SL4210 delivers sound in a compact
package that fits easily and unobtrusively into limited space.
Power taps are provided for high-impedance operation at
1.25, 2.5, 5, or 10 W for 70 V systems, and 2.5, 5, or 10 W for
100 V systems.
Housed in a ported enclosure of low-resonance molded
composite, the SL4210 leaves behind the boxy shape
of traditional surface mount speakers, offering instead
a sleek look with smooth curves that enhance the
ambiance of any location. The front face is finished
with a detachable foam-backed wire-mesh steel grille,
available in black or white, that is trimmed with an elegant
smoked-chrome rim. The innovative SL Series mounting
yoke (included) offers 180 degrees pan, 90 degrees tilt,
allowing for for optimum loudspeaker aiming.
Combining performance and versatility in a compact, stylish
loudspeaker that looks good anywhere, the EUROCOM SL4210
is an excellent choice for any surface-mounted installation
requiring top quality sound and exceptional value.

Advertisement

loading

Summary of Contents for Behringer SL4210

  • Page 1 SL Series of complementary surface-mount • 10-Watt, 3.5" x 1.18" Loudspeaker driver provides loudspeakers, the SL4210 delivers sound in a compact exceptionally wide frequency response and ultra-wide package that fits easily and unobtrusively into limited space.
  • Page 2 SL4210/SL4210-WH Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker Technical Specifications • F requency range 120 Hz - 20 kHz (-10 dB) • F requency response 150 Hz - 18 kHz (±3 dB) • Nominal dispersion 150˚ • Directivity Factor (Q) 3.0 (avg. 500 Hz-16 kHz) • Directivity Index (DI) 4.7 dB (avg. 500 Hz-16 kHz) • S ensitivity 80 dB (1 W @ 1 m passive, half-space) • M aximum continuous 90 dB @ 1 m SPL (passive) • M aximum peak...
  • Page 3 • Height x Width x Depth of 6 x 3.8 x 3.9" / 152 x 97 x 101.5 mm • Net weight of not more than 1.45 lbs / 0.66 kg The loudspeaker system shall be the BEHRINGER EUROCOM SL4210.
  • Page 4 SL4210/SL4210-WH Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker Beamwidth VS. Frequency Vertical Up Off-Axis Frequency Response Horizontal Off-Axis Frequency Response Vertical Down Off-Axis Frequency Response Frequency Response, 1 W @ 1 M Directivity Index, Q...
  • Page 5 SL4210/SL4210-WH Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker Vertical 1/3 Octave Polars...
  • Page 6 SL4210/SL4210-WH Ultra-Compact, Surface-Mounted 10-Watt Loudspeaker Horizontal 1/3 Octave Polars...
  • Page 7: Dimensional Drawings

    SIDE Copyright © 2013 MUSIC Group IP Ltd. All rights reserved. BEHRINGER, KLARK TEKNIK, MIDAS, BUGERA, and TURBOSOUND are part of the MUSIC Group (music-group.com). The information contained herein is correct at the time of printing. Technical specifications and appearance are subject to change without notice. Colors and specifications may vary from actual product. MUSIC Group IP Ltd. accepts no liability for any damages or loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained herein.
