Scion IQ 2013 Specification

iQ
SPEcIFIcatIONS
E N G I N E
ENGINE DISPLACEMENT (LITERS) . . . . . . . . . . . . . . . . . . . . . . 1 .3L (1NR - FE) (1329CC)
HORSEPOWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94 HP @ 6,000 RPM
TORQUE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89 LB .-FT @ 4,400 RPM
VALVE CONFIGURATION . . . . . . . . . . . .DOHC, 4-VALVES PER CYLINDER WITH DUAL VVT-I
BORE X STROKE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 .5 X 80 .5 MM
COMPRESSION RATIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 .5 : 1
TRANSMISSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CVT-I
IGNITION SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . TOYOTA DIRECT IGNITION (TDI)
DRIVETRAIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FWD
BRAKES FRONT / REAR . . . . . . . . . . . . . . . . . . . . . . . . . . . VENTILATED DISC/DRUM
BRAKING SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . ABS WITH EBD & BRAKE
S U S P E N S I O N
TRACTION CONTROL (TRAC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . STANDARD
VEHICLE STABILITY CONTROL (VSC)(7) . . . . . . . . . . . . . . . . . . . . . . . . . . . STANDARD
STEERING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ELECTRIC POWER STEERING (EPS)
FRONT SUSPENSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .MACPHERSON
REAR SUSPENSION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TORSION BEAM
STABILIZER BARS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FRONT
E x t E r I O r d I m E N S I O N S
TURNING CIRCLE – CURB TO CURB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 .4 FT .
LENGTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120 . 1 IN .
WIDTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66 . 1 IN .
HEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 . 1 IN .
WHEELBASE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78 .7 IN .
GROUND CLEARANCE [1] . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 .3 IN .
COEFFICIENT OF DRAG (CD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0 .31
TIRES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175 / 60R16
TREAD WIDTH (FRONT / REAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 . 1 / 57 .5 IN
WHEELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16"x
SPARE TIRE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TIRE REPAIR KIT
I N t E r I O r d I m E N S I O N S
HEAD ROOM – FRONT / REAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 .7 / 35 .9 IN .
SHOULDER ROOM – FRONT / REAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 . 1 / 50 .2 IN .
LEG ROOM — FRONT / REAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 .9 / 28 .6 IN .
SEATING CAPACITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PASSENGER VOLUME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73 .8 CU . FT .
CARGO VOLUME (REAR SEATS UP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 .5 CU . FT .
w E I G h t S / c a Pa c I t I E S
FUEL CAPACITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 .5 GAL .
CURB WEIGHT (AT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2127 LBS .
m I l E a G E E S t I m at E S
MILEAGE ESTIMATES(2) AUTOMATIC TRANSMISSION . . . . . . . 36 / CITY, 37 / HWY, 37 COMB .
sPECiFiCATiOns / FEATUREs
1. Minimum running groung clearance. 2. 2013 EPA-MPG estimates. Actual mileage will vary. 3. Covers normal factory
scheduled service. Plan is 2 years or 25K miles,whichever comes first. The new Scion vehicle cannot be part of a rental or
commercial fleet, or a livery or taxi vehicle. Complimentary 24-hour roadside assistance, for iQ only, is 3 years from date
of first use. See plan for complete coverage details. See participating Scion Dealer for details. Offer is valid only in the
continental US and Alaska and is void where prohibited. For questions concerning Scion Service Boost, call 1-800-707-2466
or contact your local Scion Dealer. 4. Performance of Bluetooth ® compatible phones will vary based on phone software
version, coverage, and your wireless carrier. 5. HD Radio TM Technology under license from iBiguity Digital Corporation U.S.
and Foreign Patents. HD Radio TM and the HD, HD Radio TM , and "ARC" Logos are proprietary Trademarks of iBiguity Digital
Corporation. 6. iPod is a registered trademark of Apple, Inc. All rights reserved. 7. Vehicle Stability Control (VSC) ia an
®
electronic system designed to help the driver maintain vehicle control under adverse conditions. It is not a substitute for
safe driving practices. Factors including speed, road conditions and driver steering input can all affect whether VSC will be
effective in preventing a loss of control. Please see your Owners Manual for further details. 8. Brake Assist is designed to
help the driver take full advantage of the benefits of ABS. It is not a substitute for safe driving practices. Braking effective-
ness also depends on proper brake-system maintenance and tire and road conditions. 9. Smart Stop Technology operates
only in the event of certain simultaneous brake and gas pedal applications. When engaged, the system will reduce engine
power to help the brakes bring the vehicle to a stop. Factors including speed, road conditions and driver input can all impact
stopping distance. Smart Stop Technology is not a substitute for safe and attentive driving and does not guarantee instant
stopping. Please see your Owner's Manual for further details.
Standard equipment, options, accessories, and other information is subject to change.
cOlOr chOIcES
ASSIST(8)
STRUT
®
5 .0J STEEL
Find Us
Facebook.com/scion Youtube.com/user/scion
2013
Classic Silver Metallic Black Sand Pearl
Hot Lava
Classic Silver Metallic Firestorm
Magnetic Gray Metallic
Pacific Blue Metallic
Black Currant Metallic
Blizzard Pearl
Instagram@scion
00430-IQBRO-13
StaNdard FEatUrES
I NtErI Or / cONVENIENc E
COMPLIMENTARY SCION SERVICE BOOST[3]
AIR CONDITIONER
REMOTE KEYLESS ENTRY SYSTEM
MULTI-INFORMATION DISPLAY
MAP LIGHT
DIGITAL CLOCK
TACHOMETER & TRIP METER
LEATHER-TRIMMED STEERING WHEEL
TILT STEERING WHEEL WITH AUDIO CONTROLS
50/50 SPLIT FOLD-FLAT REAR SEATS
DUAL SUN VISORS WITH VANITY MIRRORS
OUTSIDE TEMPERATURE GAUGE
POWER DOOR LOCKS
POWER WINDOWS WITH DRIVER AND FRONT PASSENGER ONE-TOUCH AUTO UP / DOWN
REAR WINDOW DEFOGGER
ECO-DRIVING INDICATOR
FRONT PASSENGER UNDERSEAT STORAGE TRAY
REAR CARGO STORAGE BIN
Ex tErI Or
5-SPOKE WHEEL COVER
7-SPOKE WHEEL COVER
POWER OUTSIDE MIRRORS WITH TURN SIGNAL INDICATORS
PROJECTOR BEAM HEADLAMPS
INTERMITTENT FRONT WINDSHIELD WIPERS
REAR WINDOW WIPER
aUd IO
6 SPEAKERS
AUXILIARY AUDIO JACK
BLUETOOTH ® [4] AND HD RADIO™[5] TECHNOLOGY
USB PORT WITH IPOD ® [6] CONNECTIVITY
PIONEER™ STANDARD AUDIO SYSTEM
ROOF-MOUNTED ANTENNA
S aFEtY
STAR SAFETY SYSTEM™
- VEHICLE STABILITY CONTROL(VSC)[7]
- TRACTION CONTROL (TRAC)
- ANTI-LOCK BRAKE SYSTEM (ABS)
- ELECTRONIC BRAKE-FORCE DISTRIBUTION (EBD)
- BRAKE ASSIST[8]
- SMART STOP TECHNOLOGY[9]
DRIVER AND FRONT PASSENGER ADVANCED AIRBAG SYSTEM
DRIVER AND FRONT PASSENGER SEAT-MOUNTED SIDE AIRBAGS
FRONT AND REAR SIDE CURTAIN AIRBAGS
DRIVER AND FRONT PASSENGER KNEE AIRBAGS
DRIVER AND FRONT PASSENGER SEAT CUSHION AIRBAG
REAR WINDOW CURTAIN AIRBAG
3-POINT SEATBELTS FOR ALL SEATING POSITIONS
LATCH (LOWER ANCHORS AND TETHERS FOR CHILDREN)
TIRE PRESSURE MONITORING SYSTEM (TPMS)
FIRST AID KIT
lI mI tEd warr aNtY cOVEraGE
BASIC / 36 MONTHS / 36,000 MILES
(All components other than normal wear and maintenance items)
POWERTRAIN / 60 MONTHS /60,000 MILES
(Engine, Transmission / Transaxle, Front-Wheel Drive)
CORROSION PERFORATION / 60 MONTHS / UNLIMITED MILES
(Corrosion perforation of sheet metal)
RESTRAINT SYSTEMS / 60 MONTHS / 60,000 MILES
(Seatbelts and Airbags)
EMISSIONS / COVERAGE MAY VARY UNDER FEDERAL & CALIFORNIA REGULATIONS,
OR ANY STATE THAT ADOPTS CALIFORNIA EMISSION WARRANTY PROVISIONS .
(Refer to applicable Owner's Warranty Information booklet for additional details .) details.)
ScI O N S Er VI cE B OO St
COMPLIMENTARY SERVICE MAINTENANCE UP TO 2 YEARS / 25,000 MILES
WITH 3 YEAR 24-HOUR ROADSIDE ASSISTANCE FOR IQ ONLY . (3)
(Refer to the Scheduled Maintenance Guide for additional maintenance requirements .)
